Stainless Steel Square Bar vs Rod
Stainless steel square bars and rods are versatile components designed with aneven cross-sectional area. These bars can be used interchangeably and can be differentiated on certain key features.
What is 304 and 316 Stainless Steel Square Bar?
Stainless steel 304 and 316 are common grades used to manufacture stainless steel square bars. Both these grades can be distinguished on key features.
Is Stainless Steel Rectangular Hollow Bar magnetic?
Stainless steel rectangular hollow bar can be magnetic if its meets certain requirements.
Cold Drawn vs Hot RolledStainless Steel Square Bars
Stainless steel square bars are designed in the hot and cold rolled process. Both these versatile processes can be distinguished from key features.
Grade List | All Grades |
---|---|
Bar Finishing | Polish, Bright, Square Round Bar |
Otder Services | Centreless Grinding, Machining, Bending, Heat Treatment, Rolling, Polish, Anneling, Forging, Pickling, Cutting |
Produtcs | Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS | Price in INR | Price in UAE Dirham | Price in USD |
---|---|---|---|---|---|---|
STAINLESS STEEL BRIGHT SQUARE BARS GRADE: AISI 304L ( 22 MM ) | 16 | 0.62 | 2.05 | 164 | 8.06 UAE Dirham | $2.19 |
BRIGHT STEEL BARS MADE OUT OF STAINLESSSTEEL STAINLESS STEEL SQUARE BARS, BRIGHT POLISHED, BUFFED FINISH, WITHOUT OIL O | 18 | 0.79 | 2.59 | 165 | 8.11 UAE Dirham | $2.21 |
STAINLESS STEEL BRIGHT BARS SHAPE : SQUARE GRADE : AISI 304L/1.4307 ( 20 MM ) | 20 | 0.76 | 2.49 | 141 | 6.93 UAE Dirham | $1.89 |
STAINLESS STEEL ROD/BAR SQUARE PART NO:ASGRCS1059RM0115-5PH AMS 5659 2.00X2.00 (QTY:50 PCS, NET WT:977.00 LBS) | 22 | 1.18 | 3.87 | 1,131 | 55.59 UAE Dirham | $15.13 |
(FOC ITEM) STAINLESS STEEL SQUARE BAR (3 PCS) | 25 | 1.52 | 5.00 | 1,109 | 54.51 UAE Dirham | $14.84 |
STAINLESS STEEL BARS SQUARE DRAWN 1.4404/316L QUENCHED EN10278 H11 22.00 DEG REASED LENGTH 3000+200 MM | 28 | 1.91 | 6.27 | 245 | 12.04 UAE Dirham | $3.28 |
ST ST SQ BAR 15-5 PH 2.00X2.00 (STAINLESS STEEL SQUARE BARASGRCS1059RM01, DIM:L16IN, NET WT:199.177 LBS, QTY:11 PCS) | 30 | 2.19 | 7.20 | 936 | 46.00 UAE Dirham | $12.52 |
Heading Codes | Heading Description |
---|---|
7222 | Harmonized Syestem Codes Of Other Bars And Square Bars Of SS; Angles, Shapes And Sections Of Stainless Steel First Six Digits HSN Code SS Square Bar |
Imperial SS Square Bar | 1/4″, 5/16″, 3/8″ 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/4″, 1 1/2″, 1 3/4″, 2”, 4″ |
---|---|
Metric Stainless Steel Square bar | 6mm, 8mm, 10mm , 12mm, 13mm, 14mm, 15mm, 16mm, 18mm, 20mm, 22mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 120mm, 150mm |
SQUARES | ||
---|---|---|
Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
16 | 0.62 | 2.05 |
18 | 0.79 | 2.59 |
20 | 0.76 | 2.49 |
22 | 1.18 | 3.87 |
25 | 1.52 | 5.00 |
28 | 1.91 | 6.27 |
30 | 2.19 | 7.20 |
32 | 2.50 | 8.19 |
36 | 3.16 | 10.37 |
38 | 3.52 | 11.55 |
40 | 3.90 | 12.80 |
45 | 4.94 | 16.20 |
50 | 6.10 | 20.00 |
56 | 7.65 | 25.08 |
60 | - | - |
65 | - | - |
70 | - | - |
75 | - | - |
80 | - | - |
90 | - | - |
100 | - | - |
Width X Depth | Width X Depth | Width X Depth |
---|---|---|
milimeter | milimeter | milimeter |
5X5 | 20X20 | 48X48 |
4X4 | 19X19 | 45X45 |
7X7 | 22X22 | 53X53 |
6X6 | 21X21 | 50X50 |
9X9 | 25X25 | 60X60 |
8X8 | 24X24 | 56X56 |
11X11 | 28X28 | 67X67 |
10X10 | 26X26 | 63X63 |
13X13 | 32X32 | 75X75 |
12X12 | 30X30 | 70X70 |
15X15 | 35X35 | 85X85 |
14X14 | 34X34 | 80X80 |
17X17 | 40X40 | 95X95 |
16X16 | 38X38 | 90X90 |
18X18 | 42X42 | 100X100 |
Stainless Steel Square Bar Size and Theoretical Weight | |||||||
---|---|---|---|---|---|---|---|
Weight (kilogram/m) | Size (milimeter) | Weight (kilogram/m) | Size (milimeter) | Weight (kilogram/m) | Size (milimeter) | Weight (kilogram/m) | Size (milimeter) |
1.0784 | 15 × 15 | 0.0071 | 3 × 3 | 28.0548 | 60 × 60 | 7.0137 | 30 × 30 |
2.003 | 16 × 16 | 0.0127 | 4 × 4 | 31.0474 | 63 × 63 | 8.012 | 32 × 32 |
2.0292 | 17 × 17 | 0.0198 | 5 × 5 | 35.0598 | 67 × 67 | 9.0167 | 34 × 34 |
2.0569 | 18 × 18 | 0.0285 | 6 × 6 | 38.0857 | 70 × 70 | 9.0714 | 35 × 35 |
2.0863 | 19 × 19 | 0.0389 | 7 × 7 | 44.0606 | 75 × 75 | 11.0451 | 38 × 38 |
3.0172 | 20 × 20 | 0.0508 | 8 × 8 | 50.0752 | 80 × 80 | 12.0688 | 40 × 40 |
3.0497 | 21 × 21 | 0.0642 | 9 × 9 | 52.0294 | 85 × 85 | 13.0989 | 42 × 42 |
3.0838 | 22 × 22 | 0.0793 | 10 × 10 | 64.0233 | 90 × 90 | 16.0058 | 45 × 45 |
4.0568 | 24 × 24 | 0.096 | 11 × 11 | 71.0568 | 95 × 95 | 18.0271 | 48 × 48 |
4.0956 | 25 × 25 | 1.0142 | 12 × 12 | 79.03 | 100 × 100 | 19.0825 | 50 × 50 |
5.0361 | 26 × 26 | 1.034 | 13 × 13 | 22.0275 | 53 × 53 | ||
6.0217 | 28 × 28 | 1.0554 | 14 × 14 | 24.0868 | 56 × 56 | ||
Siding × Siding × 0.000793 = Weight (kg) per meter |
Stainless Steel CF Tolerances | Plus | Minus |
---|---|---|
5/16″ to 1/2″ (exclusive) | 0.000 | 0.003 |
1/8″ to 5/16″ (exclusive) | 0.000 | 0.002 |
over 1″ to 2″ (inclusive) | 0.000 | 0.006 |
1/2″ to 1″ (inclusive) | 0.000 | 0.004 |
over 2″ to 3″ (inclusive) | 0.000 | 0.008 |
H&T | Hardened and tempered. |
---|---|
ANN | Annealed |
PH | Precipitation hardened. |
Stainless Steel Grade | S | Mn | Mo | C | Ti | Fe | Cr | P | N | Si | Ni | |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Stainless Steel 304 | minimum | 18.00 | 8.00 | |||||||||
maximum | 0.0030 | 2.00 | 0.008 | 20.00 | 0.0045 | 0.010 | 0.075 | 10.05 | ||||
304L | minimum | 18.00 | 8.00 | |||||||||
maximum | 0.0030 | 2.00 | 0.0030 | 20.00 | 0.0045 | 0.010 | 0.075 | 12.00 | ||||
304H | minimum | 0.004 | 18.00 | 8.00 | ||||||||
maximum | 0.0030 | 2.00 | 0.0010 | 20.00 | 0.0045 | 0.075 | 10.05 | |||||
Stainless Steel 310 | 0.0015 maximum | 2 maximum | 0.010 maximum | 0.0015 maximum | 24.000 26.000 | 0.0020 maximum | 54.07 minimum | 0.0015 maximum | 19.000 21.000 | |||
SS 310S | 0.0030 maximum | 2 maximum | 0.075 maximum | 0.008 maximum | 24.000 26.000 | 0.0045 maximum | 53.0095 minimum | 1.000 maximum | 19.000 21.000 | |||
Stainless Steel 310H | 0.0030 maximum | 2 maximum | 0.004 0.010 | 24.000 26.000 | 0.0045 maximum | 53.0885 minimum | 1.000 maximum | 19.000 21.000 | ||||
Stainless Steel 316 | minimum | 2.003.00 | 16.00 | 10.00 | ||||||||
maximum | 0.0030 | 2.00 | 0.0035 | 18.00 | 0.0045 | 0.075 | 14.00 | |||||
316L | minimum | 2.003.00 | 16.00 | 10.00 | ||||||||
maximum | 0.0030 | 2.00 | 0.0035 | 18.00 | 0.0045 | 0.075 | 14.00 | |||||
316TI | 0.0030 maximum | 10.000 14.000 | 0.075 maximum | 0.008 maximum | 16.000 18.000 | 0.0045 maximum | 2.00 maximum | 2.000 3.000 | ||||
Stainless Steel 317 | 0.0030 maximum | 2 maximum | 3.000 4.000 | 0.008 maximum | 57.0845 minimum | 18.000 20.000 | 0.0045 maximum | 1 maximum | ||||
SS 317L | 0.0030 maximum | 2.00 maximum | 3.000 4.000 | 0.0035 maximum | 57.089 minimum | 18.000 20.000 | 0.0045 maximum | 1.00 maximum | 11.000 15.000 | |||
SS 321 | 0.0030 maximum | 2.00 maximum | 0.008 maximum | 5(C+N) 0.070 maximum | 17.000 19.000 | 0.0045 maximum | 0.010 maximum | 1.00 maximum | 9.000 12.000 | |||
Stainless Steel 321H | 0.0030 maximum | 2.00 maximum | 0.004 0.010 | 4(C+N) 0.070 maximum | 17.000 19.000 | 0.0045 maximum | 0.010 maximum | 1.00 maximum | 9.000 12.000 | |||
347/ 347H | 0.0030 maximum | 2.00 maximum | 0.008 maximum | 17.000 20.000 | 0.0045 maximum | 1.00 maximum | 9.00013.000 | |||||
Stainless Steel 410 | minimum | 11.05 | ||||||||||
maximum | 0.0030 | 1.00 | 0.015 | 13.05 | 0.0040 | 1.000 | 0.075 | |||||
446 | minimum | 23.00 | 0.010 | |||||||||
maximum | 0.0030 | 1.05 | 0.02 | 30.00 | 0.0040 | 0.025 | 0.075 | 0.050 | ||||
Stainless Steel 904L | minimum | 4.000 | 19.00 | 0.010 | 23.000 | |||||||
maximum | 0.0035 | 2.000 | 5.000 | 0.020 | 23.00 | 0.0045 | 0.025 | 1.000 | 28.000 |
Stainless Steel Grade | Elongation | Density | Melting Point | Tensile Properties | Yield Properties |
---|---|---|---|---|---|
304H | 40 % | 8.0 g/centimeter3 | (2550 °F) 1400 °C | MPa 515, Psi 75000 | MPa 205, Psi 30000 |
Stainless Steel 304/ 304L | 35 % | 8.0 g/centimeter3 | (2550 °F) 1400 °C | MPa 515, Psi 75000 | MPa 205, Psi 30000 |
904L | 35 % | 7.95 g/centimeter3 | (2460 °F) 1350 °C | MPa 490, Psi 71000 | MPa 220, Psi 32000 |
306/ 316H | 35 % | 8.0 g/centimeter3 | (2550 °F) 1400 °C | MPa 515, Psi 75000 | MPa 205, Psi 30000 |
Stainless Steel 310 / 310S / 310H | 40 % | 7.9 g/centimeter3 | (2555 °F) 1402 °C | MPa 515, Psi 75000 | MPa 205, Psi 30000 |
316L | 35 % | 8.0 g/centimeter3 | (2550 °F) 1399 °C | MPa 515, Psi 75000 | MPa 205, Psi 30000 |
Stainless Steel 321 | 35 % | 8.0 g/centimeter3 | (2650 °F) 1457 °C | MPa 515, Psi 75000 | MPa 205, Psi 30000 |
317 | 35 % | 7.9 g/centimeter3 | (2550 °F)1400 °C | MPa 515, Psi 75000 | MPa 205, Psi 30000 |
347 | 35 % | 8.0 g/centimeter3 | (2650 °F) 1454 °C | MPa 515, Psi 75000 | MPa 205, Psi 3000 |
Stainless Steel HF Tolerances | Plus | Minus | Out of Sq |
---|---|---|---|
Over 1-1/4″ to 1-3/8″ (inclusive) | 0.012 | 0.012 | 0.018 |
Over 1″ to 1-1/8″ (inclusive) | 0.010 | 0.010 | 0.015 |
Over 1-1/8″ to 1-1/4″ (inclusive) | 0.011 | 0.011 | 0.016 |
Over 1-1/2″ to 2″ (inclusive) | 1/64 | 1/64 | 0.023 |
Over 1-3/8″ to 1-1/2″ (inclusive) | 0.014 | 0.014 | 0.021 |
BD | Bright drawn | Slit rolled edge | SRE |
---|---|---|---|
CD | Cold drawn | Polished | P |
P&T | Peeled and turned | Rough turned/peeled | RT |
CF | Cold finished | Hot rolled pickled and annealed | HRAP |
CG | Centreless ground | Hot finished | HF |
ST | Smooth turned | reeled and Peeled | PR |
STANDARD | JIS | AFNOR | GOST | UNS | BS | WERKSTOFF NR. | EN |
---|---|---|---|---|---|---|---|
Stainless Steel 304L | SUS 304L | Z3CN18‐10 | 03Х18Н11 | S30403 | 3304S11 | 1.4306 / 1.4307 | X2CrNi18-9 / X2CrNi19-11 |
SS 310 | SUS 310 | – | 20Ch25N20S2 | S31000 | 310S24 | 1.4841 | X15CrNi25-20 |
SS 304H | – | – | – | S30409 | – | 1.4301 | – |
Stainless Steel 304 | SUS 304 | Z7CN18‐09 | 08Х18Н10 | S30400 | 304S31 | 1.4301 | X5CrNi18-10 |
SS 310S | SUS 310S | – | 20Ch23N18 | S31008 | 310S16 | 1.4845 | X8CrNi25-21 |
SS 310H | – | – | – | S31009 | – | – | – |
Stainless Steel 316L | SUS 316L | Z3CND17‐11‐02 / Z3CND18‐14‐03 | 03Ch17N14M3 / 03Ch17N14M2 | S31603 | 316S11 / 316S13 | 1.4404 / 1.4435 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
SS 316H | – | – | – | S31609 | – | 1.4401 | – |
Stainless Steel 316 | SUS 316 | Z7CND17‐11‐02 | – | S31600 | 316S31 / 316S33 | 1.4401 / 1.4436 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
SS 316Ti | SUS 316Ti | Z6CNDT17‐123 | 08Ch17N13M2T | S31635 | 320S31 | 1.4571 | X6CrNiMoTi17-12-2 |
SS 317 | SUS 317 | – | – | S31700 | – | 1.4449 | – |
SS 321 | SUS 321 | – | – | S32100 | – | 1.4541 | X6CrNiTi18-10 |
Stainless Steel 317L | SUS 317L | – | – | S31703 | – | 1.4438 | X2CrNiMo18-15-4 |
SS 321H | SUS 321H | – | – | S32109 | – | 1.4878 | X12CrNiTi18-9 |
SS 347H | SUS 347H | – | – | S34709 | – | 1.4961 | X6CrNiNb18-12 |
SS 347 | SUS 347 | – | 08Ch18N12B | S34700 | – | 1.4550 | X6CrNiNb18-10 |
Stainless Steel 904L | SUS 904L | Z2 NCDU 25-20 | STS 317J5L | N08904 | 904S13 | 1.4539 | X1NiCrMoCu25-20-5 |
SIZE in Milimeter | PERMITTED VARIATION CHART | |||
---|---|---|---|---|
PRIMARY ROLLED | RE-ROLLED | |||
DIAMETER +/- Milimeter | OUT OF SECTION Milimeter | OUT OF SECTION Milimeter | DIAMETER OR WIDTH ACROSS FLATS +/- Milimeter | |
<=16 | 0.3 | 0.2 | ||
>16 <=26 | 0.5 | 0.3 | ||
>26 <=38 | 0.6 | 0.4 | ||
>38 <=51 | 0.8 | 0.5 | ||
>51 <=64 | 0.9 | 0.6 | ||
>64 <=76 | 1.1 | 0.7 | ||
>76 <=90 | 1.3 | 2.0 | ||
>90 <=120 | 1.5 | 2.3 | ||
>120 <=160 | 2.0 | 3.0 | ||
>160 <=200 | 2.5 | 3.8 | ||
>200 | 3.0 | 4.5 |
Stainless Steel Square Bar | Cold Drawn Stainless Steel Square Bar |
Stainless Square Bar | Precision Ground Stainless Steel Square Bar |
Ss Square Bar | Stainless Steel Rectangular Hollow Bar |
Ss Square Rod | 1/4 Inch Stainless Steel Square Bar |
Stainless Steel Square Rod | Metric Stainless Steel Square Bar |
304 Stainless Steel Square Bar | Stainless Steel Twisted Square Bar |
303 Stainless Steel Square Bar | 316l Stainless Steel Square Bar |
8mm Square Stainless Steel Bar | 410 Stainless Steel Square Bar |
316 Stainless Steel Square Bar | 420 Stainless Steel Square Bar |
12mm Stainless Steel Square Bar | 440c Stainless Steel Square Bar |
10mm Stainless Steel Square Bar | Grade 304 Square Hollow Bar |
Ss 304 Square Bar | Stainless Steel 316 Box Bar |
10mm Square Stainless Steel Bar | Stainless Steel Square Hollow Bar |
6mm Square Stainless Steel Bar | Stainless Steel 316 Square Bar |
Stainless Steel Solid Square Bar | ASTM A276 Stainless Steel 316 Square Bar |
Stainless Square Rod | SS 316 Square Bars |
416 Stainless Steel Square Bar | Cold Finished Square Bar |
Brushed Stainless Steel Square Bar | Hot Finished Square Bar |
Stainless Steel Black Square Bar | Polished Stainless Steel Square Bar |
Square Bar Weight Formula 0.00623 X ( mm ) Diam X ( mm ) Diam = Weight / Meter 0.0019 X ( mm ) Diam X ( mm ) Diam = Weight / Feet |
Square Bar Weight Formula
0.00788 X ( mm ) Diam X ( mm ) Diam = Weight / Meter 0.00240 X ( mm ) Diam X ( mm ) Diam = Weight / Feet |
Square Bar Weight Forumla 0.00680 X ( mm ) Diam X ( mm ) Diam = Weight / Meter 0.002072 X ( mm ) Width X ( mm ) Diam = Weight / Feet |
Square Bar Weight Forumla 0.00798 X ( mm ) Thickness X ( mm ) Width = Weight / Meter 0.00243 X ( mm ) Width X ( mm ) Thickness = Weight / Fee |
