SS 316L Washers Material Equivalent
| WERKSTOFF NR. | JIS | UNS | AFNOR | BS | EN | GOST |
| 1.4404 / 1.4435 | SUS 316L | S31603 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | 316S11 / 316S13 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | 03Ch17N14M3 / 03Ch17N14M2 |
Chemical Compatibility of UNS S31603 Stud bolt
| Mn | C | P | Si | S | Cr | Ni | Mo | Fe |
| 2.0 max | 0.035 max | 0.045 max | 1.0 max | 0.030 max | 16.00 - 18.00 | 11.00 - 14.00 | 2.00 - 3.00 | 68.89 min |
SS 316L Nut Bolts Mechanical And Physical Properties
| Melting Point | Density | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
Spec Chart of Stainless Steel 316L Fasteners
| Specification | ASTM A193/ ASME SA193 |
| SS 316L threaded rod Threads | METRIC, BSW, BSF, UNC, UNF or as required |
|---|---|
| 316L Stainless hex screws | M1.6 - M12 |
| Available Length | From 3 mm - 200 mm |
| Size Ranges | M02 – M160 | 3/6" upto 2" |
SS 316L Bolts Applications
- Power Generation
- Off-Shore Oil Drilling Companies
- Gas Processing
- Petrochemicals
- Pharmaceuticals
- Specialty Chemicals
- Chemical Equipment
- Pharmaceutical Equipment
- Heat Exchangers
- Sea Water Equipment
- Pulp and Paper Industry
- Condensers
316L Hex Head Bolt Size Chart
| Minimal Size (D) | HEAD THICKNESS | BODY DIAMETER | CORNERS | THE FLATS | ||||
|---|---|---|---|---|---|---|---|---|
| H | H (MIN) | D | D (MIN) | C | C (MIN) | F (MAX) | F (MIN) | |
| m12 | 7.76 max | 4.24 | 12.00 max | 11.73 | 20.78 max | 20.03 | 19.00 | 17.73 |
| m10 | 6.63 max | 6.17 | 10.00 max | 9.78 | 18.48 max | 17.77 | 17.00 | 15.73 |
| m90 | 57.74 max | 54.26 | 90.00 max | 89.13 | 150.11 max | 143.07 | 130.00 | 125.50 |
| m14 | 9.09 max | 8.51 | 14.00 max | 13.73 | 24.25 max | 23.35 | 22.00 | 20.67 |
| m80 | 51.58 max | 48.42 | 80.00 max | 79.26 | 132.72 max | 126.54 | 115.00 | 111.00 |
| m16 | 10.32 max | 9.68 | 16.00 max | 15.73 | 27.71 max | 26.75 | 24.00 | 23.67 |
| m72 | 46.45 max | 43.55 | 72.00 max | 71.26 | 121.24 max | 115.60 | 105.00 | 101.40 |
| m20 | 12.88 max | 12.12 | 20.00 max | 19.67 | 34.64 max | 32.95 | 30.00 | 29.16 |
| m24 | 15.44 max | 14.56 | 24.00 max | 23.67 | 41.57 max | 39.55 | 36.00 | 35.00 |
| m42 | 26.97 max | 25.03 | 42.00 max | 41.38 | 75.06 | 71.71 | 65.00 | 62.90 |
| m30 | 19.48 max | 17.92 | 30.00 max | 29.67 | 53.12 | 50.85 | 46.00 | 45.00 |
| m100 | 63.9 max | 60.10 | 90.00 max | 99.13 | 167.43 | 159.60 | 145.00 | 140.00 |
| m36 | 23.38 max | 21.63 | 36.00 max | 35.61 | 63.51 | 60.79 | 55.00 | 53.80 |
| m64 | 41.32 max | 38.68 | 64.00 max | 63.26 | 109.70 | 104.65 | 95.00 | 91.80 |
| m48 | 31.07 max | 28.93 | 48.00 max | 47.38 | 86.60 | 82.76 | 75.00 | 72.60 |
| m56 | 36.2 max | 33.80 | 56.00 max | 55.26 | 98.15 | 93.71 | 85.00 | 82.20 |
