7075 Aluminum Tubing and Aluminium 6061 t6 tube manufacturer in Mumbai

Aluminium Pipe Supplier in India

What Is Aluminium Pipe Vs Aluminium Tube
Aluminium is a high-strength grade designed with pipes and tubes as the main piping constituents. The grades can be distinguished based on certain aspects.

  • Aluminium pipes can only be shaped in a circular shape. Tubes in this grade can be shaped in circular, square, and rectangular cross-sections.
  • Tubes in the aluminium grade can be manufactured in the hot and cold rolling process. Similarly, pipes in this grade can only be manufactured in the hot rolling process.
  • Pipes are available in seamless, welded, and ERW types. Tubes are available in a seamless, welded, heat exchanger, boiler, condenser, coiled, etc.
  • Aluminium tubes are stronger and more rigid than pipes of this grade.

Aluminium Seamless Pipe Vs Welded Aluminium Pipes
Pipes in the aluminium grade are available in seamless and welded configurations. Both types can be differentiated based on certain features.

  • Aluminium seamless pipes are manufactured by passing hot steel billets through extruded metal. Welded pipe grade is welded in place, making use of sheets or strips to precisely shape the components.
  • Seamless pipes of aluminium grade possess higher strength and load-bearing capacity than a welded pipe configuration.
  • Welded aluminium pipes are cheaper than a standard seamless pipe.

6061 Aluminum Tubing and 7075 Aluminum Tube
6061 and 7075 aluminum tubes are heat treatable items and can be only compared when they are heat treated by the same process. Below are the most common differences.

  • The 7075 tube showcases enhanced strength over the 6061 grade.
  • Tubes of the 6061 grade can be welded and machined more precisely than the latter.
  • The aluminium 7075 tube melts at a slightly lower temperature than a 6061 grade.
  • Aluminium 6061 tubing has higher thermal conductivity than a 7075 tube.

How Do You Bend Aluminum Plumbing Pipe Without a Pipe Bender?

  • The first step is to plug the pipe and fill the end with sand or some material to give the pipe strength.
  • Clamp one end of the pipe and bend it, hydraulic benders can be also used to slowly bend the pipe without deformation.
  • Sand the pipe and cut any deformed part.

Looking for Anodized Aluminum Pipe manufacturer in India? Check ASME SB 211 Welded Pipes & Tubes, Aluminium Section Pipe and 6082 Aluminium Hollow Pipe in a wide range of sizes, specification and properties.

Aluminum Irrigation Pipe Specification

ASTM Specification ASTM/ ASME B 211 / SB 211, B 619 / SB 619
Form Square, Pan Cake Coils, Round, Hollow, Hydraulic, Rectangular, Coiled, “U” Shape, Straight Pipes etc.
Standard EN, JIS, NF, TOCT, ASTM, ASME, DS, AMS, SAE, DTD, AISI, DIN, GB
Type DOM / ERW/ Seamless / EFW / Fabricated / Welded / CDW / CEW Aluminium
Seamless Pipes Size from 4 upto 219mm W. T.: 0.5 upto 20mm
End Beveled End, Screwed ends, Plain End, Treaded Pipe
Welded Pipes Size between 5.0 to 1219.2 mm
Marking by Aluminium pipe suppliers
  • Nominal Pipe Sizes (NPS)
  • Material Grade
  • Wall Thickness or Schedule No.
  • Heat Number
  • Manufacturing Process (Seamless/ EFW/ ERW/ Welded)
  • Stockholder/ Dealer/ Supplier or Manufacturer’s Name or Custom Logo - as required
EFW Pipe size between 5.0 to 1219.2 mm
Application Oil Pipe, Dairy Pipe, Gas Pipe, Boiler Pipes for Chemical Industry, Fluid Pipe
Swg & Bwg 10 Swg., 12 Swg., 16 Swg., 20 Swg., 14 Swg., 18 Swg.,
Value Added Service provided by Anodized Aluminum Pipe Suppliers Polish (Electro & Commercial) Annealed & Pickled Bending, Draw & Expansion as per required Size & Length, Machining Etc.
Schedule XS, Schedule30, Schedule40, XXS, Schedule80, Schedule120, Schedule60, Schedule140, STD, Schedule10, Schedule10S, Schedule40S, Schedule80, Schedule20, Schedule5, Schedule160 Manufacturers
Specialize in Aluminium Pipe Large Diameter
Large Diameter Aluminum Tube
Aluminium Pipe Length Single & Double Random, Cut length Pipe and Standard.
Manufacturing Technique Hot drawn, cold drawn, solid solution, bright annealed, hot extruding
Finish AP (Annealed & Pickled), Polished, BA (Bright & Annealed), NO.1, MF, NO.4, BA, 2B, HL, Mirror finish, 8K, etc
Material Test Certificates (MTC) EN 10204 3.1 / 10204 3.2, Material Test Certificates (MTC) as per EN 10204/3.1B, Heat Treatment Charts, 100% Radiography Test Report, Raw Materials Certificate, Fumigation Certificates, Third Party Inspection Report, Form A for Generalized System of Preferences (GSP), Aluminium HS Code Commercial Invoice
Our stockyard Bhubaneswar, Ahmedabad, Navi Mumbai, Noida, Thiruvananthapuram, Dhanbad, Tiruchirappalli, Hyderabad, Agra, Mumbai, Pune, Bengaluru, Chennai, Shivamogga, Coimbatore, Pimpri Chinchwad, Tirunelveli
Aluminum Tube Manufacturers
  • Sumitomo Metals, Japan
  • Schoeller Bleckmann, Austria
  • Sanyo Special Steel, Japan
  • Nippon Steel Corporation, Japan
  • Kobe Special Tube, Japan
  • Seah Steel Corporation, Korea
  • Tubacex Tubos Inoxidables S.A., Spain
Test Certificate provided by Aluminium Pipe Manufacturers In India Manufacturer Test Certificate
Laboratory Test Certificate from Govt. Approved Lab.
Under Third Party Inspection
We can also cut, thread, and groove Aluminum Tubing Distributors to meet your specifications. Aluminium 6061 T6 Tube Suppliers Dimension ANSI/ ASME B36.10, B36.19, B2.1
Types Wall thickness Out diameter Length
Aluminium Seamless Pipe (Custom Sizes) As per requirement 5.0mm ~ 203.2mm Upto 6 Meters
NB Sizes (in stock) SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160 1/8” ~ 8” Upto 6 Meters
Aluminium Welded Pipe (in Stock + Custom Sizes) 1.0 ~ 15.0 mm 5.0mm ~ 1219.2mm Upto 6 Meters

Aluminum Compressed Air Piping Chemical Composition

Grade Mn Si Mg Fe Cr Cu Ti Zn Others(Total) Al
Aluminium 0.15 0.40 – 0.80 0.8-1.2 0.70 max 0.04-0.35 0.15-0.40 0.15 max 0.25 max 0.15 max Balance

Aluminium Pipe Roughness

Surface Absolute Roughness Coefficient
k -
(feet) (10-3 m)
Drawn Copper, Lead, Brass, Aluminum (new) and the like (3.28 - 6.56) 10-6 0.001 - 0.002

Threaded Aluminum Tube Mechanical Properties

Temper Tensile Hardness
Ultimate Yield Elongation Brinell
MPA KSI KSI MPA %
T6, T651 310 45 21 145 25 65

Prestige quality Aluminium Pipe Suppliers offer these Black Anodised Aluminium Pipes and Threaded Aluminum Pipes in Mumbai. Supply Cut to length 6061 Aluminium Shoulder Pipes, ASTM B 211 Aluminium 5052, 6063 Pipe and Schedule and Weight Chart

Aluminium Pipe Tolerances


Nominal Diameter Tol. Nominal Pipe Size  Schedules 5 & 10 Schedules 20 & greater
6061-T6, 6063-T52, 6101-T6 Extruded   5 to 6 + 0.062",  - 0.031"  +/- 1%
6061-T6, 6063-T52, 6101-T6 Extruded   Under 2 + 0.015",  - 0.031" + 0.015",  - 0.031"
6061-T6, 6063-T52, 6101-T6 Extruded   8 to 12 + 0.093",  - 0.031"  +/- 1%
6061-T6, 6063-T52, 6101-T6  Extruded   2 to 4 +/- 0.031"  +/- 1%
Schedule # Wall Thickness Tol.
6061-T6, 6063-T52, 6101-T6 Extruded   5 & 10 +/- 12.5%, +/- 0.012" min.
6061-T6, 6063-T52, 6101-T6 Extruded   20 & Greater  - 12.5%

Anodized Aluminum Pipe Physical Properties

Physical Property Value
Modulus of Elasticity 69 GPa
Density 2,70 g/cm³
Thermal Conductivity 170 W/m.K
Melting Point 582 °C
Electrical Resistivity %43 IACS
Thermal Expansion 23.4 x 10^-6 /K

Types of Aluminium Pipes and Tubes

Aluminium Square Pipe
Aluminium Square Pipe
Aluminium Square Pipe
Aluminum Air Pipe
Aluminum Air Pipe
Aluminum Air Pipe
Aluminium Flexible Pipe
Aluminium Flexible Pipe
Aluminium Flexible Pipe
Anodized Aluminum Pipe
Anodized Aluminum Pipe
Anodized Aluminum Pipe
Oval Aluminium Tube
Oval Aluminium Tube
Oval Aluminium Tube
Aluminium Round Pipe
Aluminium Round Pipe
Aluminium Round Pipe
Aluminium Exhaust Pipe
Aluminium Exhaust Pipe
Aluminium Exhaust Pipe
Aluminum Threaded Pipe
Aluminum Threaded Pipe
Aluminum Threaded Pipe
Aluminium Rectangular Pipe
Aluminium Rectangular Pipe
Aluminium Rectangular Pipe
Aluminum Water Pipe
Aluminum Water Pipe
Aluminum Water Pipe
Aluminium Irrigation Pipe
Aluminium Irrigation Pipe
Aluminium Irrigation Pipe
Aluminium Door Pipe
Aluminium Door Pipe
Aluminium Door Pipe
Aluminium Rainwater Pipe
Aluminium Rainwater Pipe
Aluminium Rainwater Pipe
Aluminium Gas Pipe
Aluminium Gas Pipe
Aluminium Gas Pipe
Aluminium Pipe Heat Exchanger
Aluminium Pipe Heat Exchanger
Aluminium Pipe Heat Exchanger
Manufacturer and exporter of Aluminium Hollow Pipe, Aluminium 6063, and 5083 Aluminium Lag Pipe in India. We supply Aluminium 6082 Dome Pipe, 7075, 1100 Aluminium Seamless Pipe from thin wall to thick wall pipes in seamless or welded forms.

Aluminium Pipe Cutting Machine

Aluminium Pipe Cutting Machine

Schedule 40 Aluminum Pipe Size Chart

OM SIZE OUTSIDE
DIA (D)
WALL THICKNESS IN MM (T)
METRIC SIZE
Schedule 40 Schedule 10S Schedule 80s Schedule 10 Schedule 80 Schedule
40 S
STD Weight
1 1/2" 48.26 3.68 2.77 5.08   5.08 3.68 3.68 40
1/4 " 13.72 2.24 1.65 3.02   3.02 2.24 2.24 -
2" 60.32 3.91 2.77 5.54 - 5.54 3.91 3.91 50
3/8" 17.15 2.31 1.65 3.2   3.2 2.31 2.31
2 1/2" 73.02 5.16 3.05 7.01 - 7.01 5.16 5.16 65
1/2" 21.34 2.77 2.11 3.73 - 3.73 2.77 2.77 15
3" 88.9 5.49 3.05 7.62 - 7.62 5.49 5.49 80
3/4" 26.67 2.87 2.11 3.91   3.91 2.87 2.87 20
4" 114.3 6.02 3.05 8.56 - 8.56 6.02 6.02 100
1" 33.4 3.38 2.77 4.55 - 4.55 3.38 3.38 25
5" 141.3 6.55 3.4 9.52 - 9.52 6.55 6.55 125
1 1/4" 42.16 3.56 2.77 4.85   4.85 3.56 3.56 32
8" 219.07 8.18 3.76 12.7 - 12.7 8.18 8.18 200
3 1/2" 101.6 5.74 3.05 8.08 - 8.08 5.74 5.74 90
10" 273.05 9.27 4.19 12.7 - 15.08 9.27 9.27 250
6" 168.27 7.11 3.4 10.97 - 10.97 7.11 7.11 150
14" 355.6 11.12 4.77 - 6.35 19.05 - 9.52 350
12" 323.85 10.31 4.57 12.7 - 17.47 9.52 9.52 300
18" 457.2 14.27 4.77 - 6.35 23.82 - 9.52 450
16" 404.6 12.7 4.77 - 6.35 21.44 - 9.52 400

Aluminium Exhaust Pipe Schedule Chart

3 1/2" IPS( 4.000"O. D.) 1/8" IPS(.405"O. D.)
SCH 10, 40, 80, 160, XXH SCH 40, 80
4" IPS(4.500"O. D.) 1/4" IPS(.540"O. D.)
SCH 10, 40, 80, 160, XXH SCH 10, 40, 80
5" IPS( 5.563"O. D.) 3/8" IPS(.675"O. D.)
SCH 10, 40, 80, 160, XXH SCH 10, 40, 80
6" IPS(6.625"O. D.) 1/2" IPS(.840"O. D.)
SCH 5, 10, 40, 80, 120, 160, XXH SCH 5, 10, 40, 80, 160, XXH
8 ” IPS(8.625"O. D.) 3/4" IPS(1.050"O. D.)
SCH 5, 10, 40, 80, 120, 160, XXH SCH 10, 40, 80, 160, XXH
10" IPS(10.750"O. D.) 1" IPS:(1.315′O. D.)
SCH 10, 20, 40, 80 (.500), TRUE 80(.500) SCH 5, 10, 40, 80, 160, XXH
12" IPS(12.750"O. D.) 1-1/4" IPS(1.660"O. D.)
SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) SCH 10, 40, 80, 160, XXH
14" IPS(14.000"O. D.) 1-1/2" IPS(1.900"O. D.)
SCH10 (.188), SCH40 (.375) SCH 10, 40, 80, 160, XXH
16" IPS(16.000"O. D.) 2" IPS(2.375"O. D.)
SCH10(.188), SCH40(.375) SCH 10, 40, 80, 160, XXH
18" IPS (18.000"O. D.) 2 1/2" IPS(2.875"O. D.)
SCH-40 (.375) SCH 10, 40, 80, 160, XXH
  3" IPS( 3.500"O. D.)
  SCH 5, 10, 40, 80, 160, XXH
We Keep Bulk Stock of Aluminium 6061 Hexagonal Pipe, Aluminium 5086 ERW Pipes and 6061 Aluminium T Pipe at our stockyard. Buy Jindal Aluminium Square Pipe, 6061 Aluminium Acorn Pipes and Aluminium Water Pipe at best price in India

Aluminium Pipe Weight Chart

NPS Outside Diameter Weight Weight Wall Thickness
in mm kg/Mtr Lb/ft mm in Sched
3/4″ 1.050 27 1.684 1.131 2.870 0.113 40 STD
2.195 1.474 3.912 0.154 80 STD
1/2″ 0.840 21 1.268 0.851 2.769 0.109 40 STD
1.621 1.088 3.734 0.147 80 STD
1 1/4″ 1.660 42 3.385 2.273 3.556 0.140 40 STD
4.464 2.997 4.851 0.191 80 STD
1″ 1.315 33 2.501 1.679 3.378 0.133 40 STD
3.325 2.172 4.547 0.179 80 STD
2″ 2.375 60 5.441 3.653 3.912 0.154 40 STD
7.480 5.022 5.537 0.218 80 STD
1 1/2″ 1.900 48 4.048 2.718 3.683 0.145 40 STD
5.409 3.361 5.080 0.200 80 STD
2 1/2″ 2.875 73 8.629 5.793 5.516 0.203 40 STD
11.411 7.661 7.010 0.276 80 STD
4″ 4.500 114 16.073 10.790 6.020 0.237
22.318 14.983 8.560 0.337
3″ 3.500 89 11.284 7.576 5.486 0.216 40 STD
15.272 10.253 7.620 0.300 80 STD
8″ 8.625 219 25.233 16.940 4.775 0.188
27.198 18.259 5.156 0.203
29.286 19.661 5.563 0.219
33.308 22.361 6.350 0.250 20
36.786 24.696 7.036 0.277 30
42.352 28.554 8.179 0.322 40
49.216 33.041 9.525 0.375
53.085 35.638 10.312 0.406 60
64.627 43.388 12.700 0.500 80 XHY
6″ 6.625 168 19.252 12.924 4.775 0.188
20.739 13.923 5.516 0.203
22.318 14.983 5.563 0.219
25.354 17.021 6.350 0.250
58.263 18.974 7.112 0.280 40 STD
31.334 21.036 7.925 0.312
37.285 25.031 9.525 0.375
42.561 28.573 10.973 0.432 80 XHY
48.719 32.708 12.700 0.500
10″ 10.750 273 31.588 21.207 4.775 0.188
36.689 24.631 5.563 0.219
41.759 28.035 6.350 0.250 20
51.002 34.240 7.798 0.307 30
56.946 38.231 8.738 0.344
63.301 40.483 9.271 0.365 40 STD
71.852 48.238 11.125 0.438
81.530 54.735 12.700 0.500 60 XHY
95.969 64.429 15.088 0.594 80
14″ 14.000 356 41.308 27.732 4.775 0.188
48.012 32.233 5.563 0.219
54.685 36.713 6.350 0.250 20
61.327 41.172 7.137 0.281
67.939 45.611 7.925 0.312
81.281 54.568 9.525 0.375 STD
94.498 63.441 11.125 0.438 40
107.381 72.090 12.700 0.500 XHY
132.983 89.278 15.875 0.625
12″ 12.750 324 37.570 25.222 4.775 0.188
43.657 29.309 5.563 0.219
49.713 33.375 6.350 0.250
55.739 37.420 7.137 0.281
61.735 41.445 7.925 0.312
73.824 49.562 9.525 0.375
79.727 53.525 10.312 0.406
97.438 65.415 12.700 0.500
108.966 73.154 14.275 0.562
16” 16.000 406 47.290 21.748 4.775 0.188
54.980 36.910 5.563 0.219
62.639 42.053 6.350 0.250 10
70.268 47.174 7.137 0.281
77.866 52.275 7.925 0.312 20
85.677 57.519 8.738 0.344
93.213 62.578 9.525 0.375 30 STD
108.433 72.797 11.125 0.438
123.289 82.770 12.700 0.500 40 XHY
20″ 20.000 508 78.547 52.733 6.350 0.250
88.458 59.386 7.163 0.282
97.719 65.604 7.925 0.312
117.075 78.598 9.525 0.375 20 STD
136.305 91.508 11.125 0.438
155.106 104.130 12.700 0.500 30 XHY
183.378 123.110 15.088 0.594 40
192.640 129.328 15.875 0.625
211.368 141.901 17.475 0.688
18″ 18.000 457 61.948 41.588 5.563 0.219
70.593 47.393 6.350 0.250
79.208 53.176 7.137 0.281
87.792 58.939 7.925 0.312 20
105.144 70.588 9.525 0.375 STD
122.369 82.152 11.125 0.438 30
139.198 93.450 12.700 0.500 XHY
155.904 104.666 14.275 0.562 40
172.754 115.978 15.875 0.625
24″ 24.000 610 94.456 63.413 6.350 0.250
106.029 71.183 7.137 0.281
117.573 18.932 7.925 0.312
140.938 64.618 9.525 0.375 20 STD
164.176 110.219 11.125 0.438
186.923 125.490 12.700 0.500 XHY
232.410 156.028 15.875 0.625
255.148 171.293 17.475 0.688 40
277.401 186.233 19.050 0.750
36″ 36.000 914 142.180 95.453 6.350 0.250
159.672 107.196 7.137 0.281
177.133 118.918 7.925 0.312 10
215.525 142.678 9.525 0.375 STD
247.790 166.353 11.125 0.438
282.372 198.570 12.700 0.500 20 XHY
351.723 236.128 15.875 0.625
386.487 259.467 17.475 0.688
420.576 282.353 19.050 0.750
30″ 30.000 762 118.318 79.433 6.350 0.250
132.851 89.189 7.137 0.281
147.353 98.925 7.925 0.312 10
176.731 118.648 9.525 0.375 STD
205.983 138.286 11.125 0.438
234.647 157.530 12.700 0.500 20 XHY
292.066 196.078 15.875 0.625 30
320.817 215.380 17.475 0.688
348.988 234.293 19.050 0.750
48″ 48.000 1219 284.112 190.738 9.525 0.375 STD
331.404 222.487 11.125 0.438
377.822 253.650 12.700 0.500 XHY
563.750 378.473 19.050 0.750
655.969 440.383 22.225 0.875
42″ 42.000 1067 206.914 138.911 7.925 0.312
248.319 166.708 9.525 0.375 STD
33.097 221.610 12.700 0.500 XHY
492.163 330.413 19.050 0.750

3 Inch Aluminium Pipe Dimensions

Gauge Regular Wall (RW) mm Outside Diameter Tolerance mm Extra Thin Wall (XTW) mm Thin Wall (TW) mm Ultra Thin Wall (UTW) mm
23 0.140 - 0.165 0.635 - 0.647 0.089 - 0.114 0.051 - 0.102
30 0.064 - 0.089 0.304 - 0.317
22 0.140 - 0.165 0.711 - 0.723 0.077 - 0.102 0.096 - 0.121 0.051 - 0.102
29 0.064 - 0.089 o.330 - 0.342
21 0.140 - 0.165 0.812 - 0.825 0.102 - 0.127 0.051 - 0.102
28 0.076 - 0.102 0.355 - 0.368
20 0.108 - 0.165 0.901 - 0.914 0.108 - 0.134
27 0.089 - 0.115 0.406 - 0.419 0.064 - 0.089
19 0.166 - 0.216 1.054 - 1.079 0.070 - 0.108 0.102 - 0.140
26 0.089 - 0.114 0.457 - 0.469
18 0.191 - 0.241 1.257 - 1.282 0.083 - 0.121 0.127 - 0.165 0.051 - 0.102
25 0.115 - 0.140 0.508 - 0.520 0.089 - 0.114
16 0.204 - 0.254 1.638 - 1.663 0.096 - 0.133 0.127 - 0.165 0.070 - 0.121
24 0.114 - 0.140 0.558 - 0.571 0.089 - 0.114 0.051 - 0.102
12 0.267 - 0.321 2.743 - 2.749
17 0.177 - 0.229 1.460 - 1.485 0.083 - 0.127 0.115 - 0.152 0.057 - 0.102
11 0.293 - 0.368 3.023 - 3.073 0.216 - 0.292
15 0.204 - 0.254 1.816 - 1.841 0.096 - 0.134 0.127 - 0.165 0.070 - 0.121
10 0.318 - 0.394 3.378 - 3.429 0.216 - 0.292
14 0.216 - 0.292 2.082 - 2.133 0.114 - 0.165 0.165 - 0.229 0.076 - 0.134
13 0.267 - 0.343 2.387 - 2.438 0.191 - 0.267

Aluminum Exhaust Tubing Pressure Rating

Pipe O.D.
(in.)
Wall Thickness of Pipe (inches)
.083 .028 .095 .035 .120 .049 .109 .065
Working Pressure (psig)
3/8 3100 4400 6100
1/8 7900 10100
1/2 2300 3200 4400
1/4 3700 4800 7000 9500
3/4 4000 4600 2200 3000
5/16 3700 5400 7300
1 2900 3400 4300 3900 2200

Aluminium Pipe Thickness Chart

NOMINAL O.D. INCHES 40 10S 80S & E.H. 10 80 40S & STD 160
3 3.500 .216 .120 .300 .120 .300 .216 .437
1/8 .405 .068 .049 .095 .049 .095 .068
3 1/2 4.000 .226 .120 .318 .120 .318 .226
1/4 .540 .088 .065 .119 .065 .119 .088
4 4.500 .237 .120 .337 .120 .337 .237 .531
3/8 .675 .091 .065 .126 .065 .126 .091
4 1/2 5.000 .355 .247
1/2 .840 .109 .083 .147 .083 .147 .109 .187
5 5.563 .258 .134 .375 .134 .375 .258 .625
3/4 1.050 .113 .083 .154 .083 .154 .113 .218
6 6.625 .280 .134 .432 .134 .432 .280 .718
1 1.315 .133 .109 .179 .109 .179 .133 .250
7 7.625 .500 .301
1 1/4 1.660 .140 .109 .191 .109 .191 .140 .250
8 8.625 .322 .148 .500 .148 .500 .322 .906
1 1/2 1.900 .145 .109 .200 .109 .200 .145 .281
10 10.750 .365 .165 .500 .165 .593 .365 1.125
2 2.375 .154 .109 .218 .109 .218 .154 .343
12 12.750 .406 .180 .500 .180 .687 .375 1.312
2 1/2 2.875 .203 .120 .276 .120 .276 .203 .375
14 14.000 .437 .188 .500 .250 .750 .375 1.406
9 9.625 .500 .342
18 18.000 .562 .188 .500 .250 .937 .375 1.781
11 11.750 .500 .375
16 16.000 .500 .188 .500 .250 .843 .375 1.593
Don't forget to compare our Aluminium UNS A96061 Tube and Schedule 40 Aluminium Pipe before you buy. View updated Aluminium 5086 tubing, Aluminium Section Pipe and Threaded Aluminum Pipe suppliers in India.

Aluminum Rectangular Tube Price

Products Sizes
1 ft 3 ft
Inside Dia.(inche) Outside Dia.(inche) Wall Thickness (inche) Price in USD Inside Dia.(inche) Outside Dia.(inche) Wall Thickness (inche) Price in USD
High Quality 6061 6082 5083 2024 Aluminium Pipe / 7075 T6 Aluminum Tube 0.035 1/16 0.014 $2.49 / pkg. 0.066 3/32 0.014 $16.44 / pkg.
Aluminium Pipe 6063 6061 6005 Extruded Aluminium Round Tube Aluminium Pipe 0.066 3/32 0.014 $2.67 / pkg. 0.097 1/8 0.014 $17.75 / pkg.
Best Prices Custom 20mm 30mm 100mm 150mm 6061 T6 Large Diameter Anodized Round Aluminum Pipe 0.097 1/8 0.014 $3.16 / pkg. 0.118 3/16 0.035 $32.06 / pkg.
High strength anti oxidation extruded pipe 2mm aluminium round tube 0.128 5/32 0.014 $1.48 / each 0.128 5/32 0.014 $18.81 / pkg.
3mm 4mm Customized Small Diameter 6063 6061 T6 Aluminum Capillary Tube / pipe 0.159 3/16 0.014 $1.48 / each 0.16 3/16 0.014 $23.51 / pkg.
Tubes / Pipes Colourful Aluminium Is Alloy Round for Wind Chime 0.5-150mm 6000 Series 2-2500mm 3 0.191 7/32 0.014 $1.58 / each 0.18 1/4 0.035 $9.70 / each
In Stock Wholesale 6063 6061 T5 T6 300x200 300x300 Large Diameter Square Aluminum Tube Pipe  0.222 1/4 0.014 $1.58 / each 0.18 1/4 0.18 $33.03 / pkg.

Aluminium Pipe HSN Code

HS Code Description
760820 Tubes and pipes of aluminium alloys (excluding hollow profiles)
760810 Tubes and pipes of non-alloy aluminium (excluding hollow profiles)
76082000 TUBES AND PIPES OF ALUMINIUM ALLOYS
76081000 TUBES ANDPIPES OF NON-ALLOYED ALUMINIUM

6061 Aluminium Pipe Welding Machine

6061 Aluminium Pipe Welding Machine

Know the

Delivery strength of your Aluminium Tube Suppliers before ordering.

Application Projects
P.M. Metal Logo

7075 Aluminum Tube

Bangladesh, Jakarta -Indonesia, Dubai, Los Alamos -Mexico, Hong Kong, Turkey, Argentina, Germany, China, Oman, Saudi Arabia (KSA).

Application Projects
P.M. Metal Logo

2.5 Inch Aluminum Pipe

Malaysia, Poland, Romania, Indonesia, Malaysia, Iran, Qatar, New Zealand, Brazil, Netherlands, United Arab Emirates (UAE).

Application Projects
P.M. Metal Logo

6061 Aluminum Tube

USA, Chile, Ellington -United States, Canada, Sweden, United States, Greece, Singapore, Vietnam, Mexico, Denmark, Thailand, Finland.

Application Projects
P.M. Metal Logo

Aluminum Flexible Pipe

Russia, Belgium, Norway, Egypt, Bahrain, Philippines, South Korea, Peru, Malaysia, Tehran -Iran, Colombia, Italy.

Application Projects
P.M. Metal Logo

Curved Aluminum Tubing

Spain, Jakarta, Europe, Australia, Jordan, Dammam -KSA, Japan, Istanbul -Turkey, NY 12203 (USA), Dubai -UAE, Kuala Lumpur.

Application Projects
P.M. Metal Logo

Aluminium Compressed Air Pipe

France, Singapore, Taiwan, South Africa, Portugal, Morocco, Czechia, Kuwait, Austria, United Kingdom (UK), Nigeria.
