Stainless Steel 316 Plate vs Stainless Steel 316 Sheet?
Stainless steel 316 plates and sheets are metal grades that can be distinguished based on their thickness and functions.
Can 316 Stainless Steel Perforated Sheet be hardened?
The perforated sheets in ss 316 grade cannot be hardened by the process of heat treatment. The versatile sheets can be only be hardened by solution treatment or annealing. Here, the sheets are heated at temperatures between 1010 to 1120 degrees C, followed by rapid cooling.
What is AISI 316 Stainless Steel Sheet and 316 Ss Hot Rolled Plate?
A stainless steel AISI 316 hot rolled plates and sheets are components designed with a superior chemical composition of nickel, chromium, and molybdenum giving them enhanced corrosion resistance properties. The hot rolled plates are processed at temperatures of over 1700 degrees F or above. Here the metal reaches its recrystallization level allowing it to be shaped easily. The robust modules have an uneven surface but have superior strength and tolerance.
Table of Content
Specifications | ASTM / ASME A240/ SA240 |
---|---|
Standard | EN, GB, JIS, AISI, ASTM, DIN, etc |
316 2b Stainless Steel Sheet Thickness | From 4mm to 100mm |
Width | 1000mm, 1500mm, 1219mm, 3500mm, 2000mm, 1800mm, 2500mm, 3000mm, etc |
Surface | 2D, 2B,BA, NO.4, NO.1, NO.8, mirror, 8K, checkered, hair line, embossed, sand blast, etching, brush, etc |
Stainless Hairline 316 Length | 6000mm, 2440mm, 5800mm, 3000mm, 2000mm, etc |
Finish | Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Hot rolled plate (HR) |
Package | Export standard package |
Manufacturer: | Acerinox, Baosteel, Aperam, Thyssenkrup, TISCO, POSCO, Jindal Stainless, Nippon Metal, DKC Korea, Arcelor Mittal, Nas, Sail, Outokumpu |
Stainless Steel 316 Hairline Finish Form | Foils, Coils, Rolls, Shim Sheet, Plain Sheet, Perforated Sheet, Strip, Blank (Circle), Chequered Plate Suppliers and Manufacturer |
Grade | S | C | Cr | Mn | Mo | Si | Ni | P | N |
---|---|---|---|---|---|---|---|---|---|
SS 316 | 0.030 max | 0.08 max | 16.00 – 18.00 | 2 max | 2.00 – 3.00 | 1.0 max | 11.00 – 14.00 | 0.045 max | 67.845 min |
Grade | Tensile Properties | Density | Elongation | Melting Point | Yield Properties (0.2%Offset) |
---|---|---|---|---|---|
SS 316 | Psi – 75000 , MPa – 515 | 8.0 g/cm3 | 35 % | 1400 °C (2550 °F) | Psi – 30000 , MPa – 205 |
Sheet/Plate | ||||
---|---|---|---|---|
Stainless Steel Sheet / Plate | Cold Rolled | Spec. Thickness, in. | Thickness Tol. | |
Widths over 40" & ≤ 50" | Widths ≤ 40" | |||
0.012 | +/- 0.0015 inches | +/- 0.001 inches | ||
0.016 | +/- 0.0015 inches | +/- 0.0015 inches | ||
0.020 | +/- 0.002 inches | +/- 0.0015 inches | ||
0.024 | +/- 0.002 inches | +/- 0.002 inches | ||
0.032 | +/- 0.0025 inches | +/- 0.002 inches | ||
0.040 | +/- 0.003 inches | +/- 0.0025 inches | ||
0.047 | +/- 0.003 inches | +/- 0.003 inches | ||
0.059 | +/- 0.004 inches | +/- 0.003 inches | ||
0.079 | +/- 0.004 inches | +/- 0.004 inches | ||
0.098 | +/- 0.005 inches | +/- 0.004 inches | ||
0.118 | +/- 0.007 inches | +/- 0.005 inches | ||
0.157 | +/- 0.007 inches | +/- 0.007 inches | ||
0.197 | +/- 0.008 inches | +/- 0.007 inches | ||
0.236 | +/- 0.009 inches | +/- 0.007 inches | ||
0.3125 | +/- 0.007 inches |
Grade | Specific Heat 0-100°C (J/kg.K) |
Density (kg/m3) |
Thermal Conductivity (W/m.K) |
Mean Co-eff of Thermal Expansion (µm/m/°C) | Elastic Modulus (GPa) |
Elec Resistivity (nΩ.m) |
|||
---|---|---|---|---|---|---|---|---|---|
At 100°C | At 500°C | 0-315°C | 0-100°C | 0-538°C | |||||
316 | 500 | 8000 | 16.3 | 21.5 | 16.2 | 15.9 | 17.5 | 193 | 740 |
STANDARD | BS | W. NR. | AFNOR | UNS | GOST | JIS | EN |
---|---|---|---|---|---|---|---|
SS 316 | 316S33/ 316S31 | 1.4436/ 1.4401 | Z7CND17‐11‐02 | S31600 | – | SUS 316 | X3CrNiMo17-13-3/ X5CrNiMo17-12-2 |
Property | SS 316 Hairline Finish Sheet |
Hardness | 95 |
316 Stainless Steel Plate Sizes (milimeter) | Weight per sheet (Kilogram) |
Size (milimeter) | Weight per sheet (Kilogram) |
---|---|---|---|
2000 x 1000 x 2.5 | 40.9 | 2500 x1250 x 1.0 | 25.6 |
2500 x 1250 x 1.5 | 38.4 | 2000 x1000 x 0.7 | 11.5 |
2000 x 1000 x 2.0 | 32.7 | 2000 x1000 x 0.9 | 14.7 |
2500 x 1250 x 2.0 | 51.2 | 2500 x1250 x 0.9 | 23.0 |
3000 x 1500 x 1.5 | 55.3 | 2500 x1250 x 0.7 | 17.9 |
3000 x 1500 x 2.0 | 73.7 | 2000 x1000 x 1.0 | 16.4 |
2500 x 1250 x 2.5 | 63.9 | 3000 x1500 x 1.0 | 36.8 |
3000 x 1500 x 2.5 | 92.1 | 2000 x1000 x 1.2 | 19.6 |
2000 x 1000 x 3.0 | 49.6 | 2500 x1250 x 1.2 | 30.7 |
2500 x 1250 x 3.0 | 77.5 | 3000 x1500 x 1.2 | 44.2 |
3000 x 1500 x 3.0 | 112.0 | 2000 x1000 x 1.5 | 24.6 |
Gauge Number | Inches | MM |
---|---|---|
8 | .17187 | 4.365 |
10 | .14062 | 3.571 |
9 | .15625 | 3.968 |
11 | .125 | 3.175 |
14 | .07812 | 1.984 |
12 | .10937 | 2.778 |
16 | .0625 | 1.587 |
20 | .0375 | .9525 |
18 | .050 | 1.270 |
22 | .03125 | .7937 |
30 | .0125 | .3175 |
26 | .01875 | .476 |
24 | .025 | .635 |
28 | .01562 | .396 |
Product | Thickness MM | Finish | Max Sheet Size MM |
---|---|---|---|
Grade 304 | 0.9 | Plain 2B | 2000 x 1000 |
Bright | 2000 x 1000 | 0.9 | |
Brushed Finish | 2000 x 1000, 2500 x 1250 | 0.9, 1.2 | |
Rimex Super Mirror | 2400 x 1200, 2500 x 1250 | 0.8, 1.2 | |
Embossed | 2500 x 1250 | 0.8, 1.0 |
Hole Centres mm | Hole Dia mm | Tck mm | O/A | Full Sheet Size mm | Finish |
---|---|---|---|---|---|
1.5 | 0.75 | 0.6 | 23% | 2000 x 1000 | 2B |
2 | 1 | 1.0 | 23% | 2000 x 1000 | 2B |
2.6 | 1.5 | 1.0 | 30% | 2000 x 1000 | 2B |
3.5 | 2 | 1.0 | 30% | 2000 x 1000 | 2B |
3.5 | 2 | 1.0 | 30% | 2000 x 1000 | 2B |
5 | 3 | 1.0 | 33% | 2000 x 1000 | 2B |
5.6 | 4 | 1.0 | 46% | 2000 x 1000 | 2B |
8 | 5 | 1.0 | 35% | 2000 x 1000 | 2B |
8 | 6 | 1.0 | 51% | 2000 x 1000 | 2B |
10 | 8 | 1,0 | 58% | 2000 x 1000 | 2B |
316 Stainless Steel Plate Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
---|---|---|---|---|---|---|
kg/m² | lbs/ft² | kg | lbs | |||
0.381 mm | 0.015 inches | 36 x 96 | 3.07566 | 0.630 | 6.84936 | 15.12 |
0.381 mm | 0.015 inches | 36 x 120 | 3.07566 | 0.630 | 8.5617 | 18.90 |
0.45212 mm | 0.0178 inches | 36 x 96 | 3.690792 | 0.756 | 8.22195 | 18.15 |
0.45212 mm | 0.0178 inches | 36 x 120 | 3.690792 | 0.756 | 10.27404 | 22.68 |
0.45212 mm | 0.0178 inches | 48 x 96 | 3.690792 | 0.756 | 10.95807 | 24.19 |
0.45212 mm | 0.0178 inches | 48 x 120 | 3.690792 | 0.756 | 13.69872 | 30.24 |
0.5969 mm | 0.0235 inches | 30 x 96 | 4.921056 | 1.008 | 9.13248 | 20.16 |
0.5969 mm | 0.0235 inches | 30 x 120 | 4.921056 | 1.008 | 11.4156 | 25.20 |
0.5969 mm | 0.0235 inches | 36 x 96 | 4.921056 | 1.008 | 10.95807 | 24.19 |
0.5969 mm | 0.0235 inches | 36 x 120 | 4.921056 | 1.008 | 13.69872 | 30.24 |
0.5969 mm | 0.0235 inches | 36 x 144 | 4.921056 | 1.008 | 16.43937 | 36.29 |
0.5969 mm | 0.0235 inches | 48 x 96 | 4.921056 | 1.008 | 14.61378 | 32.26 |
0.5969 mm | 0.0235 inches | 48 x 120 | 4.921056 | 1.008 | 18.26496 | 40.32 |
0.5969 mm | 0.0235 inches | 48 x 144 | 4.921056 | 1.008 | 21.92067 | 48.39 |
0.73914 mm | 0.0291 inches | 30 x 96 | 6.15132 | 1.260 | 11.4156 | 25.20 |
0.73914 mm | 0.0291 inches | 30 x 120 | 6.15132 | 1.260 | 14.2695 | 31.50 |
0.73914 mm | 0.0291 inches | 36 x 96 | 6.15132 | 1.260 | 13.69872 | 30.24 |
0.73914 mm | 0.0291 inches | 36 x 120 | 6.15132 | 1.260 | 17.1234 | 37.80 |
0.73914 mm | 0.0291 inches | 36 x 144 | 6.15132 | 1.260 | 20.55261 | 45.37 |
0.73914 mm | 0.0291 inches | 48 x 96 | 6.15132 | 1.260 | 18.26496 | 40.32 |
0.73914 mm | 0.0291 inches | 48 x 120 | 6.15132 | 1.260 | 22.83573 | 50.41 |
0.73914 mm | 0.0291 inches | 48 x 144 | 6.15132 | 1.260 | 27.40197 | 60.49 |
0.9017 mm | 0.0355 inches | 30 x 96 | 7.381584 | 1.512 | 13.69872 | 30.24 |
0.9017 mm | 0.0355 inches | 30 x 120 | 7.381584 | 1.512 | 17.1234 | 37.80 |
0.9017 mm | 0.0355 inches | 36 x 96 | 7.381584 | 1.512 | 16.43937 | 36.29 |
HS Code | Description | Unit |
---|---|---|
72193320 | EX STOCK STAINLESS STEEL SHEETS GRADE 316/316L(1MM to less than 3MM) | KGS |
Thickness | Density in g/cm³ | Plate Weight per Unit Area ( kg/m²) |
---|---|---|
7/8 Inches | 0.315 lbs/in³8.72 | 0.274 lbs/in²192.6410704 |
3/16 Inches | 0.315 lbs/in³8.72 | 0.06000 lbs/in²42.184176 |
1 Inches | 0.315 lbs/in³8.72 | 0.313 lbs/in²220.0607848 |
1/4 Inches | 0.315 lbs/in³8.72 | 0.08 lbs/in²56.245568 |
1 1/4 Inches | 0.315 lbs/in³8.72 | 0.391 lbs/in²274.9002136 |
3/8 Inches | 0.315 lbs/in³8.72 | 0.121 lbs/in²85.0714216 |
1 1/2 Inches | 0.315 lbs/in³8.72 | 0.47 lbs/in²330.442712 |
1/2 Inches | 0.315 lbs/in³8.72 | 0.161 lbs/in²113.1942056 |
2 Inches | 0.315 lbs/in³8.72 | 0.627 lbs/in²440.8246392 |
5/8 Inches | 0.315 lbs/in³8.72 | 0.196 lbs/in²137.8016416 |
2 1/2 Inches | 0.315 lbs/in³8.72 | 0.784 lbs/in²551.2065664 |
3/4 Inches | 0.315 lbs/in³8.72 | 0.235 lbs/in²165.221356 |
1 3/4 Inches | 0.315 lbs/in³8.72 | 0.549 lbs/in²385.9852104 |
2 1/4 Inches | 0.315 lbs/in³8.72 | 0.705 lbs/in²495.664068 |
2 3/4 Inches | 0.315 lbs/in³8.72 | 0.862 lbs/in²606.0459952 |
3 Inches | 0.315 lbs/in³8.72 | 0.941 lbs/in²661.5884936 |
316 Grade Stainless Steel Product | Thickness | Width | Length | 16 Gauge 316 Stainless Steel Sheet Price |
---|---|---|---|---|
COLD ROLLED STAINLESS WIDE SHEETS(HAVING NI>8%) 2.667MMX1219.200MMX3048-316L-AMS/2B/TRIM EDGE.F.P.SSWIDTOF600MM | 0.002 | 6 | 50 | $22.10 / each |
0.5mm-3mm thick 10K 8K Mirror 316 stainless sheet | 0.004 | 6 | 50 | $49.92 / each |
Hot Sale 2mm Cold Rolled SS Plate Aisi 316 Stainless Sheet | 0.003 | 6 | 50 | $25.78 / each |
HOT ROOLED STAINLESS WIDE SHEETS(HAVING >8%)12.700MMX1524MMX3048 -316L-AMS/NO1/TRIMEDGE FR.PR.SS. 600 MM | 0.002 | 6 | 50 | $45.99 / each |
2mm 6mm 10mm Thick 316 Stainless Sheet Plate for Sale | 0.003 | 6 | 50 | $47.74 / each |
316 STAINLESS SHEETS SIZE 6 X 5MMTHICKNESS | 0.002 | 6 | 100 | $31.58 / each |
316 Hot Rolled Stainless 3mm 4mm 6mm 12mm Thickness Coil | 0.003 | 6 | 100 | $39.27 / each |
316 STAINLESS SHEETS SIZE 6 X 4MMTHICKNESS 1.25X 25 X 4MM | 0.002 | 6 | 100 | $82.96 / each |
STAINLESS INSULATION JACKETING (STAINLES SS316L ,2B FINISH CORRUGATED SHEET 0.50 MM DETAILS AS PER INV | 0.002 | 12 | 50 | $39.27 / each |
Cold Rolled 2mm Thick 316 Stainless Sheet Price | 0.003 | 12 | 50 | $78.14 / each |
STAINLESS SHEET GUILLOTINED EDGES.316 NUMBER 2BA FINISH 1000MM X 500MM X1.2MM THK | 0.002 | 12 | 50 | $71.47 / each |
High Quality 2mm 316 Stainless Sheet/ Plate | 0.004 | 6 | 50 | $31.20 / each |
Hot Sale 2mm Cold Rolled SS Plate Aisi 316 Stainless Sheet Plate | 0.004 | 6 | 100 | $46.45 / each |
Ss 316 Sheet 2b SS | SS 316 Plate |
SS 316 Perforated Sheet | ASTM A240 316 SS Expanded Metal |
SS 316 Sheet Metal | 316 SS Foil |
SA240 316 SS Sheet | SS 316 Mesh Sheet |
316 SS Plate | AISI 316 EN 1.4401 Ss Hot Rolled Plate |
2mm 316 SS Sheet | SS Grade 316 Data Sheet |
Stainless Hairline 316 Sheet | SS 316 Hairline Finish Plate |
316 SS Plate For Sale | 316 Marine Grade SS Sheet |
SS 316 2b Finish SS Sheet | 316 SS 2b Finish |
18 Gauge 316 SS Sheet | 20 Gauge 316 SS Sheet |
SA240 Tp316 SS Perforated Sheet | 3mm 316 SS Sheet |
316 SS Sheet Metal | SS 316 Plate |
316 Grade SS Plate | 316 SS Perforated Sheet |
SS 316 Hairline Finish Sheet | Brushed 316 SS Sheet |
SS 316 Sheet | AISI 316 SS Sheet |
ASTM A240 TP316 SS Diamond Plate | UNS S31600 Ss Hot Rolled Plate |
