What Is Stainless Steel 304 Plate Vs 304 Sheet
Plates and sheets are used interchangeably across the 304 grade. The components can be distinguished based on their thickness.
Can ASTM A240 304 Stainless Steel Plate Rust?
All grades of steel rust when exposed to different chemical constituents over a period of time. The 304 plates are designed with a superior content of 18% chromium and 8% of nickel, giving them good resistance to rust and reducing media. The plates in this grade are; however, susceptible to pitting in marine environments.
What Are Different Finishes of Stainless Steel 304 Perforated Sheet
The perforated sheet of the 304 grade is designed in a range of surface finish to add aesthetical value and offer good tolerance. The most common finishes are anodizing, galvanizing, and powder finish. The sheets can also have a mirror or cold rolled finish along with some other finishes.
How to Calculate Weight of 304 2b Stainless Steel Plate
To calculate the weight of the 304 2b stainless steel plate you’ll need to know the length, width, density, and thickness of the module.
Now Width X Length X Thickness X Density = Weight.
48 X 96 X 0.1875″ X 0.289 lb/in3 = 250 lb
Table of Content
Specifications | ASTM / ASME A240/ SA240 |
---|---|
18 Gauge 304 Stainless Steel Standard | EN, GB, JIS, AISI, ASTM, DIN, etc |
304 Stainless Steel Sheet Thickness | From 4mm to 100mm |
Stainless Hairline 304 Width | 1000mm, 1500mm, 1219mm, 3500mm, 2000mm, 1800mm, 2500mm, 3000mm, etc |
Surface | 2D, 2B,BA, NO.4, NO.1, NO.8, mirror, 8K, checkered, hair line, embossed, sand blast, etching, brush, etc |
Lengt of 304 Stainless Steel Sheet Suppliers In Indiah | 6000mm, 2440mm, 5800mm, 3000mm, 2000mm, etc |
Finish | Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Hot rolled plate (HR) |
Package of 304 Stainless Steel Sheet Manufacturers In India | Export standard package |
AISI 304 EN 1.4301 Plate Manufacturer: | Acerinox, Baosteel, Aperam, Thyssenkrup, TISCO, POSCO, Jindal Stainless, Nippon Metal, DKC Korea, Arcelor Mittal, Nas, Sail, Outokumpu |
Form | Foils, Coils, Rolls, Shim Sheet, Plain Sheet, Perforated Sheet, Strip, Blank (Circle), Chequered Plate 304 Stainless Steel Sheet Distributors and Suppliers |
Grade | S | C | Cr | Mn | Mo | Si | Ni | P | N |
---|---|---|---|---|---|---|---|---|---|
SS 304 | 0.030 max | 0.08 max | 18 – 20 | 2 max | – | 0.75 max | 8 – 11 | 0.045 max | – |
Density | Tensile Strength | Melting Point | Elongation | Yield Strength (0.2%Offset) |
---|---|---|---|---|
8.0 g/cm3 | Psi – 75000 , MPa – 515 | 1400 °C (2550 °F) | 35 % | Psi – 30000 , MPa – 205 |
STANDARD | BS | WERKSTOFF NR. | GOST | UNS | AFNOR | JIS | EN |
---|---|---|---|---|---|---|---|
Stainless Steel 304 Hairline Finish | 304S31 | 1.4301 | 08Х18Н10 | S30400 | Z7CN18‐09 | SUS 304 | X5CrNi18-10 |
Melting Point | Specific Gravity | Density | Modulus of Elasticity in Tension |
---|---|---|---|
2550-2590° F 1399-1421° C |
7.90 | .285 lb/in³ 7.90 g/cm³ |
29 X 106 psi 200 Gpa |
Sheet/Plate | ||||
---|---|---|---|---|
Stainless Steel Sheet / Plate | Cold Rolled | Spec. Thickness, in. | Thickness Tol. | |
Widths over 40" & ≤ 50" | Widths ≤ 40" | |||
0.012 | +/- 0.0015" | +/- 0.001" | ||
0.016 | +/- 0.0015" | +/- 0.0015" | ||
0.020 | +/- 0.002" | +/- 0.0015" | ||
0.024 | +/- 0.002" | +/- 0.002" | ||
0.032 | +/- 0.0025" | +/- 0.002" | ||
0.040 | +/- 0.003" | +/- 0.0025" | ||
0.047 | +/- 0.003" | +/- 0.003" | ||
0.059 | +/- 0.004" | +/- 0.003" | ||
0.079 | +/- 0.004" | +/- 0.004" | ||
0.098 | +/- 0.005" | +/- 0.004" | ||
0.118 | +/- 0.007" | +/- 0.005" | ||
0.157 | +/- 0.007" | +/- 0.007" | ||
0.197 | +/- 0.008" | +/- 0.007" | ||
0.236 | +/- 0.009" | +/- 0.007" | ||
0.3125 | +/- 0.007" |
CTE, linear 20°C | 9.61 µin/in-°F | 17.3 µm/m-°C | from 0-100°C |
CTE, linear 250°C | 9.89 µin/in-°F | 17.8 µm/m-°C | at 0-315°C (32-600°F) |
CTE, linear 500°C | 10.4 µin/in-°F | 18.7 µm/m-°C | at 0-650°C |
Specific Heat Capacity | 0.12 BTU/lb-°F | 0.5 J/g-°C | from 0-100°C (32-212°F) |
Thermal Conductivity | 112 BTU-in/hr-ft²-°F | 16.2 W/m-K | at 0-100°C, 21.5 W/m°C at 500°C |
Melting Point | 2550 - 2650 °F | 1400 - 1455 °C | |
Solidus | 2550 °F | 1400 °C | |
Liquidus | 2650 °F | 1455 °C |
Rockwell Hardness Number A Scale, 60 Kgf (HRA) | Rockwell Hardness Number B Scale, 100 Kgf (HRB) | Rockwell Superficial Hardness No. 30T Scale, 30 Kgf (30T) | Rockwell Superficial Hardness No. 15T Scale, 15 Kgf (15T) | Rockwell Superficial Hardness No. 45T Scale, 45 Kgf (45T) |
---|---|---|---|---|
61.5 | 100 | 80.4 | 91.5 | 70.2 |
60.9 | 99 | 79.7 | 91.2 | 69.2 |
60.3 | 98 | 79 | 90.8 | 68.2 |
59.7 | 97 | 78.3 | 90.4 | 67.2 |
59.1 | 96 | 77.7 | 90.1 | 66.1 |
58.5 | 95 | 77 | 89.7 | 65.1 |
58 | 94 | 76.3 | 89.3 | 64.1 |
57.4 | 93 | 75.6 | 88.9 | 63.1 |
56.8 | 92 | 74.9 | 88.6 | 62.1 |
56.2 | 91 | 74.2 | 88.2 | 61.1 |
55.6 | 90 | 73.5 | 87.8 | 60.1 |
55 | 89 | 72.8 | 87.5 | 59 |
54.5 | 88 | 72.1 | 87.1 | 58 |
53.9 | 87 | 71.4 | 86.7 | 57 |
53.3 | 86 | 70.7 | 86.4 | 56 |
52.7 | 85 | 70 | 86 | 55 |
52.1 | 84 | 69.3 | 85.6 | 54 |
51.5 | 83 | 68.6 | 85.2 | 52.9 |
50.9 | 82 | 67.9 | 84.9 | 51.9 |
50.4 | 81 | 67.2 | 84.5 | 50.9 |
49.8 | 80 | 66.5 | 84.1 | 49.9 |
Gauge Number | Inches | MM |
---|---|---|
8 | .17187 | 4.365 |
10 | .14062 | 3.571 |
9 | .15625 | 3.968 |
11 | .125 | 3.175 |
14 | .07812 | 1.984 |
12 | .10937 | 2.778 |
16 | .0625 | 1.587 |
20 | .0375 | .9525 |
18 | .050 | 1.270 |
22 | .03125 | .7937 |
30 | .0125 | .3175 |
26 | .01875 | .476 |
24 | .025 | .635 |
28 | .01562 | .396 |
Surface Finish | Definition | Application |
---|---|---|
NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank |
HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
304 Stainless Steel Sheet Thickness Chart | Stainless Steel Grade 304 Thickness | 304 Stainless Steel Sheet Cut To Size | Surface Area per Unit weight | Approx Weight per Sheet | ||
---|---|---|---|---|---|---|
mm | inches | kg/m² | lbs/ft² | kg | lbs | |
0.381 | 0.015 | 36 x 96 | 3.07566 | 0.630 | 6.84936 | 15.12 |
0.381 | 0.015 | 36 x 120 | 3.07566 | 0.630 | 8.5617 | 18.90 |
0.45212 | 0.0178 | 36 x 96 | 3.690792 | 0.756 | 8.22195 | 18.15 |
0.45212 | 0.0178 | 36 x 120 | 3.690792 | 0.756 | 10.27404 | 22.68 |
0.45212 | 0.0178 | 48 x 96 | 3.690792 | 0.756 | 10.95807 | 24.19 |
0.45212 | 0.0178 | 48 x 120 | 3.690792 | 0.756 | 13.69872 | 30.24 |
0.5969 | 0.0235 | 30 x 96 | 4.921056 | 1.008 | 9.13248 | 20.16 |
0.5969 | 0.0235 | 30 x 120 | 4.921056 | 1.008 | 11.4156 | 25.20 |
0.5969 | 0.0235 | 36 x 96 | 4.921056 | 1.008 | 10.95807 | 24.19 |
0.5969 | 0.0235 | 36 x 120 | 4.921056 | 1.008 | 13.69872 | 30.24 |
0.5969 | 0.0235 | 36 x 144 | 4.921056 | 1.008 | 16.43937 | 36.29 |
0.5969 | 0.0235 | 48 x 96 | 4.921056 | 1.008 | 14.61378 | 32.26 |
0.5969 | 0.0235 | 48 x 120 | 4.921056 | 1.008 | 18.26496 | 40.32 |
0.5969 | 0.0235 | 48 x 144 | 4.921056 | 1.008 | 21.92067 | 48.39 |
0.73914 | 0.0291 | 30 x 96 | 6.15132 | 1.260 | 11.4156 | 25.20 |
0.73914 | 0.0291 | 30 x 120 | 6.15132 | 1.260 | 14.2695 | 31.50 |
0.73914 | 0.0291 | 36 x 96 | 6.15132 | 1.260 | 13.69872 | 30.24 |
0.73914 | 0.0291 | 36 x 120 | 6.15132 | 1.260 | 17.1234 | 37.80 |
0.73914 | 0.0291 | 36 x 144 | 6.15132 | 1.260 | 20.55261 | 45.37 |
0.73914 | 0.0291 | 48 x 96 | 6.15132 | 1.260 | 18.26496 | 40.32 |
0.73914 | 0.0291 | 48 x 120 | 6.15132 | 1.260 | 22.83573 | 50.41 |
0.73914 | 0.0291 | 48 x 144 | 6.15132 | 1.260 | 27.40197 | 60.49 |
0.9017 | 0.0355 | 30 x 96 | 7.381584 | 1.512 | 13.69872 | 30.24 |
0.9017 | 0.0355 | 30 x 120 | 7.381584 | 1.512 | 17.1234 | 37.80 |
0.9017 | 0.0355 | 36 x 96 | 7.381584 | 1.512 | 16.43937 | 36.29 |
Product | Stainless Steel 304 Sheet Thickness MM | Finish | Max Sheet Size MM |
---|---|---|---|
Grade 304 | 0.9 | Plain 2B | 2000 x 1000 |
Bright | 2000 x 1000 | 0.9 | |
Brushed Finish | 2000 x 1000, 2500 x 1250 | 0.9, 1.2 | |
Rimex Super Mirror | 2400 x 1200, 2500 x 1250 | 0.8, 1.2 | |
Embossed | 2500 x 1250 | 0.8, 1.0 |
Hole Centres mm | Hole Dia mm | Tck mm | O/A | Full Sheet Size mm | Finish |
---|---|---|---|---|---|
1.5 | 0.75 | 0.6 | 23% | 2000 x 1000 | 2B |
2 | 1 | 1.0 | 23% | 2000 x 1000 | 2B |
2.6 | 1.5 | 1.0 | 30% | 2000 x 1000 | 2B |
3.5 | 2 | 1.0 | 30% | 2000 x 1000 | 2B |
3.5 | 2 | 1.0 | 30% | 2000 x 1000 | 2B |
5 | 3 | 1.0 | 33% | 2000 x 1000 | 2B |
5.6 | 4 | 1.0 | 46% | 2000 x 1000 | 2B |
8 | 5 | 1.0 | 35% | 2000 x 1000 | 2B |
8 | 6 | 1.0 | 51% | 2000 x 1000 | 2B |
10 | 8 | 1,0 | 58% | 2000 x 1000 | 2B |
Size (mm) | Weight Of Stainless Steel Sheet 304 per (Kg) |
Size (mm) | Weight per sheet (Kg) |
---|---|---|---|
2500 x 1250 x 1.5 | 38.4 | 2000 x1000 x 0.7 | 11.5 |
3000 x 1500 x 1.5 | 55.3 | 2500 x1250 x 0.7 | 17.9 |
2000 x 1000 x 2.0 | 32.7 | 2000 x1000 x 0.9 | 14.7 |
2500 x 1250 x 2.0 | 51.2 | 2500 x1250 x 0.9 | 23.0 |
3000 x 1500 x 2.0 | 73.7 | 2000 x1000 x 1.0 | 16.4 |
2000 x 1000 x 2.5 | 40.9 | 2500 x1250 x 1.0 | 25.6 |
2500 x 1250 x 2.5 | 63.9 | 3000 x1500 x 1.0 | 36.8 |
3000 x 1500 x 2.5 | 92.1 | 2000 x1000 x 1.2 | 19.6 |
2000 x 1000 x 3.0 | 49.6 | 2500 x1250 x 1.2 | 30.7 |
2500 x 1250 x 3.0 | 77.5 | 3000 x1500 x 1.2 | 44.2 |
3000 x 1500 x 3.0 | 112.0 | 2000 x1000 x 1.5 | 24.6 |
Thickness in Inches | Density in g/cm³ | Plate Weight per Unit Area ( kg/m²) |
---|---|---|
7/8 | 0.315 lbs/in³8.72 | 0.274 lbs/in²192.6410704 |
3/16 | 0.315 lbs/in³8.72 | 0.06000 lbs/in²42.184176 |
1 | 0.315 lbs/in³8.72 | 0.313 lbs/in²220.0607848 |
1/4 | 0.315 lbs/in³8.72 | 0.08 lbs/in²56.245568 |
1 1/4 | 0.315 lbs/in³8.72 | 0.391 lbs/in²274.9002136 |
3/8 | 0.315 lbs/in³8.72 | 0.121 lbs/in²85.0714216 |
1 1/2 | 0.315 lbs/in³8.72 | 0.47 lbs/in²330.442712 |
1/2 | 0.315 lbs/in³8.72 | 0.161 lbs/in²113.1942056 |
2 | 0.315 lbs/in³8.72 | 0.627 lbs/in²440.8246392 |
5/8 | 0.315 lbs/in³8.72 | 0.196 lbs/in²137.8016416 |
2 1/2 | 0.315 lbs/in³8.72 | 0.784 lbs/in²551.2065664 |
3/4 | 0.315 lbs/in³8.72 | 0.235 lbs/in²165.221356 |
1 3/4 | 0.315 lbs/in³8.72 | 0.549 lbs/in²385.9852104 |
2 1/4 | 0.315 lbs/in³8.72 | 0.705 lbs/in²495.664068 |
2 3/4 | 0.315 lbs/in³8.72 | 0.862 lbs/in²606.0459952 |
3 | 0.315 lbs/in³8.72 | 0.941 lbs/in²661.5884936 |
HS Code | Description | Unit |
---|---|---|
72199013 | COLD ROLLED STAINLESS STEEL SHEET, GRADE SUS304, TRIMMED EDGE, NO.8+GOLD FINISH (0.8x1260x2500MM) | KGS |
We provide Multiple Payment Options Of SS 304 Material Price, Contact us today for Buy 304 Grade Stainless Steel Plate, Stainless Steel 304 Sheet Price Per Kg In India before
Products | Thickness | Width | Length | 304 SS Sheet Price in USD |
---|---|---|---|---|
HOT ROLLED STAINLESS STEEL WIDE SHEETS(HAVING NI>8%) 6.350MMX1219.200MMX2438.400-304-AMS/NO1/TRIM EDGE.FPSWIDT600MM | 0.002 in | 12 in | 10 ft | $31.31/ each |
COLD ROLLED STAINLESS STEEL WIDE SHEETS(HAVING NI>8%) 3.429MMX1524MMX3048 -304-AMS/2B/TRIM EDGE.FR.PR.SSWIDTOF600MM | 0.002 in | 12 in | 25 ft | $58.76/ each |
STAINLESS STEEL CR COILS/ SHEETS PRIME QUALITY SPEC. 1.500MM X 1000MM X COIL- 304/2B/ TRIM EDGE | 0.002 in | 12 in | 50 ft | $93.13/ each |
HOT ROLLED STAINLESS STEEL WIDE PLATES (HAVING NI>8%) 12.700MMX1219.200MMX3048 -304-AMS/NO1/TRIM EDGE.FPSWIDT600MM | 0.002 in | 12 in | 100 ft | $173.57/ each |
STAINLESS STEEL PLATE TO ASTM A 240 GR.TP 304, COLD ROLLED, 2B FINISH SIZE: 500 MM x 500 MM x 9 MM THK | 0.002 in | 24 in | 10 ft | $48.24/ each |
S.S. 304 PLATE SIZE:16 MM THK X 2 MTRSX 6 MTRS | 0.002 in | 24 in | 25 ft | $97.55/ each |
SS 304 SHEET CR 3 MM | 0.002 in | 24 in | 50 ft | $184.03/ each |
SS 304 SHEET JINDAL | 0.002 in | 24 in | 100 ft | $345.05/ each |
Stainless Steel 304 Sheet | 304 Stainless Steel Baking Sheet |
Stainless Steel 304 Plate | 304 Stainless Steel Sheet #4 Brushed Finish |
ASTM A240 Tp304 Stainless Steel Foil | 304 Brushed Stainless Steel Sheet |
Ss 304 2b Finish | 304 Grade Stainless Steel Material |
ASME SA240 304 2b Stainless Steel Sheet | Stainless Steel 304 Data Sheet |
18 Gauge 304 Stainless Steel Sheet | 20 Gauge 304 Stainless Steel Sheet |
Stainless 304 2b Coil | Stainless Steel 304 Flat Sheet |
AISI 304 EN 1.4301 Plate | Stainless Steel Sheet 304 2b Finish |
SS 304 2B Finish Sheet | 304 Stainless Steel Sheet Finishes |
ASTM A240 Grade 304 Plate | 304 Stainless Steel Sheet Mirror Finish |
SS 304 Hairline Finish | Brushed 304 Stainless Steel Sheet |
Stainless Steel 304 Perforated Sheet | Brushed 304 Stainless Steel Plate |
Stainless Steel Sheet 2b Finish | 304 Stainless Steel Perforated Sheet |
A240 Tp 304 2b Stainless Steel Plate | 14 Gauge 304 Stainless Steel Sheet |
ASTM A240 304 Stainless Steel Plate | 304 Stainless Steel Sheet #8 Mirror |
Aisi 304 Ba Stainless Steel Sheet | Stainless Steel 304 Perforated Sheet |
Stainless Hairline 304 Plate | Stainless Steel 304 Hairline Finish |
304 Bright Annealed Stainless Steel Sheet | 304 Stainless Steel Sheet Roll |
SS 304 Perforated Sheet | SS 304 Plate |
Shim Plate SS 304 | SS 304 Mirror Finish |
Searching for
ASTM A240 Tp304 Stainless Steel Sheets Manufacturer in your country? Checklist of material we export in the following areas.
ASTM A240 Tp304 Stainless Steel Foil
Bangladesh, Jakarta -Indonesia, Dubai, Los Alamos -Mexico, Hong Kong, Turkey, Argentina, Germany, China, Oman, Saudi Arabia (KSA).
ASME Sa240 304 2b Stainless Steel Sheet
Malaysia, Poland, Romania, Indonesia, Malaysia, Iran, Qatar, New Zealand, Brazil, Netherlands, United Arab Emirates (UAE).
SS 304 Coil
USA, Chile, Ellington -United States, Canada, Sweden, United States, Greece, Singapore, Vietnam, Mexico, Denmark, Thailand, Finland.
AISI 304 Plate
Russia, Belgium, Norway, Egypt, Bahrain, Philippines, South Korea, Peru, Malaysia, Tehran -Iran, Colombia, Italy.
304 Ss Material
Spain, Jakarta, Europe, Australia, Jordan, Dammam -KSA, Japan, Istanbul -Turkey, NY 12203 (USA), Dubai -UAE, Kuala Lumpur.
20 Gauge 304 Stainless Steel Sheet
France, Singapore, Taiwan, South Africa, Portugal, Morocco, Czechia, Kuwait, Austria, United Kingdom (UK), Nigeria.
