Alloy C276 Bolts Equivalent Material
| STANDARD | WERKSTOFF NR. | UNS | EN | JIS | GOST | OR |
| Hastelloy C276 | 2.4819 | N10276 | NiMo16Cr15W | NW 0276 | ХН65МВУ | ЭП760 |
Hastelloy c276 Hex Nut Chemical Compatibility Chart
| C | Ni | Mo | Mn | Si | Fe | P | Co | S | Cr |
| 0.01 max | Balance | 15 – 17 | 1.0 max | 0.08 max | 4 – 7 | 0.04 max | 2.5 max | 0.03 max | 14.5 – 16.5 |
Spec Chart of Hastelloy c276 screws
| Sizes Range | M02 – M160 | 3/6" upto 2" |
| In Form of: |
|
|---|---|
| Available Lengths | From 3 - 200 mm |
| Threads of Hastelloy C276 Screws | METRIC, BSW, UNC, BSF, UNF or as required |
| Specification | ASTM B574/ ASME SB574 |
Mechanical Characteristics of Hastelloy c276 Fasteners
| Density | Yield Strength (0.2%Offset) | Melting Point | Elongation | Tensile Strength |
| 8.89 g/cm3 | Psi – 52,000 , MPa – 355 | 1370 °C (2500 °F) | 40 % | Psi – 1,15,000 , MPa – 790 |
Alloy C276 Bolts Applications
- Power Generation
- Off-Shore Oil Drilling Companies
- Gas Processing
- Petrochemicals
- Pharmaceuticals
- Specialty Chemicals
- Chemical Equipment
- Pharmaceutical Equipment
- Heat Exchangers
- Sea Water Equipment
- Pulp and Paper Industry
- Condensers
