Schedule 40 Low Carbon Steel Seamless Pipe and High Yield CS Welded Pipe exporter in Mumbai

Carbon Steel Pipe Supplier in India

What Is Carbon Steel Pipe Vs Carbon Steel Tube
Pipes and tubes are common piping modules in the carbon steel grade and can be used interchangeably in the system. These components can be differentiated based on certain features.

  • A carbon steel pipe can only be shaped in circular cross-sections. Tubes in the carbon steel grade can be shaped in circular, rectangular, and square cross-sectional areas.
  • Carbon pipes require special equipment to be precisely shaped. Carbon steel tubes can be easily bent or shaped using normal equipment.
  • Steel tubes of the carbon grade are more rigid and strong when compared to steel pipes in the carbon grade.
  • Carbon tubes can be produced by the hot and cold rolling process. Pipes can only be manufactured by the hot rolling process.

Seamless Carbon Steel Tube Vs Welded Black Steel Pipe
Carbon steel piping grades can be produced by seamless and welded configurations. Both these types can be distinguished based on key features.

  • Seamless carbon tubes are manufactured by passing hot steel billets through metal and precisely shaping them. Welded black pipes are produced by welding pieces of sheets or strips.
  • Seamless carbon steel tubes possess more strength and load-bearing capacity than a welded black steel pipe.
  • Welded pipe grades are cheaper than seamless modules.

Carbon Steel Square Tube Vs Rectangular Tubing
The key difference between a carbon steel square and rectangular tubing is their cross-sectional area. Apart from this, a square tube is employed in the construction, machinery, shipbuilding, railway, and other related applications. Rectangular tubing is mostly employed in applications wherein the tubes are used to transport fluids, petroleum, and natural gas, where the requirement of bending and torsional strength is of the highest degree.

Is Carbon Steel Ptfe Lined Pipe Good for High Pressure?
Ptfe lined pipes are coated with a non-reactive polytetrafluoroethylene grade. The grade is very strong and prevents wear and tear due to high-pressure fluid flow in corrosive environments.

Hot /cold drawn Large Diameter Low Carbon Steel Erw Pipe Supplier and exporter in India, Buy Jindal and ISMT Make Galvanized Carbon Steel Tube for boilers at factory price list ex Mumbai

Carbon Steel Seamless Pipe Price List FOB Mumbai India

ProductsSpecificationsCoatingFOB Mumbai
ODWTLengthUSD/ TON
INCH12MM14SCHMMM
Carbon Steel Seamless Pipe133.4S-403.386.0Black$ 833
High Carbon Steel SMLS Pipe1 1/442.2S-403.56$ 764
Low CS Seamless Pipe1 1/248.3S-403.68$ 764
Medium Carbon Steel SMLS Pipe260.3S-403.91$ 750
Black CS Seamless Pipe2 1/273.0S-405.16$ 799
Fully Killed CS Seamless Pipe388.9S-405.49$ 799
Galvanized Carbon Steel SMLS Pipe4114.3S-406.02$ 764
Killed CS Seamless Pipe5141.3S-406.55$ 799
Low Temperature Carbon Steel SMLS Pipe6168.3S-407.11$ 799
Nace Mr0175 Carbon Steel Seamless Pipe8219.1S-408.18$ 792
Normalized CS Seamless Pipe10273.1S-409.27$ 833
Plain CS SMLS Pipe12323.9S-4010.31$ 833
Quenching Low Carbon Steel Seamless Pipe14355.6S-4011.31$ 833
Quenching High CS SMLS Pipe16406.4S-4012.70$ 875

AD 2000/ Nace Mr0175 / ADW and IBR approved ASTM A524 Low Carbon Pipe, check SCH 40 Carbon Steel Pipe and ASTM A524 Low CS tube price per meter and cost per foot in India

Carbon Steel Pipe Materials Selection And Specification

Sizes1/2" NB upto 36" NB
Surface FinishNo.1, 2B, No.4 Mirror Finish, No.8
FormSquare, Hydraulic Tubes, “U” Shape, Pan Cake Coils, Rectangular, Coiled, Round.
Schedule ThicknessSchedule XS, Schedule 40, Schedule 80S, Schedule 5, Schedule 80, Schedule XXS, Schedule 160, Schedule 10
Thicknessbetween 3 to 12 millimeter
TypeWelded | CDW | ERW | DOM | Seamless | Fabricated | CEW
LengthMin. 3 to Max. 18 Meters; Single Random, Double Random, Cut to length
EndScrewed, Beveled, Threaded, Plain
Delivery ConditionAnnealed & Pickled, Polished, Bright & Annealed, etc

API SPEC 5L
Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
Line PipesØ10.3~1200 x WT1.0~120API 5LA, B, X42, X46, X52, X60, X70, X80, PSL1 / PSL2
API SPEC 5CT
Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
CastingØ114~219 x WT5.2~22.2API 5CTJ55, K55, N80, L80, P110
TubingØ48.3~114.3 x WT3.2~16API 5CTJ55, K55, N80, L80, P110
ASTM / ASME
Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
Black and Hot-Dipped Zinc-Coated Seamless Steel PipesØ10.3~1200 x WT1.0~150ASTM A53Gr.A, Gr.B, Gr.C
Seamless Carbon Steel Pipes for High Temperature ServiceØ10.3~1200 x WT1.0~150ASTM A106Gr.B, Gr.C
Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser TubesØ10.3~426 x WT1.0~36ASTM A179Low Carbon Steel
Seamless Carbon Steel Boiler Tubes for High PressureØ10.3~426 x WT1.0~36ASTM A192Low Carbon Steel
Seamless Cold-Drawn Intermediate Alloy Steel Heat-Exchanger and Condenser TubesØ10.3~426 x 1.0~36ASTM A199T5, T22
Seamless Medium-Carbon Steel Boiler and Superheater TubesØ10.3~426 x WT1.0~36ASTM A210A1, C
Seamless Ferritic and Austenitic Alloy Steel Boiler, Superheater and Heat-Exchanger TubesØ10.3~426 x WT1.0~36ASTM A213T5, T9, T11, T12, T22, T91
Seamless Carbon and Alloy Steel for Mechanical TubingØ1/4"~42" x WT SCH20~XXSASTM A333Gr.1, Gr.3, Gr.6
Seamless and Welded Carbon Steel Pipes and Alloy Steel Pipes for Low Temperature UseØ1/4"~4" x WT SCH20~SCH80ASTM A334Gr.1, Gr.6
Seamless Cold-Drawn Carbon Steel Feedwater Heater TubesØ10.3~426 x WT1.0~36ASTM A556A2, B2
DIN
Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
Seamless Steel Tubes for Elevated TemperatureØ10~762 x WT1.0~120DIN 17175St35.8, St45.8, 10CrMo910, 15Mo3, 13CrMo44, STPL340, STB410, STB510, WB36
Seamless Steel TubesØ13.5~762 x WT1.8~120DIN 1629 / DIN 2391St37.0, St44.0, St52.0, St52.3
Seamless Steel TubesØ13.5~165.1 x WT1.8~4.85DIN 2440St33.2
Seamless Steel Pipes for Structural PurposeØ16~426 x WT1.0~36DIN 2393RSt34-2, RSt37-2, RSt44-2, St52

Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
Seamless Steel Tubes for Machine StructureØ10~762 x WT1.0~120BS 970Carbon Steel
Seamless Steel Tubes for Boiler and Heat ExchangersØ10~762 x WT1.0~120BS 3059360, 410, 440, 460, 490

Carbon Steel Erw Pipe Wall thickness table DIN / ISO / EN / ASME

Sizes1/2" NB upto 36" NB
Surface FinishNo.1, 2B, No.4 Mirror Finish, No.8
FormSquare, Hydraulic Tubes, “U” Shape, Pan Cake Coils, Rectangular, Coiled, Round.
Schedule ThicknessSchedule XS, Schedule 40, Schedule 80S, Schedule 5, Schedule 80, Schedule XXS, Schedule 160, Schedule 10
Thicknessbetween 3 to 12 millimeter
TypeWelded | CDW | ERW | DOM | Seamless | Fabricated | CEW
LengthMin. 3 to Max. 18 Meters; Single Random, Double Random, Cut to length
EndScrewed, Beveled, Threaded, Plain
Delivery ConditionAnnealed & Pickled, Polished, Bright & Annealed, etc

API SPEC 5L
Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
Line PipesØ10.3~1200 x WT1.0~120API 5LA, B, X42, X46, X52, X60, X70, X80, PSL1 / PSL2
API SPEC 5CT
Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
CastingØ114~219 x WT5.2~22.2API 5CTJ55, K55, N80, L80, P110
TubingØ48.3~114.3 x WT3.2~16API 5CTJ55, K55, N80, L80, P110
ASTM / ASME
Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
Black and Hot-Dipped Zinc-Coated Seamless Steel PipesØ10.3~1200 x WT1.0~150ASTM A53Gr.A, Gr.B, Gr.C
Seamless Carbon Steel Pipes for High Temperature ServiceØ10.3~1200 x WT1.0~150ASTM A106Gr.B, Gr.C
Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger and Condenser TubesØ10.3~426 x WT1.0~36ASTM A179Low Carbon Steel
Seamless Carbon Steel Boiler Tubes for High PressureØ10.3~426 x WT1.0~36ASTM A192Low Carbon Steel
Seamless Cold-Drawn Intermediate Alloy Steel Heat-Exchanger and Condenser TubesØ10.3~426 x 1.0~36ASTM A199T5, T22
Seamless Medium-Carbon Steel Boiler and Superheater TubesØ10.3~426 x WT1.0~36ASTM A210A1, C
Seamless Ferritic and Austenitic Alloy Steel Boiler, Superheater and Heat-Exchanger TubesØ10.3~426 x WT1.0~36ASTM A213T5, T9, T11, T12, T22, T91
Seamless Carbon and Alloy Steel for Mechanical TubingØ1/4"~42" x WT SCH20~XXSASTM A333Gr.1, Gr.3, Gr.6
Seamless and Welded Carbon Steel Pipes and Alloy Steel Pipes for Low Temperature UseØ1/4"~4" x WT SCH20~SCH80ASTM A334Gr.1, Gr.6
Seamless Cold-Drawn Carbon Steel Feedwater Heater TubesØ10.3~426 x WT1.0~36ASTM A556A2, B2
DIN
Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
Seamless Steel Tubes for Elevated TemperatureØ10~762 x WT1.0~120DIN 17175St35.8, St45.8, 10CrMo910, 15Mo3, 13CrMo44, STPL340, STB410, STB510, WB36
Seamless Steel TubesØ13.5~762 x WT1.8~120DIN 1629 / DIN 2391St37.0, St44.0, St52.0, St52.3
Seamless Steel TubesØ13.5~165.1 x WT1.8~4.85DIN 2440St33.2
Seamless Steel Pipes for Structural PurposeØ16~426 x WT1.0~36DIN 2393RSt34-2, RSt37-2, RSt44-2, St52

Product NameDimension (mm)Executive StandardSteel Code / Steel Grade
Seamless Steel Tubes for Machine StructureØ10~762 x WT1.0~120BS 970Carbon Steel
Seamless Steel Tubes for Boiler and Heat ExchangersØ10~762 x WT1.0~120BS 3059360, 410, 440, 460, 490

Epoxy Lined Carbon Steel Pipe Materials comparison DIN / EN / ASTM

Pipes / Tubes
Material numberENASTM
Alloyed heat-resistant
1.738010 CrMo 9 1010CrMo9–10A 335 Grade P22
1.541515 Mo 316Mo3A 335 Grade P1
A 335 Grade P11
1.733513 CrMo 4 413CrMo4–5A 335 Grade P12
A 335 Grade P9
1.736212 CrMo 19 5X11CrMo5A 335 Grade P5
1.4903X10CrMoVNb9–1A 335 Grade P91
Non-alloy
1.0305St 35.8/IIIP235GH TC2 (1.0345)
1.0254St 37.0P235TR1A 53 Grade A
1.0305St 35.8/IP235GH TC1 (1.0345)A 106 Grade A
1.0570St 52-3S355J2H (1.0576)
1.0405St 45.8/IIIP265GH TC2 (1.0425)
1.0405St 45.8/IP265GH TC1 (1.0425)A 106 Grade B
Fine-grain steels
1.8902StE 420P420NAPI 5L Grade X60
1.0486StE 285API 5L Grade X42
1.8905StE 460P460NAPI 5L Grade X70
1.0562StE 355P355NAPI 5L Grade X52
Low temperature
P265NL (1.0453)A 333 Grade 6
1.563710 Ni 14X12Ni14A 333 Grade 3
1.0356TTSt 35 VP255QL (1.0452)
1.0356TTSt 35 NP215NL (1.0451)A 333 Grade 1
High yield steels
1.0582StE 360.7L360NB / L360NEAPI 5L Grade X52
1.0457StE 240.7L245NB / L245NEAPI 5L Grade B
1.8972StE 415.7L415NB / L415NEAPI 5L Grade X60
1.0484StE 290.7L290NB / L290NEAPI 5L Grade X42

Value Added Services of Black Carbon Steel Pipe

Black Carbon Steel Pipe
We stock and supply galvanized Carbon Steel Welded Pipe stock, SCH 40-XXS CS Seamless Pipe custom length cutting at ZERO COST, offer PTFE/ Epoxy/ FBE Lined Pipe coating in desired wall thickness and large diameter.

Spiral Welded Steel Pipe Standard Sizes

Nominal sizeASME B36.10M Welded & Seamless Carbon Steel Pipe supplier
All dimensions
Schedule (mm)
OD
NPSDN6010100201203014040160StdXXS80XSmm
1/861.241.451.731.732.412.4110.3
1/481.651.852.242.243.023.0213.7
3/8101.651.852.312.313.203.2017.1
1/2152.112.412.774.782.777.473.733.7321.3
3/4202.112.412.875.562.877.823.9126.7
1252.772.903.386.353.389.094.554.5533.4
11/4322.772.973.566.353.569.704.854.8542.2
11/2402.773.183.687.143.6810.155.085.0848.3
2502.773.183.918.743.9111.075.545.5460.3
21/2653.054.785.169.535.1614.027.017.0173.0
3803.054.785.4911.135.4915.247.627.6288.9
31/2903.054.785.745.748.088.08101.6
41003.0511.134.786.0213.496.0217.128.568.56114.3
51253.4012.706.5515.886.5519.059.539.53141.3
61503.4014.277.1118.267.1121.9510.9710.97168.3
820010.313.7615.096.3518.267.0420.628.1823.018.1822.2312.7012.70219.1
1025012.704.1918.266.3521.447.8025.409.2728.589.2725.4015.0912.70273.0
1230014.274.5721.446.3525.408.3828.5810.3133.329.5325.4017.4812.70323.8
1435015.096.3523.837.9227.799.5331.7511.1335.719.5319.0512.70355.6
1640016.666.3526.197.9230.969.5336.5312.7040.499.5321.4412.70406.4
1845019.056.3529.367.9234.9311.1339.6714.2745.249.5323.8312.70457
2050020.626.3532.549.5338.1012.7044.4515.0950.019.5326.1912.70508
2255022.236.3534.939.5341.2812.7047.6353.989.5328.5812.70559
2460024.616.3538.899.5346.0214.2752.3717.4859.549.5330.9612.70610
266507.9212.709.5312.70660
287007.9212.7015.889.5312.70711
307507.9212.7015.889.5312.70762
328007.9212.7015.8817.489.5312.70813
348507.9212.7015.8817.489.5312.70864
369007.9212.7015.8819.059.5312.70914
389509.5312.70965
4010009.5312.701016
4210509.5312.701067
4411009.5312.701118
4611509.5312.701168
4812009.5312.701219

What Are The Different Types Of Large Diameter Carbon Steel Pipe ?

Carbon Steel Seamless Pipe
Carbon Steel Seamless Pipe
Carbon Steel Seamless Pipe
SCH 40 Carbon Steel Pipe
SCH 40 Carbon Steel Pipe
SCH 40 Carbon Steel Pipe
Low Carbon Steel Pipe
Low Carbon Steel Pipe
Low Carbon Steel Pipe
Carbon Steel Erw Pipe
Carbon Steel Erw Pipe
Carbon Steel Erw Pipe
Carbon Steel Welded Pipe
Carbon Steel Welded Pipe
Carbon Steel Welded Pipe
Large Diameter Carbon Steel Pipe
Large Diameter Carbon Steel Pipe
Large Diameter Carbon Steel Pipe
Carbon Steel Tubes
Carbon Steel Tubes
Carbon Steel Tubes
Carbon Steel Boiler Tubes
Carbon Steel Boiler Tubes
Carbon Steel Boiler Tubes
PTFE Lined Carbon Steel Pipe
PTFE Lined Carbon Steel Pipe
PTFE Lined Carbon Steel Pipe
Do not forget to compare our price and delivery time with other carbon steel pipe suppliers in India, ask CS ERW Pipe and rectangular tubing for a Free quote & Free sample now! check galvanized Carbon Steel Welded Pipe specification, chemical and mechanical properties

Carbon Steel Seamless Pipe Chemical Structure

specification Grade Chemical Composition [%]
C Mn P S Si Cr Mo Cu Ni V
Min Max. Min Max. Max. Max. Min. Max Min. Max Min. Max Max Max Max
HYDROCARBON PROCESS INDUSTRY/STRUCTURAL/PRESSURE VESSEL TUBES
ASTM A-106 A
B c
- - - 0.25 0.30
0.35
0.27 0.29
0.29
0.93 1.06
1.06
0.035 0.035
0.035
0.035 0.035
0.035
0.10 0.10
0.10
- - - - - - 0.40 0.40
0.40
- - - 0.15 0.15
0.15
0.40 0.40
0.40
0.40 -
0.08 0.08
0.08
ASTM A-53 A
B
- - 0.25 0.30 - - 0.95 1.20 0.050 0.050 0.045 0.045 - - - - - - 0.40 0.40 - - 0.15 0.15 0.40 for S 0.40 for S 0.40 0.40 0.08 0.08
ASTM A333 & A 334 1
6
-
-
0.30 0.30 0.40 0.29 1.06 1.06 0.025 0.025 0.025 0.025 - 0.10 - - - - - - - - - - - - - - - -
SEAMLESS COLD DRAWN PRECISION STEEL TUBES FOR MECHANICAL APPLICATIONS/HYDRAULIC/PNEUMATIC POWER SYSTEMS
DIN 2391 St - 45
St - 45
St - 52
-
-
-
0.17 0.21
0.22
0.40 0.40 - - -
1.60
0.025 0.025
0.025
0.025 0.025
0.025
- - - 0.35 0.35
0.55
- - - - - - - - - - - - - - - - - - - - -
EN 10305-1/ EN10305-4 E 235 E 355 0.17 0.22 1.2 1.6 0.025 0.025 0.025 0.025 0.35 0.55 0.02 0.02
ASTM A-519 SAE 1010
SAE 1018
SAE 1026
SAE 1035 SAE 1040
SAE 1518
SAE 1541
SAE 4130
0.08 0.15
0.22
0.32
0.37
0.15
0.36
0.28
0.13 0.20 0.28
0.38
0.44
0.21
0.44
0.33
0.30 0.60
0.60
0.60
0.60
1.10
1.35
0.40
0.60 0.90
0.90
0.90
0.90
1.40
1.65
0.60
0.040 0.040
0.040
0.040
0.040
0.040
0.040
0.040
0.050 0.050
0.050
0.050
0.050
0.050
0.050
0.040
- - -
-
-
-
-
0.15
- - -
-
-
-
-
0.35
- - -
-
-
-
-
0.80
- - -
-
-
-
-
1.10
- - -
-
-
-
-
0.15
- - -
-
-
-
-
0.25
- - -
-
-
-
-
-
- - -
-
-
-
-
-
- - -
-
-
-
-
-
EN 10216-1 P195 TR1
P235 TR1
0.13 0.16 0.7 1.2 0.025 0.025 0.02 0.02 0.35 0.35 0.3 0.3 0.08 0.08 0.3 0.3 0.3 0.3
EN 10216-2 P235 GH 0.16 1.2 0.025 0.02 0.35 0.3 0.08 0.3 0.3 0.02
BOILER/HEAT EXCHANGER/SUPERHEATER & CONDENSER TUBES
ASTM
A335
P-11
P-12 P-22
0.05 0.05
0.05
0.15 0.15
0.15
0.30 0.30
0.30
0.60 0.61
0.60
0.025 0.025
0.025
0.025 0.025
0.025
0.50 -
-
1.00 0.50
0.50
1.00 0.80
1.90
1.50 1.25
2.60
0.44 0.44
0.87
0.65 0.65
1.13
- -
-
- -
-
- -
-
ASTM A179 - 0.06 0.18 0.27 0.63 0.035 0.035 - - - - - - - - -
BS 3059 Pt I 320 - 0.16 0.30 0.70 0.040 0.040 0.10 0.35 - - - - - - -
ASTM A192 0.06 0.18 0.27 0.63 0.035 0.035 - 0.25 - - - - - - -
DIN 1629 St- 37.0 St - 52 - - 0.17 0.22 - - - - 0.040 0.040 0.040 0.035 - - - - - - - - - - - - - - - - - -
ASTM A 210 A-1
C
-
-
0.27 0.35 - 0.29 0.93 1.06 0.035 0.035 0.035 0.035 0.10 0.10 - - - - - - - - - - - - - - - -
DIN 17175 St - 35.8 St - 45.8 - - 0.17 0.21 0.40 0.40 0.80 1.20 0.040 0.040 0.040 0.040 0.10 0.10 0.35 0.35 - - - - - - - - - - - - - -
ASTM A 213 T-11
T-12 T-22
0.05 0.05
0.05
0.15 0.15
0.15
0.30 0.30
0.30
0.60 0.61
0.60
0.025 0.025
0.025
0.025 0.025
0.025
0.50 -
-
1.00 0.50
0.50
1.00 0.80
1.90
1.50 1.25
2.60
0.44 0.44
0.87
0.65 0.65
1.13
- -
-
- -
-
- -
-
BS 3059 Pt II 622-490 0.08 0.15 0.40 0.70 0.030 0.030 - 0.50 2.00 2.50 0.90 1.20 - - -
RAILWAYS
IS:1161 YST-210 YST-240
YST-310
- -
-
0.12 0.16
0.25
- -
-
0.60 1.20
1.30
0.040 0.040
0.040
0.040 0.040
0.040
- -
-
- -
-
- -
-
- -
-
- -
-
- -
-
- -
-
- -
-
- -
-
IS:1239 Pt I - - - - - 0.050 0.050 - - - - - - - - -

SCH 40 Carbon Steel Pipe Mechanical Analysis

Grade A Grade B Grade C
Yield properties, min, psi (MPa) 30,000 (205) 35,000 (240) 40,000 (275)
Tensile properties, min, psi (MPa) 48,000 (330) 60000 (415) 70,000 (485)

Low Carbon Steel Pipe Equivalent Material

Low Carbon Steel Pipe Equivalent Material

Cs Seamless Pipe weight per meter

NominalOD mmPipe sizeSch STDSch 40NominalPipe sizeOD mmSch STDSch 40
MmWallInchWt.WallWt.1004114.36.0216.076.0216.07
2533.413.382.53.382.535014355.69.5381.311.1394.3
310.31/81.730.371.730.3571255141.36.621.776.5521.77
3242.21 1/43.563.393.563.3840016406.49.5393.312.7123
613.7¼2.240.632.240.6251506168.37.1128.267.1128.26
4048.31 1/23.684.053.684.0545018457.29.5310514.3156
1017.13/82.310.842.310.842008219.18.242.58.242.5
65732 1/25.28.635.168.6355022558.89.53129
1521.3½2.771.262.771.26250102739.2760.39.2760.3
8088.935.511.35.511.360024609.69.5314117.4255
2026.7¾2.871.692.871.6830012323.99.5373.810.379.7
5060.323.95.443.95.44500205089.53177.215.1183
901.631/25.7413.575.7413.57Seamless Sch 40 Pipe/Seamless Pipe

Schedule 40 Carbon Steel Pipe Pressure Rating

NPSODSchedule
(inches)(inches)60108020XXSSTD12030140XS16040100
3/80.6759147660691476606
22.375449889953177449870973177
1/20.8485751715063588575109086358
11.3156670133404956667093164956
1 1/41.665638112764133563873804133
2 1/22.875470494083460470463913460
3 1/243896276938962769
1212.7521602644961384314413843126843241922504215603244
44.53670733925814769367057822581
66.6253195639020714157319553182071
88.625230728411420497118294085157446132841514718293375
141420798752625109213133829131343751750492115333283
18182042681255384910213743119242521361484815303147
2020198961325269199193675122542881225482414553138
4242583438729875
2424197851024897667663700114742101021478614053126
30305108176131021817
3434450721540901992

Carbon Steel Black Pipe High Pressure applications

ASTMABSASMELRSJIS G 3454ISODINNKBSDNV
A53 AABS 2SA53 ASec 2 320STPG 3702604 II TW41626 ust37.0KSTPG 383601 320Sec 4-B-TS360
Sec 2 3602604 III TS4
A135 AABS 8SA135 ASec 3 3202604 II TS51626 st37.03601 360Sec 4-B-TW360
Sec 3 3602604 III TW5
2604 II TS61629 st37.0
2604 III TW6
A53 BABS 3SA53 BSec 2 410STPG 4102604 II TS91626 st44.0KSTPG 423601 430Sec 4-B-TS410
2604 III TW9Sec 4-B-TW410
A135 BABS 9SA135 BSec 3 4102604 II TS101629 st44.0Sec 4-B-TS430
2604 III TW10Sec 4-B-TW430
Sec 2 4602604 II TS131626 st52.0Sec 4-B-TS500
2604 III TW13Sec 4-B-TW500
Sec 2 4902604 II TS141629 st52.0
Sec 3 4602604 III TW14

JIS G 3455ISODINNK
STS 3701630 st37.4KSTS 38
STS 4102604 II TS151630 st44.4KSTS 42
STS 4802604 II TS181630 st52.4KSTS 49

Epoxy Coated Carbon Steel Pipe High Temperature applications

ASTM JIS G 3456 ASME ABS DIN BS NK
A106 A STPT 370 SA106 A ABS 4 17175 st35.8 3602 P1 360 KSTPT 38
17177 st37.8
A106 B STPT 410 SA106 B ABS 5 17175 st45.8 3602 P1 430 KSTPT 42
17177 st42.8
A106 C STPT 480 SA106 C 17175 17Mn4 3602 P1 500Nb KSTPT 49
17175 19Mn5
Looking for a reliable carbon steel pipe suppliers in India? check Low/ High/ Medium/ Normalized/ Quenching/ Fully Killed/ Plain CS Seamless Pipes weight chart, SCH 80 CS Seamless Tube Tolerence and standards.

Carbon Steel Tubes Standards

Types Grades Std
Seamless Steel Tubes for Elevated Temperature STB410, 15Mo3, St45.8, 10CrMo910, WB36, STPL340, St35.8, STB510, 13CrMo44 DIN 17175
Seamless Steel Tubes St33.2 DIN 2440
Seamless Steel Pipes for Structural Purpose RSt34-2, RSt44-2, RSt37-2, St52 DIN 2393
Seamless Steel Tubes St52.3, St52.0, St37.0, St44.0 DIN 1629 and DIN 2391

Carbon Steel Square Tube Tolerance

Types Size (MM) Tolerances (MM)
Cold drawn Outer Diam. 50 ±1%
6 To 10 ±0.20
30 To 50 ±0.45
10 To 30 ±0.40
Wall Thk. 1 To 3 +15% -10%
1 ±0.15
3 +12.5% -10%
Hot rolled Wall Thickness All +15%, -12.5%
Outer Diam. All ±1% (min ±0.50)

Coated Carbon Steel Pipe

Coating Type Coating Layer Coating thickness
Two layers polyethylene Outside layer: polythene 2.0 -4.5mm
Inside layer: adhensive
Epoxy Epoxy 200-400um
Two layers epoxy Inside layer: expoxy (Green) 400-800um
Outside layer:intensity epoxy (sage green)
Three layers polyethylene Inside layer: epoxy (Green) 2.0 -4.5mm
Outsidelayer:polyethylene (Black)
Mid layer: adhensive (White)
Three layers polyethylene Inside layer: expoxy (Green) 2.5 -3mm
Outside layer: polypropylene (White)
Mid layer: adhensive (White)
Coated Carbon Steel Pipe

Low Carbon Steel Pipe Uses

  • Pulp and Paper Industry
  • Sea Water Equipment
  • Petrochemicals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Heat Exchangers

ASTM A500 Grb CS ERW Pipe Schedule Chart

N.P.S (mm)Outer Diam. (MM)Pipe Sizes (inch)Schedule 20Schedule 60Schedule STDSchedule EXTRASchedule 40Schedule XS
613.7¼2.240.633.022.240.6250.804
310.31/81.730.372.411.730.3570.47
1017.13/82.310.843.22.310.841.1
2026.7¾2.871.693.912.871.682.2
1521.3½2.771.263.732.771.261.62
3242.211/43.563.394.853.563.384.47
2533.413.382.54.553.382.53.24
4048.311/23.684.055.083.684.055.41
657321/25.28.6375.168.6311.41
5060.323.95.445.53.95.447.48
8088.93/85.511.37.625.511.315.3
100114.346.0216.078.566.0216.0722.3
901.631/25.7413.578.085.7413.5718.63
125141.356.621.779.536.5521.7730.9
200219.186.3533.310.353.18.242.512.78.242.564.6
150168.367.1128.2610.977.1128.2642.5
250273106.3541.712.781.59.2760.312.79.2760.381.5
350355.6147.9268.115.1126.49.5381.312.711.1394.3107
300323.9126.3549.714.31099.5373.812.710.379.797.4
450457.2187.9287.8192069.5310512.714.3156130
400406.4167.9277.916.71609.5393.312.712.7123123
500508209.53117.220.62489.53177.212.715.1183155.1
600609.6249.5314124.53559.5314112.717.4255187
550558.8229.5312922.22949.5312912.7171

Carbon Steel Rectangular Tubing HS Code

Description HSN Code
Carbon Steel Pipes 73049000
Check JIS G 3445 Grade STKM 11A low carbon steel boiler tubes and heat exchanger tubing Dimensions and Carbon Steel Erw Pipe inventory according to ASME B36.19

Carbon Steel Welded Pipe Services

Carbon Steel Welded Pipe Services

Carbon Steel Square Pipe Dimensions Chart

NBSizeO.D.5S40SXXSS10S140S20S60S40S100XS/80SS80S120S160
1/413.722.243.02
3/817.152.313.2
203/426.671.72.97.822.873.913.915.56
25133.41.73.49.093.384.554.556.35
321 1/442.161.73.69.73.564.854.856.35
401 1/248.261.73.710.23.685.085.087.14
50260.331.73.911.13.915.545.549.74
652 1/273.032.15.2145.167.017.019.53
903 1/2101.62.15.75.748.088.08
1004114.32.1617.16.028.568.5611.113.5
1506168.32.87.1227.1110.971114.318.3
30012323.949.525.428.66.414.310.321.412.717.525.433.3
35014355.649.56.431.87.915.111.123.812.719.127.835.7
45018457.24.29.56.439.77.919.114.329.412.723.834.945.2
500205084.89.56.444.59.520.615.132.512.726.238.150
60024609.65.59.56.452.49.524.617.538.912.7314659.5
65026660.49.57.91312.7
750307626.49.57.91312.7
80032812.89.57.91317.512.7
90036914.49.57.91319.112.7

Structural Steel Pipe

Product Structural Seamless Pipes
Size Range Outer Diameter between 73 To 630
Wall Thk between 6-35mm
Length in Meter between 5.8 To 12
Pipes Standard ASTM A519, ASTM A500, ASTM A53, EN 10210/ 10219, DIN1629, JIS G3444
Uses Mechanism Industry, General Structure

We are the stockist of Baotou Steel Union, TPCO and Baosteel in Mumbai

Baotou Steel Union, Inner Mongolia
Baotou Steel Union, Inner Mongolia
Baotou Steel Union, Inner Mongolia
TPCO, China
TPCO, China
TPCO, China
Baosteel, Shanghai, China
Baosteel, Shanghai, China
Baosteel, Shanghai, China

FBE Lined carbon steel pipe Available Type

Carbon Steel Pipe Epoxy Lined Carbon Steel Pipe
carbon seamless steel pipe Epoxy Coated Carbon Steel Pipe
Carbon Steel Pipe Carbon Steel Square Pipe
SCH 40 Carbon Steel Pipe Carbon Steel Tubes
Low Carbon Steel Pipe Carbon Steel Square Tube
Carbon Steel ERW Pipe CS ERW Pipe
SCH 40 Steel Pipe ASTM A500 Grb
SCH 40 Seamless Pipe Carbon Steel Rectangular Tubing
Carbon Steel Erw Pipe Carbon Steel Tubing
Carbon Steel Welded Pipe Galvanized Carbon Steel Pipe
Spiral Welded Steel Pipe Stkm11a Pipe
Large Diameter Carbon Steel Pipe Low Carbon Steel Tube
Coated Carbon Steel Pipe Carbon Steel Boiler Tubes
Carbon Steel Boiler Tube Carbon Steel Tube
ASTM A524 black carbon steel pipe
Cs Seamless Pipe FBE Lined carbon steel pipe
Schedule 40 Carbon Steel Pipe PTFE Lined carbon steel pipe
Carbon Steel Black Pipe Carbon Steel Pipe

Searching for

Carbon Steel Pipe supplier in your country? Checklist of material we export in the following areas.

Application Projects
P.M. Metal Logo

Carbon Steel Seamless Pipe

Bangladesh, Jakarta -Indonesia, Dubai, Los Alamos -Mexico, Hong Kong, Turkey, Argentina, Germany, China, Oman, Saudi Arabia (KSA).

Application Projects
P.M. Metal Logo

Carbon Steel Pipe

Malaysia, Poland, Romania, Indonesia, Malaysia, Iran, Qatar, New Zealand, Brazil, Netherlands, United Arab Emirates (UAE).

Application Projects
P.M. Metal Logo

SCH 40 Carbon Steel Pipe

USA, Chile, Ellington -United States, Canada, Sweden, United States, Greece, Singapore, Vietnam, Mexico, Denmark, Thailand, Finland.

Application Projects
P.M. Metal Logo

Coated Carbon Steel Pipe

Russia, Belgium, Norway, Egypt, Bahrain, Philippines, South Korea, Peru, Malaysia, Tehran -Iran, Colombia, Italy.

Application Projects
P.M. Metal Logo

Carbon Steel Tubes

Spain, Jakarta, Europe, Australia, Jordan, Dammam -KSA, Japan, Istanbul -Turkey, NY 12203 (USA), Dubai -UAE, Kuala Lumpur.

Application Projects
P.M. Metal Logo

Carbon Steel Boiler Tubes

France, Singapore, Taiwan, South Africa, Portugal, Morocco, Czechia, Kuwait, Austria, United Kingdom (UK), Nigeria.
