What Is The Melting Point Of 310 Stainless Steel
A stainless steel 310 pipe is an austenitic grade that is designed with a melting point of 1454 degrees C.
What Is 310 Stainless Steel Pipe And Tube
Stainless steel 310 pipes and tubes are important features of this grade. Both these piping modules are designed with a superior content of chromium and nickel, giving these items superior corrosion and oxidation resistance. The piping grade shows enhanced resistance to temperatures up to 1150 degrees C. The hardened components can also be employed in applications where the temperatures goes as low as -450 degrees F. They can be employed to transport fluids and gases across carburizing sulfur-induced atmospheres. The items in this grade are not recommended for frequent liquid quenching as it is susceptible to thermal shocks.
Difference between Stainless Steel 310 Seamless Pipe vs 310 Welded Pipes
Seamless and welded pipe configurations are two grades that are utilized in the stainless steel 310 grade. Both these types of modules can be differentiated based on certain features.
Difference between ASTM A312 Tp310 And ASME Sa312 Tp310
ASTM and ASME are two major grades that are utilized in manufacturing different piping modules in the SS 310 grades. Both these product ranges are very identical; however, they have key differences that separate them.
Grades | Stainless Steel 310 Pipe/ Tube |
---|---|
Thickness | Schedule 5, Schedule 10, Schedule 40, Schedule 80, Schedule 80S, Schedule 160, Schedule XXS, Schedule XS |
Specifications | ASTM A312 / ASME SA312 |
Outer Diameter | Sizes up to 24” NB and 6.00 mm OD up to 914.4 mm OD |
Size | 1/8″NB to 30″NB IN |
Type | “U” Shape, Round Pipes, Hollow Pipes, Pan Cake Coils |
ERW Pipes Size | 1/2" NB to 24" NB |
Length | Required Length, Single Random, and Double Random |
EFW Pipes Size | 6" NB to 100" NB |
End | Beveled End, Plain End, Treaded |
Grade | S | C | Cr | Mn | Fe | Si | Ni | P | Mo |
---|---|---|---|---|---|---|---|---|---|
SS 310 | 0.015 max | 0.015 max | 24.00 - 26.00 | 2.0 max | 54.7 min | 0.15 max | 19.00 - 21.00 | 0.020 max | 0.10 max |
Tensile Strength | Density | Yield Strength (0.2%Offset) | Melting Point | Elongation |
---|---|---|---|---|
Psi – 75000 , MPa – 515 | 7.9 g/cm3 | Psi – 30000 , MPa – 205 | 1402 °C (2555 °F) | 40 % |
STANDARD | BS | WERKSTOFF NR. | AFNOR | UNS | EN | JIS | GOST |
---|---|---|---|---|---|---|---|
SS 310 Tube | 310S24 | 1.4841 | - | S31000 | X15CrNi25-20 | SUS 310 | 20Ch25N20S2 |
Grade | Specific Heat 0-1000C (J/kg.K) | Density (kg/m3) | Thermal Conductivity (W/m.K) | Mean Coefficient of Thermal Expansion (m/m/0C) | Elastic Modulus (GPa) | Electrical Resistivity (n.m) | |||
---|---|---|---|---|---|---|---|---|---|
at 100°C | at 500°C | 0-315°C | 0-100°C | 0-538°C | |||||
310 | 500 | 7750 | 14.2 | 18.7 | 16.2 | 15.9 | 17.0 | 200 | 720 |
1% Elongation1) for | Rupture2) for | ||||
---|---|---|---|---|---|
Temperature °C | 1,000 h N/mm2 | 10,000 h N/mm2 | 10,000 h N/mm2 | 100,000 h N/mm2 | 1,000 h N/mm2 |
800 | 18 | 18 | 10 | 7 | 35 |
600 | 100 | 130 | 90 | 80 | 170 |
900 | 10 | 8.5 | 4 | 3 | 15 |
700 | 45 | 40 | 30 | 18 | 80 |
Pipe Size (inches) |
Pipe Schedule | Temperature (°F) | ||||||||
---|---|---|---|---|---|---|---|---|---|---|
100 | 200 | 300 | 400 | 500 | 600 | 650 | 700 | 750 | ||
4" | 80 | 2213 | 1909 | 1715 | 1577 | 1466 | 1397 | 1355 | 1328 | 1314 |
1" | 40 | 3048 | 2629 | 2362 | 2171 | 2019 | 1924 | 1867 | 1824 | 1810 |
5" | 40 | 1342 | 1158 | 1040 | 956 | 889 | 847 | 822 | 805 | 797 |
1" | 80 | 4213 | 3634 | 3265 | 3002 | 2791 | 2659 | 2580 | 2528 | 2501 |
8" | 40 | 1073 | 926 | 832 | 765 | 711 | 678 | 657 | 644 | 637 |
1" | 160 | 6140 | 5296 | 4759 | 4375 | 4068 | 3876 | 3761 | 3684 | 3646 |
4" | 40 | 1531 | 1321 | 1187 | 1091 | 1014 | 967 | 938 | 919 | 909 |
1.5" | 40 | 2257 | 1947 | 1750 | 1608 | 1496 | 1425 | 1383 | 1354 | 1340 |
5" | 80 | 1981 | 1709 | 1535 | 1411 | 1312 | 1250 | 1213 | 1189 | 1176 |
1.5" | 80 | 3182 | 2744 | 2466 | 2267 | 2108 | 2009 | 1949 | 1909 | 1889 |
4" | 160 | 3601 | 3106 | 2791 | 2566 | 2386 | 2273 | 2206 | 2161 | 2138 |
1.5" | 160 | 4619 | 3984 | 3580 | 3291 | 3060 | 2916 | 2829 | 2772 | 2743 |
6" | 80 | 1913 | 1650 | 1483 | 1363 | 1267 | 1208 | 1172 | 1148 | 1136 |
2" | 40 | 1902 | 1640 | 1474 | 1355 | 1260 | 1201 | 1165 | 1141 | 1129 |
8" | 160 | 3175 | 2738 | 2460 | 2262 | 2103 | 2004 | 1944 | 1905 | 1885 |
2" | 80 | 2747 | 2369 | 2129 | 1957 | 1820 | 1734 | 1682 | 1648 | 1631 |
8" | 80 | 1692 | 1459 | 1311 | 1205 | 1121 | 1068 | 1036 | 1015 | 1005 |
2" | 160 | 4499 | 3880 | 3486 | 3205 | 2980 | 2840 | 2755 | 2699 | 2671 |
10" | 40 | 974 | 840 | 755 | 694 | 945 | 615 | 596 | 584 | 578 |
3" | 40 | 1806 | 1558 | 1400 | 1287 | 1196 | 1140 | 1106 | 1084 | 1072 |
10" | 80 | 1609 | 1388 | 1247 | 1147 | 1066 | 1016 | 986 | 966 | 956 |
3" | 80 | 2553 | 2202 | 1979 | 1819 | 1691 | 1612 | 1564 | 1532 | 1516 |
3" | 160 | 3840 | 3312 | 2976 | 2736 | 2544 | 2424 | 2352 | 2304 | 2280 |
5" | 160 | 3414 | 2945 | 2646 | 2433 | 2262 | 2155 | 2091 | 2049 | 2027 |
6" | 160 | 3289 | 2836 | 2549 | 2343 | 2179 | 2076 | 2014 | 1973 | 1953 |
6" | 40 | 1219 | 1052 | 945 | 869 | 808 | 770 | 747 | 732 | 724 |
10" | 160 | 3147 | 2714 | 2439 | 2242 | 2085 | 1986 | 1927 | 1880 | 1868 |
Stainless Steel 310 seamless tube
Melting Point (Deg F): 2650
Nominal size [inches] | Wall thickness [inches] | Wall thickness [mm] | Outside diameter [inches] | Outside diameter [mm] | Weight [lb/ft] | Weight [kg/m] |
1/8 | 0.095 | 2.41 | 0.405 | 10.3 | 0.31 | 0.47 |
1/4 | 0.119 | 3.02 | 0.54 | 13.7 | 0.54 | 0.8 |
1/2 | 0.147 | 3.73 | 0.84 | 21.3 | 1.09 | 1.62 |
3/4 | 0.154 | 3.91 | 1.05 | 26.7 | 1.47 | 2.2 |
1 | 0.179 | 4.55 | 1.315 | 33.4 | 2.17 | 3.24 |
1 1/4 | 0.191 | 4.85 | 1.66 | 42.2 | 3 | 4.47 |
1 1/2 | 0.2 | 5.08 | 1.9 | 48.3 | 3.63 | 5.41 |
2 | 0.218 | 5.54 | 2.375 | 60.3 | 5.02 | 7.48 |
2 1/2 | 0.276 | 7.01 | 2.875 | 73 | 7.66 | 11.41 |
3 | 0.3 | 7.62 | 3.5 | 88.9 | 10.25 | 15.27 |
3 1/2 | 0.318 | 8.08 | 4 | 101.6 | 12.5 | 18.63 |
4 | 0.337 | 8.56 | 4.5 | 114.3 | 14.98 | 22.32 |
5 | 0.375 | 9.53 | 5.563 | 141.3 | 20.78 | 30.97 |
6 | 0.432 | 10.97 | 6.625 | 168.3 | 28.57 | 42.56 |
8 | 0.5 | 12.7 | 8.625 | 219.1 | 43.39 | 64.64 |
10 | 0.594 | 15.09 | 10.75 | 273 | 64.43 | 96.01 |
12 | 0.688 | 17.48 | 12.75 | 323.8 | 88.63 | 132.08 |
14 | 0.75 | 19.05 | 14 | 355.6 | 106.13 | 158.1 |
16 | 0.844 | 21.44 | 16 | 406.4 | 136.61 | 203.53 |
18 | 0.938 | 23.83 | 18 | 457 | 170.92 | 254.55 |
20 | 1.031 | 26.19 | 20 | 508 | 208.87 | 311.17 |
24 | 1.125 | 30.96 | 24 | 610 | 296.58 | 442.08 |
OD mm |
Sch | WT mm |
Kg/m | in. |
---|---|---|---|---|
13.72 | 10S | 1.65 | 0.50 | 1/4 |
13.72 | 40S | 2.24 | 0.64 | 1/4 |
13.72 | 80S | 3.02 | 0.81 | 1/4 |
17.15 | 10S | 1.65 | 0.64 | 3/8 |
17.15 | 40S | 2.31 | 0.86 | 3/8 |
17.15 | 80S | 3.20 | 1.12 | 3/8 |
21.34 | 10S | 2.11 | 1.02 | 1/2 |
21.34 | 40S | 2.77 | 1.29 | 1/2 |
21.34 | 80S | 3.73 | 1.65 | 1/2 |
26.67 | 10S | 2.11 | 1.30 | 3/4 |
26.67 | 40S | 2.87 | 1.71 | 3/4 |
26.67 | 80S | 3.91 | 2.23 | 3/4 |
33.40 | 10S | 2.77 | 2.13 | 1 |
33.40 | 40S | 3.38 | 2.54 | 1 |
33.40 | 80S | 4.55 | 3.29 | 1 |
33.40 | 160 | 6.352) | 4.30 | 1 |
42.16 | 10S | 2.77 | 2.73 | 1¼ |
42.16 | 40S | 3.56 | 3.44 | 1¼ |
42.16 | 80S | 4.85 | 4.53 | 1¼ |
42.16 | 160 | 6.352) | 5.69 | 1¼ |
48.26 | 10S | 2.77 | 3.16 | 1½ |
48.26 | 40S | 3.68 | 4.11 | 1½ |
48.26 | 80S | 5.08 | 5.49 | 1½ |
60.33 | 10S | 2.77 | 3.99 | 2 |
60.33 | 40S | 3.91 | 5.52 | 2 |
60.33 | 80S | 5.54 | 7.60 | 2 |
60.33 | 160 | 8.742) | 11.29 | 2 |
73.03 | 10S | 3.05 | 5.35 | 2½ |
73.03 | 40S | 5.16 | 8.77 | 2½ |
73.03 | 80S | 7.01 | 11.59 | 2½ |
88.90 | 10S | 3.05 | 6.56 | 3 |
88.90 | 40S | 5.49 | 11.47 | 3 |
88.90 | 80S | 7.62 | 15.51 | 3 |
88.90 | 160 | 11.132) | 21.67 | 3 |
101.60 | 10S | 3.05 | 7.53 | 3½ |
101.60 | 40S | 5.74 | 13.78 | 3½ |
101.60 | 80S | 8.08 | 18.92 | 3½ |
114.30 | 10S | 3.05 | 8.50 | 4 |
114.30 | 40S | 6.02 | 16.32 | 4 |
114.30 | 80S | 8.56 | 22.67 | 4 |
114.30 | 160 | 13.492) | 34.05 | 4 |
141.30 | 40S | 6.55 | 22.10 | 5 |
141.30 | 80S | 9.53 | 31.44 | 5 |
141.30 | 160 | 15.882) | 49.87 | 5 |
168.28 | 10S | 3.4 | 14.04 | 6 |
168.28 | 40S | 7.11 | 28.69 | 6 |
168.28 | 80S | 10.97 | 43.21 | 6 |
168.28 | 120 | 14.27 | 54.75 | 6 |
168.28 | 160 | 18.262) | 68.59 | 6 |
219.08 | 40S | 8.18 | 43.20 | 8 |
219.08 | 80S | 12.7 | 65.63 | 8 |
219.08 | 120 | 18.23 | 91.30 | 8 |
219.08 | 160 | 23.012) | 112.97 | 8 |
Wall Thickness | Stainless Steel 310 Tube Sizes ( O.D.) |
---|---|
.010 | 1/16" , 1/8" , 3/16" |
.020 | 1/16" , 1/8" , 3/16" , 1/4" , 5/16" , 3/8" |
.012 | 1/8" |
.016 | 1/8" , 3/16" |
.028 | 1/8" , 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 3/4" , 1" , 1 1/2" , 2" |
.035 | 1/8" , 3/16" , 1/4" , 5/16" , 3/8" , 7/16" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4" |
.049 | 3/16" , 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/8" , 1 1/4" , 1 1/2" , 1 5/8" , 2" , 2 1/4" |
.065 | 1/4" , 5/16" , 3/8" , 1/2" , 16" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 3/4" , 2" , 2 1/2" , 3" |
.083 | 1/4" , 3/8" , 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 1 5/8" , 1 7/8" , 2" , 2 1/2" ,3" |
.095 | 1/2" , 5/8" , 1" , 1 1/4" , 1 1/2" , 2" |
.109 | 1/2" , 3/4" , 1" , 1 1/4" , 1 1/2" , 2" |
.120 | 1/2" , 5/8" , 3/4" , 7/8" , 1" , 1 1/4" , 1 1/2" , 2" , 2 1/4" , 2 1/2" , 3" |
.125 | 3/4" , 1" , 1 1/4" , 1 1/2" , 2" , 3" , 3 1/4" |
.134 | 1" |
.250 | 3" |
.375 | 3 1/2" |
200°C | 15.5 |
400°C | 17.0 |
600°C | 17.5 |
800°C | 18.5 |
1000°C | 19.0 |
1/8" IPS(.405"O. D.) | 3 1/2" IPS( 4.000"O. D.) |
---|---|
SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
1/4" IPS(.540"O. D.) | 4" IPS(4.500"O. D.) |
SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
3/8" IPS(.675"O. D.) | 5" IPS( 5.563"O. D.) |
SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
1/2" IPS(.840"O. D.) | 6" IPS(6.625"O. D.) |
SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
3/4" IPS(1.050"O. D.) | 8 ” IPS(8.625"O. D.) |
SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
1" IPS:(1.315′O. D.) | 10" IPS(10.750"O. D.) |
SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
1-1/4" IPS(1.660"O. D.) | 12" IPS(12.750"O. D.) |
SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
1-1/2" IPS(1.900"O. D.) | 14" IPS(14.000"O. D.) |
SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
2" IPS(2.375"O. D.) | 16" IPS(16.000"O. D.) |
SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
2 1/2" IPS(2.875"O. D.) | 18" IPS (18.000"O. D.) |
SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
3" IPS( 3.500"O. D.) | |
SCH 5, 10, 40, 80, 160, XXH |
Pipes O.D. (in.) |
Wall Thickness of Pipes/Tubes (inches) | |||||||
---|---|---|---|---|---|---|---|---|
.028 | .035 | .049 | .065 | .083 | .095 | .109 | .120 | |
Working Pressure (psig) | ||||||||
3/8 | 3100 | 4400 | 6100 | |||||
1/8 | 7900 | 10100 | ||||||
3/4 | 2200 | 3000 | 4000 | 4600 | ||||
1/4 | 3700 | 4800 | 7000 | 9500 | ||||
1 | 2200 | 2900 | 3400 | 3900 | 4300 | |||
5/16 | 3700 | 5400 | 7300 | |||||
1/2 | 2300 | 3200 | 4400 |
Pipes OD | Wall Thickness (Inches) | |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
.010 | .012 | .016 | .020 | .028 | .035 | .049 | .065 | .083 | .095 | .109 | .120 | |
3/8 | 3,530 | 5,107 | 7,029 | |||||||||
1/16 | 6,422 | 7,872 | 10,768 | 13,484 | ||||||||
1/2 | 2,595 | 3,721 | 5,078 | 6,699 | ||||||||
1/8 | 6,422 | 9,325 | 11,823 | |||||||||
5/8 | 2,051 | 2,927 | 3,970 | 5,200 | 6,056 | |||||||
3/16 | 4,081 | 5,935 | 7,630 | 11,005 | ||||||||
7/8 | 1,446 | 2,051 | 2,764 | 3,592 | 4,161 | 4,842 | 5,391 | |||||
1/4 | 4,305 | 5,518 | 8,053 | 10,946 | ||||||||
1 | 5,040 | 7,140 | 9,595 | 12,445 | 14,390 | 16,715 | 18,585 | |||||
3/4 | 1,696 | 2,412 | 3,259 | 4,249 | 4,933 | 5,755 | 6,422 |
Pipes OD | Wall Thickness (Inches) | ||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
0.5 | 0.6 | 0.7 | 0.8 | 1.0 | 1.2 | 1.5 | 1.6 | 1.8 | 2.0 | 2.2 | 2.5 | 3.0 | |
12 | 169 | 215 | 262 | 335 | 360 | 411 | 464 | ||||||
3 | 464 | 567 | 672 | 775 | 965 | ||||||||
14 | 182 | 222 | 282 | 303 | 345 | 389 | 433 | 500 | 612 | ||||
4 | 335 | 411 | 491 | 567 | 723 | 873 | |||||||
16 | 158 | 192 | 244 | 262 | 298 | 335 | 372 | 430 | 528 | ||||
6 | 310 | 360 | 464 | 567 | 723 | 775 | |||||||
18 | 140 | 169 | 215 | 230 | 262 | 294 | 326 | 377 | 464 | ||||
8 | 227 | 262 | 335 | 411 | 528 | 567 | |||||||
22 | 113 | 137 | 173 | 186 | 211 | 236 | 262 | 301 | 369 | ||||
10 | 206 | 262 | 320 | 411 | 442 | ||||||||
25 | 99 | 120 | 152 | 162 | 184 | 206 | 228 | 262 | 320 |
Price of Grade 310 Stainless Steel Pipes | Available Sizes in Stock | Price Stainless Steel 310 Pipe Suppliers in India (INR) | ASTM A312 TP 310 Pipe Price in USD | UNS S31000 SS Pipe Price in UAE Dirham |
---|---|---|---|---|
SEAMLESS STAINLESS STEEL PIPES (HOT FINISHED) GRADE TP310 | 4.00 X 1500M X C | INR: 240 | US $: 3.20 | UAE Dirham : 11.76 |
STAINLESS STEEL SEAMLESS PIPES (HOT FINISHED) AS PER ASTM A312 GRADE TP310 | 3MM X 230MM/245MM | INR: 223 | US $: 2.98 | UAE Dirham : 10.93 |
STAINLESS STEEL SEAMLESS DEFECTIVE PIPES GRADE 310 | 101.60 X 4.00, LENGTH (M) 5.8-6.2 | INR: 329 | US $: 4.39 | UAE Dirham : 16.13 |
STAINLESS STEEL SEAMLESS PIPES ASTM A312 TP310 | 33.7MM OD X 3.1MM WT X 6M LENGTH | INR: 328 | US $: 4.38 | UAE Dirham : 16.08 |
Stainless Steel 310 Pipes | Grade Stainless Steel 310 Pipes |
SS 310 Seamless Pipes | SS 310 Welded Pipes |
Stainless Steel 310 Tube | SS 310 Round Pipes |
Grade 310 Stainless Steel Pipes | Stainless Steel AISI 310 ERW Pipes |
310 Stainless Steel Pipes | ASTM A312 Gr TP 310 Welded Pipes |
310 SS Tubing | SA 312 TP 310 ERW Pipes |
ASTM A312 TP 310 Seamless Pipes | A312 TP 310 Round Pipes |
ASME SA 312 Grade 310 Welded Pipes | 310 Stainless Steel CDW Pipes |
UNS S31000 ERW Pipes | GOST 20Ch25N20S2 SS Hollow Pipes |
WNR. 1.4841 Round Pipes | Capillary 310 Stainless Steel Thin Pipes |
SA 312 TP 310 Schedule 40 Pipes | SS 310 Pipes |
ASTM A312 Gr TP 310 Hollow Pipes | Stainless Steel 310 Seamless Pipes |
AISI 310 Schedule 40 Pipes | Stainless Steel UNS S31000 Square Pipes |
SS grade 1.4841 Pipes | SS UNS S31000 Bush Hex Pipes |
1.4841 SS 310 Polished Pipess | ASTM A249 TP 310 Stainless Steel Hexagonal Pipes |
ASTM A312 TP 310 Pipes | Stainless Steel 310 Welded Pipes |
Stainless Steel 310 Seamless Pipes | TP310 Stainless Steel Hollow Pipes |
Stainless Steel 310 Tube | Stainless Steel 310 EFW Pipes |
310 Stainless Pipe | Aisi 310 Pipe |
Searching for
Stainless Steel Welded Pipe supplier in your country? Checklist of material we export in the following areas.
Bangladesh, Jakarta -Indonesia, Dubai, Los Alamos -Mexico, Hong Kong, Turkey, Argentina, Germany, China, Oman, Saudi Arabia (KSA).
Malaysia, Poland, Romania, Indonesia, Malaysia, Iran, Qatar, New Zealand, Brazil, Netherlands, United Arab Emirates (UAE).
USA, Chile, Ellington -United States, Canada, Sweden, United States, Greece, Singapore, Vietnam, Mexico, Denmark, Thailand, Finland.
Russia, Belgium, Norway, Egypt, Bahrain, Philippines, South Korea, Peru, Malaysia, Tehran -Iran, Colombia, Italy.
Spain, Jakarta, Europe, Australia, Jordan, Dammam -KSA, Japan, Istanbul -Turkey, NY 12203 (USA), Dubai -UAE, Kuala Lumpur.
France, Singapore, Taiwan, South Africa, Portugal, Morocco, Czechia, Kuwait, Austria, United Kingdom (UK), Nigeria.
