What Is Carbon Steel Flanges?
Carbon steel flanges are high carbon grade items designed to seal different piping equipment efficiently. Carbon in these flanges can be alloyed with other alloys to enhance or get the desired quality flange. The flanges can be low, medium, high, or ultra-high concentration grade. The higher the content of carbon embedded in the flanges the greater is the strength of the module. The low carbon flanges can be readily welded in place following standard welding procedures.

Carbon Steel Slip On Flanges Vs Weld Neck Flange
Slip on and weld neck flanges are two of the common flange type in the piping industry. Both these types of flanges can be distinguished on certain aspects in the carbon grade.

  • Carbon steel slip on flanges are utilized in low-pressure systems, while weld neck flanges are used in high-pressure applications.
  • Slip on flanges have a low-profile head. Weld neck flanges are designed with a long protruding hub.
  • Carbon grade slip on flanges can be welded with one or more fillet welds. WNFR flanges in the carbon range are welded using a butt-weld.

Forged Carbon Steel Flanges Vs Lap Joint Flange

  • Forged carbon steel flanges are produced by forging steel at extreme temperatures. The forged process can be used to manufacture different types of flanges.
  • Carbon steel lap joint flanges follow a two-component assembly and are either cast or forged. These flanges can be welded following a butt-weld procedure.

Functions Of The Carbon Steel Threaded Flange
Carbon steel threaded flanges are versatile modules that have threads that align themselves to the pipe modules. These flanges are commonly a feature in low-pressure applications and are widely seen in

  • Chemical processing
  • Potable water systems
  • Pipes, valves
  • Construction
  • Manufacturing industry
  • Oil and gas
  • Petrochemical sector

Advantages Of Carbon Steel Socket Weld Flange
Carbon steel socket weld flange is a pipe attachment detail allowing it to be inserted in a flange. These flanges reduce the risk of leakage, and the welded flange doesn’t require to be beveled before welding. Apart from this, the construction costs of these flanges are lower than other flange types.

Check Normalized Carbon Steel Weld Neck Flanges in Raised, RTJ and Flat Face, Get Carbon Flange and Reducing flange dimensions as per ANSI B16.47 Series A, ASME B16.5, EN 1092-2/ EN 1092-1

Carbon Steel Flange Material Specification

Carbon Steel Pipe Flange Specifications ASTM A105 / ASME SA105, A105N
Available Sizes 1/2 To 48 Inch
UNI Standard 6, 40, 16, 25, 10 Bar
ANSI Standard Class 150 to Class 2500 LBS
EN Standard 6, 40, 16, 25, 10 Bar
Equipment used Pushing Machine, Sand-blasting machine, Press machine, Bending machine, electric bevelling machine
Technique Heat treated
machined
Forged
JIS Standard 10, 30, 40, 20, 5, 16, 63 K
DIN Standard 16, 40, 10, 6, 25 Bar / PN64, PN10, PN16, PN6, PN25, PN40
Main Types of Carbon Steel Flanges Suppliers Forged / Screwed / Plate/ Threaded
Flange supporting material Ring Joint
Gasket
Flange Bolts
Test Magnetic particle detector
UI trasonic flaw detector
X ray detector
Direct reading Spectrograph
Hydrostatic testing machine
Standards of Carbon Steel Flange Manufacturer ASME B16.5, DIN, ANSI Flanges, B16.47 Series A and B, B16.48, BS 10, EN 1092, ASME Flanges, BS Flanges, BS4504, EN Flanges, GOST Flanges, DIN Flanges
Flange Face Type Large Tongue and Groove, Lap Joint Face, Large Male Female, Flat Face, Small Tongue, Raised Face, Small Male Female, Ring Joint Flange Manufacturer and Supplier
Flanges Marking All Flange are marked as follows: Supplier or Manufacturer’s Name, Class, Dimension, Size, Bore, Material, Heat No. (Or according to the customer’s request)

Carbon Steel Flanges Price List

Product Types Pipe Size Maximum Operating Pressure Temp. Range Price
FLANGES CARBON STEEL : SW RF, 300#, CL1 XS, GR.SA/A350 LF2 Threaded Flange 2-1/2 in 285 psi -20° to 100° F $73.07
3 in 285 psi $73.58
3-1/2 in 285 psi $85.51
6 in 285 psi $147.69
8 in 285 psi $252.87
FLANGE,FORGED CARBON STEEL,RTJ,5000 PSI,THREAD:API LP,DIM:API 6A,TYPE-6B2,MATERIAL:API 6B,TYPE II,SCOPE OF INSPECTION B, Blind Flange 2 in 285 psi $45.23
2-1/2 in 285 psi $72.02
3 in 285 psi $60.63
4 in 285 psi $84.47
8 in 285 psi $211.42
FLANGES FLANGE,FORGED CARBON STEEL,RTJ,5000 PSI,THREAD:API LP,DIM:API 6A,TYPE-6B2,MATERIAL:API 6B,TYPE-II.SCOPE OF INSPE Slip-On Flange 2-1/2 in 285 psi $67.37
3 in 285 psi $50.97
3-1/2 in 285 psi $66.85
6 in 285 psi $109.33
8 in 285 psi $166.85
7800009380-1 WN SWIVEL 1500 8RTJ 12.7 WT A694 F60+CLAD 6625CARBON STEEL FLANGES Socket Weld Flange 2-1/2 in 285 psi $68.92
3 in 285 psi $65.81
4 in 285 psi $84.98
6 in 285 psi $138.87
8 in 285 psi $195.52
PROOF MACHINED CARBON STEEL (BLRTJ) FLANGE CONF. TO SPECN. SA105 SIZE(MM): 150 X 0.00 X 37.95 Weld Neck Flange 1/2 in 285 psi - $49.41
2-1/2 in 285 psi - $64.25
3 in 285 psi - $73.07
3-1/2 in 285 psi - $84.98
8 in 285 psi - $228.00
CARBON STEEL FORGED FLANGES-SEMIFINISHED(PIPE FITTINGS OF IRON &STEEL)SIZE:24-900-WN-RF-1.125 WT-SC-B16.5-DRILLED-F65 Lap Joint Flange 1/2 in 740 psi - $49.14
4 in 740 psi - $134.20
5 in 740 psi - $223.86
6 in 740 psi - $240.43
8 in 740 psi - $402.11

Various CS Flange Types

Carbon Steel Weld Neck Flanges
Carbon Steel Weld Neck Flanges
Carbon Steel Weld Neck Flanges
CS WNRF Flange
CS WNRF Flange
CS WNRF Flange
Carbon Socket Weld Flange
Carbon Socket Weld Flange
Carbon Socket Weld Flange
Mild Steel SWRF Flanges
Mild Steel SWRF Flanges
Mild Steel SWRF Flanges
Carbon Slip On Flange
Carbon Slip On Flange
Carbon Slip On Flange
Killed Carbon Steel SORF Flanges
Killed Carbon Steel SORF Flanges
Killed Carbon Steel SORF Flanges
Carbon Steel Blind Flange
Carbon Steel Blind Flange
Carbon Steel Blind Flange
CS BLRF Flanges
CS BLRF Flanges
CS BLRF Flanges
Carbon Steel Lapped Joint Flange
Carbon Steel Lapped Joint Flange
Carbon Steel Lapped Joint Flange
Steel Orifice Flanges
Steel Orifice Flanges
Steel Orifice Flanges
Ansi Steel Spectacle Blind Flange
Ansi Steel Spectacle Blind Flange
Ansi Steel Spectacle Blind Flange
CS Tongue & Groove Flange
CS Tongue & Groove Flange
CS Tongue & Groove Flange
Carbon Steel Nipo Flanges
Carbon Steel Nipo Flanges
Carbon Steel Nipo Flanges
Low Temp Carbon Steel Long Weld Neck Flange
Low Temp Carbon Steel Long Weld Neck Flange
Low Temp Carbon Steel Long Weld Neck Flange
CS Reducing Flanges
CS Reducing Flanges
CS Reducing Flanges
Normalized Carbon Steel Ring Joint Flange
Normalized Carbon Steel Ring Joint Flange
Normalized Carbon Steel Ring Joint Flange
Carbon Girth Flanges
Carbon Girth Flanges
Carbon Girth Flanges
Low Temperature Carbon Steel Expander Flanges
Low Temperature Carbon Steel Expander Flanges
Low Temperature Carbon Steel Expander Flanges
Carbon Steel Screwed Flange
Carbon Steel Screwed Flange
Carbon Steel Screwed Flange
CS Threaded Flange
CS Threaded Flange
CS Threaded Flange

CS Slip On Flange Dimensions

Normal Pipe Size Of Flanges Outside Daimeter Inside Diameter Hole Of Bolt Circle Of Bolt Thickness Of Raised Face Raised Face Thickness Of Flat Face Raised Face H T1 Number of Bolt Holes
3/4 3.88 1.09 .62 2.75 .62 1.69 .56 .063 1.50 .44 4
3-1/2 8.50 4.07 .75 7.00 1.25 5.50 1.19 .063 4.81 .88 8
22 29.50 22.22 1.38 27.25 3.13 25.25 3.07 .063 24.25 1.75 20
1 4.25 1.36 .62 3.12 .69 2.00 .63 .063 1.94 .50 4
1-1/4 4.62 1.70 .62 3.50 .81 2.50 .75 .063 2.31 .56 4
1-1/2 5.00 1.97 .62 3.88 .88 2.88 .82 .063 2.56 .62 4
20 27.50 20.20 1.25 25.00 2.88 23.00 2.83 .063 22.00 1.63 20
1/2 3.50 0.88 .62 2.38 .62 1.38 .56 .063 1.19 .38 4
2 6.00 2.44 .75 4.75 1.00 3.62 .94 .063 3.06 .69 4
2-1/2 7.00 2.94 .75 5.50 1.12 4.12 1.06 .063 3.56 .82 4
18 25.00 18.18 1.25 22.75 2.69 21.00 2.63 .063 19.88 1.50 16
14 21.00 14.14 1.12 18.75 2.25 16.25 2.19 .063 15.75 1.32 12
3 7.50 3.57 .75 6.00 1.19 5.00 1.13 .063 4.25 .88 4
16 23.50 16.16 1.12 21.25 2.50 18.50 2.44 .063 18.00 1.38 16
4 9.00 4.57 .75 7.50 1.31 6.19 1.25 .063 5.31 .88 8
6 11.00 6.72 .88 9.50 1.56 8.50 1.50 .063 7.56 .94 8
8 13.50 8.72 .88 11.75 1.75 10.62 1.69 .063 9.69 1.06 8
5 10.00 5.66 .88 8.50 1.44 7.31 1.38 .063 6.44 .88 8
10 16.00 10.88 1.00 14.25 1.94 12.75 1.88 .063 12.00 1.13 12
12 19.00 12.88 1.00 17.00 2.19 15.00 2.13 .063 14.38 1.19 12
24 32.00 24.25 1.38 29.50 3.25 27.25 3.19 .063 26.12 1.82 20

Carbon Steel Blind Flange Dimensions

ASTM A105 Blind Flange Dimensions

Holes ø l D k b Kg. g
4 1/2" 15,9 88,9 60,3 11,1 0,400 34,9
4 3/4" 15,9 98,4 69,8 12,7 0,700 42,9
4 1" 15,9 107,9 79,4 14,3 0,900 50,8
4 1 1/4" 15,9 117,5 88,9 15,9 1,300 63,5
4 1 1/2" 15,9 127,0 98,4 17,5 1,600 73,0
4 2" 19,0 152,4 120,6 19,0 2,600 92,1
4 2 1/2" 19,0 177,8 139,4 22,2 4,100 104,8
4 3" 19,0 190,5 152,4 23,8 5,000 127,0
8 3 1/2" 19,0 215,9 177,8 23,8 6,400 139,7
8 4" 19,0 228,6 190,5 23,8 7,100 157,2
8 5" 22,2 254,0 215,9 23,8 9,000 185,7
8 6" 22,2 279,4 241,3 25,4 11,800 215,9
8 8" 22,2 342,9 298,4 28,6 21,000 269,9
12 10" 25,4 406,4 361,9 30,2 30,000 323,4
12 12" 25,4 482,6 431,8 31,7 45,000 381,0
12 14" 28,6 533,4 476,2 34,9 59,000 412,7
16 16" 28,6 596,9 539,9 36,5 79,000 469,9
16 18" 31,7 635,0 577,8 39,7 97,000 533,4
20 20" 31,7 698,5 635,0 42,9 124,000 584,2
20 22" 34,9 749,3 692,1 46,0 151,000 641,2
20 24" 34,9 812,8 749,3 47,6 188,000 692,1

CS Blind Flange Size Chart

Nominal Size Outside Diameter Bolt Circle Bore Diameter Hub Diameter Number of Bolt Holes Lap Radius Bolt Hole Diameter. Thickness Hub Length Approx. Weight
1 1/4 4.68 3.50 1.72 2.312 4 0.19 0.625 0.625 0.813 3
14 21.00 18.75 14.19 15.750 12 0.50 1.125 1.375 2.250 90
3 1/2 8.50 7.00 4.10 4.812 8 0.38 0.750 0.938 1.250 11
36** 46.00 42.75 36.25 39.250 32 0.50 1.625 2.375 3.750 440
6 11.00 9.50 6.75 7.562 8 0.50 0.875 1.000 1.562 18
1 1/2 5.00 3.88 1.97 2.563 4 0.25 0.625 0.688 0.875 3
30** 38.75 36.00 30.25 32.750 28 0.50 1.375 2.125 3.500 305
2 6.00 4.75 2.46 3.063 4 0.31 0.750 0.750 1.000 5
1 4.25 3.13 1.38 1.938 4 0.13 0.625 0.563 0.688 2
12 19.00 17.00 12.92 14.375 12 0.50 1.000 1.250 2.188 64
4 9.00 7.50 4.60 5.312 8 0.44 0.750 0.938 1.312 13
2 1/2 7.00 5.50 2.97 3.563 4 0.31 0.750 0.875 1.125 7
3 7.50 6.00 3.60 4.250 4 0.38 0.750 0.938 1.188 8
24 32.00 29.50 24.25 26.125 20 0.50 1.375 1.875 3.250 212
5 10.00 8.50 5.69 6.438 8 0.44 0.875 0.938 1.438 15
8 13.50 11.75 8.75 9.688 8 0.50 0.875 1.125 1.750 30
10 16.00 14.25 10.92 12.000 12 0.50 1.000 1.188 1.938 42
16 23.50 21.25 16.19 18.000 16 0.50 1.125 1.438 2.500 98
18 25.00 22.75 18.20 19.875 16 0.50 1.250 1.562 2.688 125
20 27.50 25.00 20.25 22.000 20 0.50 1.250 1.688 2.875 160

150# Carbon Steel Flange Dimensions

Nominal Pipe sizes in Inches Diameter of Flange in inches Diameter of Bolts in Inches Number of bolts used Bolt Circle in Inches Diameter of Bolt Holes in Inches
1/2 3-1/2 1/2 4 2-3/8 0.62
3/4 3-7/8 1/2 4 2-3/4 0.62
1 4-1/4 1/2 4 3-1/8 0.62
20 27-1/2 1-1/8 20 25 1.25
14 21 1 12 18-3/4 1.12
1/4 3-3/8 1/2 4 2-1/4 0.62
1-1/4 4-5/8 1/2 4 3-1/2 0.62
6 11 3/4 8 9-1/2 0.88
1-1/2 5 1/2 4 3-7/8 0.62
2 6 5/8 4 4-3/4 0.75
12 19 7/8 12 17 1
3 7-1/2 5/8 4 6 0.75
3-1/2 8-1/2 5/8 8 7 0.75
4 9 5/8 8 7-1/2 0.75
18 25 1-1/8 16 22-3/4 1.25
2-1/2 7 5/8 4 5-1/2 0.75
5 10 3/4 8 8-1/2 0.88
8 13-1/2 3/4 8 11-3/4 0.88
10 16 7/8 12 14-1/4 1
16 23-1/2 1 16 21-1/4 1.12
24 32 1-1/4 20 29-1/2 1.38

CS Slip On Flanges Torque Values

Size in Inch Size in MM Number of Bolt Bolt Diameter Bolt Stress
lb/in2
Torque
lbf.ft.
Torque
Nm
10 250 12 7/8 40,000 194 263
3/4 20 4 ½ 30,000 26 36
6 150 8 ¾ 45,000 137 185
20 500 20 1 1/8 40,000 421 571
1 35 4 ½ 33,000 29 39
1 ½ 40 4 ½ 50,000 44 60
1/2 15 4 ½ 25,000 22 30
18 450 16 1 1/8 40,000 421 571
2 50 4 5/8 50,000 86 117
12 300 12 7/8 40,000 194 263
3 80 4 5/8 50,000 86 117
16 400 16 1 40,000 289 392
4 100 8 5/8 40,000 69 93
8 200 8 ¾ 45,000 137 185
14 350 12 1 41,000 296 401
24 600 20 1 ¼ 40,000 588 797

Gasket For Carbon Steel Flanges

Gasket I.D.
NPS Gasket O.D.
Class 400 Class 150 Class 600 Class 300 Class 900
0.84 1/2 2.125 1.875 2.125 2.125 2.50
1.06 3/4 2.625 2.25 2.625 2.625 2.75
1.31 1 2.875 2.625 2.875 2.875 3.125
1.66 1 1/4 3.25 3 3.25 3.25 3.50
1.91 1 1/2 3.75 3.375 3.75 3.75 3.875
2.38 2 4.375 4.125 4.375 4.375 5.625
2.88 2 1/2 5.125 4.875 5.125 5.125 6.50
3.50 3 5.875 5.375 5.875 5.875 6.625
4.50 4 7.00 6.875 7.625 7.125 8.125
5.56 5 8.375 7.75 9.50 8.50 9.75
6.62 6 9.75 8.75 10.50 9.875 11.375
8.62 8 12.00 11 12.625 12.125 14.125
10.75 10 14.125 13.375 15.75 14.25 17.125
12.75 12 16.50 16.125 18.00 16.625 19.625

Carbon Steel Pn16 Flange Dimensions

Diameter Nominal Diameter of
Bolt Holes
Outer Diameter
of Pipe
Diameter
Male
Bolting Outer Diameter
of Flange
Pitch Circle
Diameter
Thickness of Flange Diameter at
Base of Hub
Height of
Flange
WN SOH BL
NPS DN L d1 d2 n t1 D K t2 t3 H1 X2 H2 X1
3/4 20 14 26.9 56 4 M12 105 75 16 16 16 40 45 40 26
16 400 30 406.4 480 16 M27 580 525 32 32 32 444 456 85 63
14 350 26 355.6 429 16 M24 520 470 30 30 30 390 400 82 57
3/8 10 14 17.2 41 4 M12 90 60 14 14 14 28 30 35 22
1/2 15 14 21.3 46 4 M12 95 65 14 14 14 32 35 38 22
1 25 14 33.7 65 4 M12 115 85 16 16 16 46 52 40 28
1 1/4 32 18 42.4 76 4 M16 140 100 18 18 18 56 60 42 30
12 300 26 323.9 370 12 M24 460 410 28 28 28 7 342 350 8 53
1 1/2 40 18 48.3 84 4 M16 150 110 18 18 18 64 70 45 32
2 50 18 60.3 99 4 M16 165 125 20 20 20 74 84 48 34
18 450 30 457 530 20 M27 640 585 34 34 36 490 502 87 63
10 250 26 273 319 12 M24 405 355 26 26 26 288 298 70 46
2 1/2 65 18 76.1 118 4 M16 185 145 20 20 20 92 104 48 32
4 100 18 114.3 156 8 M16 220 180 22 22 22 130 140 52 40
5 125 18 139.7 184 8 M16 250 210 22 22 22 158 168 55 44
6 150 22 168.3 211 8 M20 285 240 24 24 24 184 195 55 44
3 80 18 88.9 132 8 M16 200 160 20 20 20 110 118 50 34
8 200 22 219.1 266 12 M20 340 295 24 24 24 234 246 62 44
20 500 33 508 582 20 M30 715 650 34 34 36 546 559 90 73
24 600 36 610 682 20 M33 840 770 36 36 44 650 658 95 83

Manufacturer of Tongue and Groove faces Carbon Steel Pipe Flanges and Low CS Plate, Backing, Companion, Threaded, Stub End Flange in Mumbai, view pressure rating and Carbon Steel Blind Flange price in India

Carbon Steel Flanges Temperature Ratings

Temperature (°C) Class 900 150 Class Class 600 400 Class Class 2500 1500 Class Class 300
-29 - 38 155 19.8 103.4 68.9 431 259 51.7
50 155 19.5 103.4 68.9 431 259 51.7
300 129 10.2 85.7 57.0 357 214 42.9
150 151 15.8 100.3 66.8 418 251 50.2
475 51.3 3.7 34.2 22.8 142 85.4 17.1
100 155 17.7 103.0 68.7 429 258 51.5
425 86.3 5.5 57.5 38.4 240 144 28.8
200 146 13.8 97.2 64.8 405 243 48.6
325 124 9.3 82.6 55.0 344 207 41.4
350 120 8.4 80.0 53.4 334 200 40.0
400 104 6.5 69.4 46.3 290 174 34.7
250 139 12.1 92.7 61.7 386 232 46.3
375 114 7.4 75.7 50.4 315 189 37.8
450 69.0 4.6 46.0 30.7 192 115 23.0
500 34.7 2.8 23.2 15.4 96.5 57.9 11.6
538 17.7 1.4 11.8 7.9 49.2 29.5 5.9

CS Forged Flanges Standard

JIS B2220 Flange SABS / SANS 1123 Flanges
BS 4504 Flanges EN 1092-1 Flange
API Flanges GOST 12820 80 Flanges
Australian Flanges MSS SP-44 Flange
ISO Flanges AWWA C207 Flanges
Korean Flanges BS 10 Flanges

Carbon Steel Flanges Weight Chart

Standard Class Bolt Circle Diameter Bolt Size Diameter Number of Bolts Diameter of Bolt Hole
ISO 7005 (DIN) PN6 55 M10 80 4 11
PN10 65 M12 95 4 14
PN16 65 M12 95 4 14
PN20 60.5 M14 90 4 16
PN25 65 M12 95 4 14
PN40 65 M12 95 4 14
ANSI B16.5 ANSI 150 60 13 89 4 16
ANSI 300 67 13 95 4 16
ANSI 600 67 13 95 4 16
ANSI 900 83 19 121 4 22
ANSI 1500 83 19 121 4 22
AS4087 PN14 67 M12 95 4 14
AS 2129 Table C 67 13 95 4 14
Table D 67 13 95 4 14
Table E 67 13 95 4 14
Table F 67 13 95 4 14
Table H 83 16 114 4 17
Table J 83 16 114 4 17

Carbon Steel Flange Coating

Carbon Steel Flange Coating

Looking for CL150 Raised/ Flat Face Carbon Steel Flanges manufacturers in India? Killed Carbon Steel Forged Flanges in all types including Lap Joint, Spectacle Blinds, Orifice, LWN and Swivel Ring Flanges

Carbon Steel Pipe Flange Dimensions

Pipe Size In Inch
Pipe Outside Diameter In Inch
Flange Outside Diameter In Inch Bolt Hole Diameter In Inch Number of Bolt HolesBolt Circle In Inch
2 2.38 6 3/4 4 4-3/4
3/4 1.05 3-7/8 5/8 4 2-3/4
12 12.75 19 1 12 17
1 1.32 4-1/4 5/8 4 3-1/8
14 14.00 21 1-1/8 12 18-3/4
1-1/4 1.66 4-5/8 5/8 4 3-1/2
20 20.00 27-1/2 1-1/4 20 25
1/2 0.84 3-1/2 5/8 4 2-3/8
18 18.00 25 1-1/4 16 22-3/4
1-1/2 1.90 5 5/8 4 3-7/8
16 16.00 23-1/2 1-1/8 16 21-1/4
2-1/2 2.88 7 3/4 4 5-1/2
10 10.75 16 1 12 14-1/4
3 3.50 7-1/2 3/4 4 6
4 4.50 9 3/4 8 7-1/2
5 5.56 10 7/8 8 8-1/2
6 6.63 11 7/8 8 9-1/2
3-1/2 4.00 8-1/2 3/4 8 7
8 8.63 13-1/2 7/8 8 11-3/4
24 24.00 32 1-3/8 20 29-1/2

CS Weld Neck Flange Physical Properties

Properties Value
Density (lb / cu. in.) 0.284
Specific Gravity 7.9
Specific Heat (Btu/lb/Deg F - [32-212 Deg F]) 0.107
Melting Point (Deg F) 2740
Thermal Conductivity 360
Mean Coeff Thermal Expansion 6.7
Modulus of Elasticity Tension 30
Modulus of Elasticity Torsion 11
Manufacturing Sch 80Carbon Steel Pipe Flanges for petrochemical industry in Europe, USA, UAE, and Malaysia, 100% PMI MSS SP-44 CS Plate Flanges and Killed CS Flanges with MTC/ MTR reports

Carbon Steel Flanges HS Code

Description HSN Code
Carbon Steel Flanges 73072100

Carbon Steel Flange Mill Test Certificate

  • Raw Materials Certificate
  • EN 10204/3.1B
  • Third Party Inspection Report
  • 100% Radiography Test Report
  • Manufacturer Test Certificate as EN 10204/3.1B

Carbon Steel Puddle Flange Dimensions

Carbon Steel Puddle Flange Dimensions

CS Lap Joint Flange Chemical Composition

Grade Carbon Manganese Phosphorus Sulfur Silicon Copper Nickel Chromium Molybdenum Vanadium
Carbon Steel Flanges 0.35 0.60 To 1.05 0.35 0.40 0.10 To 0.35 0.40 0.40 0.30 0.12 0.08

CS Socket Weld Flange Mechanical Properties

Tensile Strength Elongation Yield Strength Hardness Reduction of Area
MPa ksi % MPa ksi HBW %
485 70 22 250 36 137-187 30

Carbon Steel Weld Neck Flange Dimensions

Nominal Pipe Size Thickness
B
Diameter
D
Diameter
L
Diameter
OD
Height
H
Diameter
A
Diameter
K
3/4 0.44 3.88 5/8 1.05 2 1.5 2.75
1 0.5 4.25 5/8 1.32 2.12 1.94 3.12
3.1/2 0.88 8.5 3/4 4 2.75 4.81 7
20 1.62 27.5 1.1/4 20 5.62 22 25
16 1.38 23.5 1.1/8 16 4.94 18 21.25
1.1/4 0.56 4.62 5/8 1.66 2.19 2.31 3.5
1.1/2 0.62 5 5/8 1.9 2.38 2.56 3.88
8 1.06 13.5 7/8 8.63 3.94 9.69 11.75
2 0.69 6 3/4 2.38 2.44 3.06 4.75
18 1.5 25 1.1/4 18 5.44 19.88 22.75
2.1/2 0.81 7 3/4 2.88 2.69 3.56 5.5
14 1.31 21 1.1/8 14 4.94 15.75 18.75
1/2 0.38 3.5 5/8 0.84 1.81 1.19 2.38
3 0.88 7.5 3/4 3.5 2.69 4.25 6
4 0.88 9 3/4 4.5 2.94 5.31 7.5
12 1.19 19 1 12.75 4.44 14.38 17
5 0.88 10 7/8 5.56 3.44 6.44 8.5
6 0.94 11 7/8 6.63 3.44 7.56 9.5
10 1.12 16 1 10.75 3.94 12 14.25
24 1.81 32 1.3/8 24 5.94 26.12 29.5
A complete range of Carbon Steel Slip On Flanges and Class 300/ 600 RF CS Lap Joint, Tongue and Groove Flange in India, buy RTJ/ RF CS Socket Weld Flange, and Carbon Steel Orifice Flange in Mumbai at Low price

Ansi Steel Welding Neck Flange Material Grade

  • ASTM A105 Flanges
  • ASTM A350 Lf2 Low-temperature Flanges
  • Carbon Steel In Low Alloy A182 Flanges
  • ASTM A694 Flanges For High Yield Service

Carbon Steel Flange Thickness

Nominal Wall Thickness
Pipe Normal Sizes OD Schedule
80 10 XX Hvy 20 160 Schedule 0 EXT Hvy STD Wall 40 100 140
¾ 1.05 0.154 0.083 0.308 0.219 0.154 0.113 0.113
½ 0.84 0.147 0.083 0.294 0.188 0.147 0.109 0.109
1 1.315 0.179 0.109 0.358 0.25 0.179 0.133 0.133
1 ½ 1.9 0.2 0.109 0.4 0.281 0.2 0.145 0.145
2 2.375 0.218 0.109 0.436 0.344 0.218 0.154 0.154
3 3.5 0.3 0.12 0.6 0.438 0.3 0.216 0.216
3 ½ 4 0.318 0.12 0.636 0.318 0.226 0.226
4 4.5 0.337 0.12 0.674 0.531 0.337 0.237 0.237
6 6.625 0.432 0.134 0.864 0.719 0.432 0.28 0.28
8 8.625 0.5 0.148 0.875 0.25 0.906 0.277 0.5 0.322 0.322 0.594 0.812
12 12.75 0.688 0.18 1 0.25 1.312 0.33 0.5 0.375 0.406 0.844 1.125
14 14 0.75 0.25 0.312 1.406 0.375 0.5 0.375 0.438 0.938 1.25
16 16 0.844 0.25 0.312 1.594 0.375 0.5 0.375 0.5 1.031 1.438
20 20 1.031 0.25 0.375 1.969 0.5 0.5 0.375 0.594 1.281 1.75
22 22 0.25 0.5 0.375
24 24 1.219 0.25 0.375 2.344 0.562 0.5 0.375 0.688 1.531 2.062
30 30 0.312 0.5 0.625 0.5 0.375
36 36 0.312 0.5 0.625 0.5 0.375 0.75
42 42 0.5 0.375
Carbon Steel Flanges manufacturers in India

Killed CS Flanges Material Application

Killed CS Flanges Material Application
  • Power Generation
  • Off-Shore Oil Drilling Companies
  • Gas Processing
  • Petrochemicals
  • Pharmaceuticals
  • Specialty Chemicals
  • Chemical Equipment
  • Heat Exchangers
  • Sea Water Equipment

Carbon Steel Flange Bolt Chart


Class 150 Flanges
Class 300 Flanges Class 600 Flanges
NPS Diameter of Bolts And Studs # Bolts And Studs Stud Length Diameter of Bolts And Studs # Bolts And Studs Stud Length Diameter of Bolts And Studs # Bolts And Studs Stud Length
1/16 RF RTJ 1/16 RF RTJ 1/4 RF RTJ
1/2 0.50 4 2-1/4 0.50 4 2-1/2 3 0.50 4 3 3
3/4 0.50 4 2-1/2 0.63 4 3 3-1/2 0.63 4 3-1/2 3-1/2
1 0.50 4 2-1/2 3 0.63 4 3 3-1/2 0.63 4 3-1/2 3-1/2
1-1/4 0.50 4 2-3/4 3-1/4 0.63 4 3-1/4 3-3/4 0.63 4 3-3/4 3-3/4
1-1/2 0.50 4 2-3/4 3-1/4 0.75 4 3-1/2 4 0.75 4 4-1/4 4-1/4
2 0.63 4 3-1/4 3-3/4 0.63 8 3-1/2 4 0.63 8 4-1/4 4-1/4
2-1/2 0.63 4 3-1/2 4 0.75 8 4 4-1/2 0.75 8 4-3/4 4-3/4
3 0.63 4 3-1/2 4 0.75 8 4-1/4 4-3/4 0.75 8 5 5
3-1/2 0.63 8 3-1/2 4 0.75 8 4-1/4 5 0.88 8 5-1/2 5-1/2
4 0.63 8 3-1/2 4 0.75 8 4-1/2 5 0.88 8 5-3/4 5-3/4
5 0.75 8 3-3/4 4-1/4 0.75 8 4-3/4 5-1/4 1.00 8 6-1/2 6-1/2
6 0.75 8 4 4-1/2 0.75 12 4-3/4 5-1/2 1.00 12 6-3/4 6-3/4
8 0.75 8 4-1/4 4-3/4 0.88 12 5-1/2 6 1.13 12 7-1/2 7-3/4
10 0.88 12 4-1/2 5 1.00 16 6-1/4 6-3/4 1.25 16 8-1/2 8-1/2
12 0.88 12 4-3/4 5-1/4 1.13 16 6-3/4 7-1/4 1.25 20 8-3/4 8-3/4
14 1.00 12 5-1/4 5-3/4 1.13 20 7 7-1/2 1.38 20 9-1/4 9-1/4
16 1.00 16 5-1/4 5-3/4 1.25 20 7-1/2 8 1.50 20 10 10
18 1.13 16 5-3/4 6-1/4 1.25 24 7-3/4 8-1/4 1.63 20 10-3/4 10-3/4
20 1.13 20 6-1/4 6-3/4 1.25 24 8 8-3/4 1.63 24 11-1/4 11-1/2
24 1.25 20 6-3/4 7-1/4 1.50 24 9 10 1.88 24 13 13-1/4

Low Temperature CS Flanges Packaging

Low Temperature CS Flanges Packaging
  • Payment Terms:- L/C (Letter of Credit), T/T (Bank Transfer)
  • Other Ports of Dispatch:- Mumbai Or Kalamboli India
  • Details on the packaging:- The ASTM A105 Approved Carbon Steel Flanges are marked, painted with black japan or black board (Mat Finish), and placed in a bagging bag with size, grade, and quantity stickers written on them
