ASTM A182 F316 Blind Flanges and Stainless Steel Weld Neck Flange manufacturer in India
What is Stainless Steel 316 Flanges?
Stainless steel 316 flanges belong to an austenitic grade. These flanges are designed with a superior composition consisting of a minimum of 16% chromium, 10% nickel, and 2% molybdenum. The superior chemical composition embedded in the grades gives them enhanced resistance and tolerance against corrosive or oxidative media. The content of molybdenum gives them enhanced resistance to pitting by acids in marine systems. The versatile grade of flanges effectively seals a range of piping modules across stress-induced setups. The robust grade of 316 flanges can be readily welded or bolted in place following standard procedures.
ASTM A182 F316 Slip On Flange Vs SA182 F316 Weld Neck Flange
Slip on flanges along with weld neck flanges are amongst the common grades in the piping industry. These components can be differentiated based on certain features.
- ASTM A182 F316 Slip On Flange is designed with a low-profile head. SA182 F316 Weld Neck Flange is designed with a long hub or face type.
- Weld neck flanges are a preferred choice in higher pressure setups. Slip on flanges are commonly used in low-pressure systems.
- SS 316 grade slip on flange is welded in place using a fillet weld. SS 316 weld neck flange is welded using a butt-weld.
SA 182 F316 Threaded Flanges Vs A182 Gr F316 Socket Weld Flange
- SS 316 socket weld flanges are a less common grade of flanges and require lower fitting space compared to traditional flange types. The A182 Gr F316 Socket Weld Flange type is usually welded in place using a fillet weld. These flanges can withstand a range of high-pressure applications.
- SA 182 F316 Threaded Flanges are designed with threads that align directly to piping modules. The flanges are preferred in low-pressure systems and are a common grade in the industry.
Is SS 316 Stainless Steel Flange magnetic?
The SS 316 stainless steel flange is a wrought austenitic metal grade. These versatile flanges are non-magnetic in nature.
Table of Content
316 Stainless Steel Pipe Flanges Specification
| Specifications | ASTM A182 F316 Flange/ Stainless Steel 316 Flanges |
|---|---|
| JIS Standard | 30, 20, 40, 5, 16 10, 63 K |
| Available Sizes | 1/2 To 48 Inch |
| Main Types | Screwed / Forged / Plate/ Threaded |
| ANSI Standard | Class 150 to Class 2500 LBS |
| Supporting material | Ring Joint Gasket Flange Bolts |
| EN Standard | 6, 16, 40, 25, 10 Bar |
| Test | Magnetic particle detector UI trasonic flaw detector X ray detector Direct reading Spectrograph Hydrostatic testing machine |
| UNI Standard | 6, 16, 40, 25, 10 Bar |
| Standards | ASME B16.5, DIN, ANSI Flanges, B16.47 Series A and B, B16.48, BS 10, EN 1092, ASME Flanges, BS Flanges, BS4504, EN Flanges, GOST Flanges, DIN Flanges |
| DIN Standard | 16, 40, 10, 6, 25 Bar / PN64, PN10, PN16, PN6, PN25, PN40 |
| Equipment used | Pushing Machine, Sand-blasting machine, Press machine, Bending machine, electric bevelling machine |
| Flange Face Type | Large Tongue and Groove, Lap Joint Face, Large Male Female, Flat Face, Small Tongue, Raised Face, Small Male Female, Ring Joint Flanges manufacturer and Supplier |
| Technique | Heat treated machined Forged |
| Marking | All SS 316 Flange are marked as follows: Supplier or Manufacturer’s Name, Class, Dimension, Size, Bore, Material, Heat No. (Or according to the customer’s request) |
SS 316 Flange Price List India
| Products | Size | Flange Outside Diameter | Number of Bolt Holes | Price |
|---|---|---|---|---|
| STAINLESS STEEL MALLEABLE ROUGH/MACHINEDCASTINGS ( P-BDY-224, REV-D, 316: FLANGED BODY | 1 in | 4-1/4 in | 4 | $48.71 |
| STAINLESS STEEL FLANGE:STUTZKORBRING DRW16-266(SS 316) | 1-1/2 in | 5 in | 4 | $59.80 |
| S.S. FITTINGS - STAINLESS STEEL FLANGES- FLANGE WNRF 8 CLASS 150, A182 F 316 | 2 in | 6 in | 4 | $84.60 |
| Stainless Steel Forged Flanges 316 931402XA06 9150077-129FLANGE 3 150 316 SST | 2-1/2 in | 7 in | 4 | $119.62 |
| FLANGES STAINLESS STEEL SA182 GR F316 4WN 150 RF STD/40S 125-250 RMS(5NOS) |
3 in | 7-1/2 in | 4 | $134.13 |
| STAINLESS STEEL FORGED FLANGES- PM NO.550200XA02 PART NO.DP0008-5040-S6 FLANGE DIN DN50 PN40 316 | 4 in | 9 in | 8 | $188.85 |
| Stainless Steel Forged Flanges 316 058100XA03 9150077-134FLANGE 4 150 (WELD) | 6 in | 11 in | 8 | $299.01 |
Types of Stainless Sreel 316 FLanges
316 Stainless Steel SWRF Flanges
ASTM A182 F316 Slip On Flange
SA182 F316 SORF Flanges
ASTM A182 F316 Weld Neck Flanges
SA182 Gr F316 WNRF Flange
Stainless Steel 316 Socket Weld Flange
UNS S31600 Orifice Flanges
AISI 316 Spectacle Blind Flange
SUS 316 Tongue & Groove Flange
EN 1.4401 Ring Joint Flange
1.4401 Stainless Steel Girth Flanges
AISI 316 Stainless Steel Expander Flanges
ASME SA182 F316 Nipo Flanges
Werkstoff No 1.4401 Long Weld Neck Flange
SS 316 Reducing Flanges
ASTM A182 Grade F316 Blind Flange
SS DIN 1.4401 BLRF Flanges
ASTM A182 Gr F316 Lapped Joint Flange
SA 182 Gr F316 Screwed Flange
UNS S31600 Stainless Steel Threaded Flange
SS 316 Flange Dimensions
| Nominal Pipe Size | Diameter of Hub at Bevel | Thickness of Flange | Diameter of Raised Face | Outside Diameter of Flange | Radius of Fillet | Diameter of Hub at Base | Diameter or Bore | Depth of Socket | Length Thru Hub | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Slip-on Socket | Lap Joint | Welding Neck | Slip-On Threaded Socket | Lap Joint | ||||||||
| H | Q | R | O | r | X | W | B | Z | Y | Y | Y | |
| 3/4 | 1.05 | 1/2 | 1-11/16 | 3-7/8 | 1/8 | 1-1/2 | 1.09 | 1.11 | 7/16 | 2-1/16 | 5/8 | 5/8 |
| 12 | 12.75 | 1-1/4 | 15 | 19 | 1/2 | 14-3/8 | 12.88 | 12.92 | 1-9/16 | 4-1/2 | 2-3/16 | 2-3/16 |
| 1 | 1.32 | 9/16 | 2 | 4-1/4 | 1/8 | 1-15/16 | 1.36 | 1.38 | 1/2 | 2-3/16 | 11/16 | 11/16 |
| 6 | 6.63 | 1 | 8-1/2 | 11 | 1/2 | 7-9/16 | 6.72 | 6.75 | 1-1/16 | 3-1/2 | 1-9/16 | 1-9/16 |
| 1-1/4 | 1.66 | 5/8 | 2-1/2 | 4-5/8 | 3/16 | 2-5/16 | 1.70 | 1.72 | 9/16 | 2-1/4 | 13/16 | 13/16 |
| 1-1/2 | 1.90 | 11/16 | 2-7/8 | 5 | 1/4 | 2-9/16 | 1.95 | 1.97 | 5/8 | 2-7/16 | 7/8 | 7/8 |
| 16 | 16.00 | 1-7/16 | 18-1/2 | 23-1/2 | 1/2 | 18 | 16.16 | 16.19 | 1-3/4 | 5 | 2-1/2 | 3-7/16 |
| 2 | 2.38 | 3/4 | 3-5/8 | 6 | 5/16 | 3-1/16 | 2.44 | 2.46 | 11/16 | 2-1/2 | 1 | 1 |
| 1/2 | .84 | 7/16 | 1-3/8 | 3-1/2 | 1/8 | 1-3/16 | .88 | .90 | 3/8 | 1-7/8 | 5/8 | 5/8 |
| 18 | 18.00 | 1-9/16 | 21 | 25 | 1/2 | 19-7/8 | 18.18 | 18.20 | 1-15/16 | 5-1/2 | 2-11/16 | 3-13/16 |
| 2-1/2 | 2.88 | 7/8 | 4-1/8 | 7 | 5/16 | 3-9/16 | 2.94 | 2.97 | 3/4 | 2-3/4 | 1-1/8 | 1-1/8 |
| 3 | 3.50 | 15/16 | 5 | 7-1/2 | 3/8 | 4-1/4 | 3.57 | 3.60 | 13/16 | 2-3/4 | 1-3/16 | 1-3/16 |
| 20 | 20.00 | 1-11/16 | 23 | 27-1/2 | 1/2 | 22 | 20.20 | 20.25 | 2-1/8 | 5-11/16 | 2-7/8 | 4-1/16 |
| 10 | 10.75 | 1-3/16 | 12-3/4 | 16 | 1/2 | 12 | 10.88 | 10.92 | 1-5/16 | 4 | 1-15/16 | 1-15/16 |
| 3-1/2 | 4.00 | 15/16 | 5-1/2 | 8-1/2 | 3/8 | 4-13/16 | 4.07 | 4.10 | 7/8 | 2-13/16 | 1-1/4 | 1-1/4 |
| 4 | 4.50 | 15/16 | 6-3/16 | 9 | 7/16 | 5-5/16 | 4.57 | 4.60 | 15/16 | 3 | 1-5/16 | 1-5/16 |
| 5 | 5.56 | 15/16 | 7.5/16 | 10 | 7/16 | 6-7/16 | 5.66 | 5.69 | 15/16 | 3-1/2 | 1-7/16 | 1-7/16 |
| 8 | 8.63 | 1-1/8 | 10-5/8 | 13-1/2 | 1/2 | 9-11/16 | 8.72 | 8.75 | 1-1/4 | 4 | 1-3/4 | 1-3/4 |
| 14 | 14.00 | 1-3/8 | 16-1/4 | 21 | 1/2 | 15-3/4 | 14.14 | 14.18 | 1-5/8 | 5 | 2-1/4 | 3-1/8 |
| 24 | 24.00 | 1-7/8 | 27-1/4 | 32 | 1/2 | 26-1/8 | 24.25 | 24.25 | 2-1/2 | 6 | 3-1/4 | 4-3/8 |
SS 316 Puddle Flange Pressure Rating
| Temperature (°C) | Class 900 | Class 150 | Class 2500 | Class 400 | Class 300 | Class 1500 | Class 600 |
|---|---|---|---|---|---|---|---|
| -29 - 38 | 155 | 19.8 | 431 | 68.9 | 51.7 | 259 | 103.4 |
| 50 | 155 | 19.5 | 431 | 68.9 | 51.7 | 259 | 103.4 |
| 300 | 129 | 10.2 | 357 | 57.0 | 42.9 | 214 | 85.7 |
| 150 | 151 | 15.8 | 418 | 66.8 | 50.2 | 251 | 100.3 |
| 475 | 51.3 | 3.7 | 142 | 22.8 | 17.1 | 85.4 | 34.2 |
| 100 | 155 | 17.7 | 429 | 68.7 | 51.5 | 258 | 103.0 |
| 425 | 86.3 | 5.5 | 240 | 38.4 | 28.8 | 144 | 57.5 |
| 200 | 146 | 13.8 | 405 | 64.8 | 48.6 | 243 | 97.2 |
| 325 | 124 | 9.3 | 344 | 55.0 | 41.4 | 207 | 82.6 |
| 350 | 120 | 8.4 | 334 | 53.4 | 40.0 | 200 | 80.0 |
| 400 | 104 | 6.5 | 290 | 46.3 | 34.7 | 174 | 69.4 |
| 250 | 139 | 12.1 | 386 | 61.7 | 46.3 | 232 | 92.7 |
| 375 | 114 | 7.4 | 315 | 50.4 | 37.8 | 189 | 75.7 |
| 450 | 69.0 | 4.6 | 192 | 30.7 | 23.0 | 115 | 46.0 |
| 500 | 34.7 | 2.8 | 96.5 | 15.4 | 11.6 | 57.9 | 23.2 |
| 538 | 17.7 | 1.4 | 49.2 | 7.9 | 5.9 | 29.5 | 11.8 |
316 SS Blind Flange Heat Treatment
- Treatment of the Solution (Annealing) Heat to 1010-1120°C and quickly cool. Thermal treatment will not harden these grades.
316 Stainless Steel Flanges Size Chart
| Nominal Pipe Size | Diameter of Hub at Bevel | Thickness of Flanges | Diameter of Raised Face | Outside Diameter of Flanges | Length Thru Hub | Radius of Fillet | Diameter of Hub at Base | Depth of Socket | Diameter or Bore | |||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Welding Neck | Slip-On Threaded Socket | Lap Joint | Slip-on Socket | Lap Joint | ||||||||
| 2 | 2.38 | 3/4 | 3-5/8 | 6 | 2-1/2 | 1 | 1 | 5/16 | 3-1/16 | 11/16 | 2.44 | 2.46 |
| 3/4 | 1.05 | 1/2 | 1-11/16 | 3-7/8 | 2-1/16 | 5/8 | 5/8 | 1/8 | 1-1/2 | 7/16 | 1.09 | 1.11 |
| 1 | 1.32 | 9/16 | 2 | 4-1/4 | 2-3/16 | 11/16 | 11/16 | 1/8 | 1-15/16 | 1/2 | 1.36 | 1.38 |
| 1-1/4 | 1.66 | 5/8 | 2-1/2 | 4-5/8 | 2-1/4 | 13/16 | 13/16 | 3/16 | 2-5/16 | 9/16 | 1.70 | 1.72 |
| 1/2 | .84 | 7/16 | 1-3/8 | 3-1/2 | 1-7/8 | 5/8 | 5/8 | 1/8 | 1-3/16 | 3/8 | .88 | .90 |
| 1-1/2 | 1.90 | 11/16 | 2-7/8 | 5 | 2-7/16 | 7/8 | 7/8 | 1/4 | 2-9/16 | 5/8 | 1.95 | 1.97 |
| 2-1/2 | 2.88 | 7/8 | 4-1/8 | 7 | 2-3/4 | 1-1/8 | 1-1/8 | 5/16 | 3-9/16 | 3/4 | 2.94 | 2.97 |
| 3 | 3.50 | 15/16 | 5 | 7-1/2 | 2-3/4 | 1-3/16 | 1-3/16 | 3/8 | 4-1/4 | 13/16 | 3.57 | 3.60 |
| 3-1/2 | 4.00 | 15/16 | 5-1/2 | 8-1/2 | 2-13/16 | 1-1/4 | 1-1/4 | 3/8 | 4-13/16 | 7/8 | 4.07 | 4.10 |
| 4 | 4.50 | 15/16 | 6-3/16 | 9 | 3 | 1-5/16 | 1-5/16 | 7/16 | 5-5/16 | 15/16 | 4.57 | 4.60 |
| 6 | 6.63 | 1 | 8-1/2 | 11 | 3-1/2 | 1-9/16 | 1-9/16 | 1/2 | 7-9/16 | 1-1/16 | 6.72 | 6.75 |
| 8 | 8.63 | 1-1/8 | 10-5/8 | 13-1/2 | 4 | 1-3/4 | 1-3/4 | 1/2 | 9-11/16 | 1-1/4 | 8.72 | 8.75 |
| 10 | 10.75 | 1-3/16 | 12-3/4 | 16 | 4 | 1-15/16 | 1-15/16 | 1/2 | 12 | 1-5/16 | 10.88 | 10.92 |
| 12 | 12.75 | 1-1/4 | 15 | 19 | 4-1/2 | 2-3/16 | 2-3/16 | 1/2 | 14-3/8 | 1-9/16 | 12.88 | 12.92 |
| 14 | 14.00 | 1-3/8 | 16-1/4 | 21 | 5 | 2-1/4 | 3-1/8 | 1/2 | 15-3/4 | 1-5/8 | 14.14 | 14.18 |
| 5 | 5.56 | 15/16 | 7.5/16 | 10 | 3-1/2 | 1-7/16 | 1-7/16 | 7/16 | 6-7/16 | 15/16 | 5.66 | 5.69 |
| 16 | 16.00 | 1-7/16 | 18-1/2 | 23-1/2 | 5 | 2-1/2 | 3-7/16 | 1/2 | 18 | 1-3/4 | 16.16 | 16.19 |
| 18 | 18.00 | 1-9/16 | 21 | 25 | 5-1/2 | 2-11/16 | 3-13/16 | 1/2 | 19-7/8 | 1-15/16 | 18.18 | 18.20 |
| 24 | 24.00 | 1-7/8 | 27-1/4 | 32 | 6 | 3-1/4 | 4-3/8 | 1/2 | 26-1/8 | 2-1/2 | 24.25 | 24.25 |
| 20 | 20.00 | 1-11/16 | 23 | 27-1/2 | 5-11/16 | 2-7/8 | 4-1/16 | 1/2 | 22 | 2-1/8 | 20.20 | 20.25 |
Contact directly a BS10 Table D 316 Stainless Steel Plate Flange, Gost 12815 ASTM A182 F316 Socket Weld Flange manufacturer in India for factory price and custom sizes, Supplier of ANSI B16.5 Class 300/ 600/ 900 Stainless Steel 316 Slip On Flange according to American standards ASME B16.5, View Price List of AISI 316 Lap Joint Flange material
Stainless Sreel 316 FLanges HSN Code
| Description | HSN Code |
|---|---|
| Stainless Steel 316 Flanges | 73072100 |
ASTM A182 F316 Flanges Hardness
| Hardness MAX, Brinell | 217 |
|---|
A182 Gr F316 SORF Applications
- Oil And Gas Industry
- Aviation And Aerospace Industry
- Petrochemical Industry
- Architectural Decoration Industry
- Food Industry
- Pharmaceutical Industry
SS 316 Slip On Flange Torque Chart
| Size in Inch | Bolt Stress lb/in2 |
Size in MM | Torque lbf.ft. |
Number of Bolt | Bolt Diameter | Torque Nm |
|---|---|---|---|---|---|---|
| 10 | 40,000 | 250 | 194 | 12 | 7/8 | 263 |
| 3/4 | 30,000 | 20 | 26 | 4 | ½ | 36 |
| 6 | 45,000 | 150 | 137 | 8 | ¾ | 185 |
| 20 | 40,000 | 500 | 421 | 20 | 1 1/8 | 571 |
| 1 | 33,000 | 35 | 29 | 4 | ½ | 39 |
| 1 ½ | 50,000 | 40 | 44 | 4 | ½ | 60 |
| 1/2 | 25,000 | 15 | 22 | 4 | ½ | 30 |
| 18 | 40,000 | 450 | 421 | 16 | 1 1/8 | 571 |
| 2 | 50,000 | 50 | 86 | 4 | 5/8 | 117 |
| 12 | 40,000 | 300 | 194 | 12 | 7/8 | 263 |
| 3 | 50,000 | 80 | 86 | 4 | 5/8 | 117 |
| 16 | 40,000 | 400 | 289 | 16 | 1 | 392 |
| 4 | 40,000 | 100 | 69 | 8 | 5/8 | 93 |
| 8 | 45,000 | 200 | 137 | 8 | ¾ | 185 |
| 14 | 41,000 | 350 | 296 | 12 | 1 | 401 |
| 24 | 40,000 | 600 | 588 | 20 | 1 ¼ | 797 |
EN 1092-2 PN10 AISI 316 Stainless Steel Spectacle Blind Flange manufacturers for specific design, We offer custom size AS/NZ 4087 SA182 F316 Orifice Flanges in India, Stockist and Distributor of SUS 316 Threaded Flange for leak-free connections, best price of SS 316 Puddle Flange in Mumbai
ASTM A182 F316 Stainless Steel Flanges Weight Chart
| Pipe Normal Diameter in Inch | Length Hub | Diameter of Raised Face | Diamete. of Bolt Circle |
Thickness Of Flange in Min | Thread Length | Number of Bolts |
Diameter of Bolts (inch) |
Outer Diameter Flange | LBS | Diameter. of Hub |
Diameter of Bolt Holes |
KGS | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3 | 80 | 30.20 | 127.00 | 152.40 | 23.90 | 30.20 | 4 | 5/8 | 190.50 | 9 | 108.00 | 19.10 | 4.1 |
| 1/2 | 15 | 15.70 | 35.10 | 60.50 | 11.20 | 15.70 | 4 | 1/2 | 89.00 | 0.9 | 30.20 | 15.80 | 0.4 |
| 18 | 450 | 68.30 | 533.40 | 577.90 | 39.60 | 68.30 | 16 | 1 1/8 | 635.00 | 126 | 505.00 | 31.80 | 57 |
| 1 | 25 | 17.50 | 50.80 | 79.30 | 14.20 | 17.50 | 4 | 1/2 | 108.00 | 1.8 | 49.30 | 15.80 | 0.8 |
| 12 | 300 | 55.60 | 381.00 | 431.80 | 31.80 | 55.60 | 12 | 7/8 | 482.50 | 64 | 365.30 | 25.40 | 29 |
| 1-1/4 | 32 | 20.60 | 63.50 | 88.90 | 15.70 | 20.60 | 4 | 1/2 | 117.50 | 2.6 | 58.70 | 15.80 | 1.2 |
| 3/4 | 20 | 15.70 | 42.90 | 69.90 | 12.70 | 15.70 | 4 | 1/2 | 98.50 | 1.5 | 38.10 | 15.80 | 0.7 |
| 1-1/2 | 40 | 22.40 | 73.20 | 98.60 | 17.50 | 22.40 | 4 | 1/2 | 127.00 | 3.3 | 65.00 | 15.80 | 1.5 |
| 2 | 50 | 25.40 | 91.90 | 120.70 | 19.10 | 25.40 | 4 | 5/8 | 152.50 | 5.1 | 77.70 | 19.10 | 2.3 |
| 2-1/2 | 65 | 28.40 | 104.60 | 139.70 | 22.40 | 28.40 | 4 | 5/8 | 178.00 | 8.1 | 90.40 | 19.10 | 3.7 |
| 10 | 250 | 49.30 | 323.90 | 362.00 | 30.20 | 49.30 | 12 | 7/8 | 406.50 | 39.5 | 304.80 | 25.40 | 18 |
| 3-1/2 | 90 | 31.80 | 139.70 | 177.80 | 23.90 | 31.80 | 8 | 5/8 | 216.00 | 11.2 | 122.20 | 19.10 | 5.1 |
| 16 | 400 | 63.50 | 469.90 | 539.80 | 36.60 | 63.50 | 16 | 1 | 597.00 | 103 | 457.20 | 28.50 | 47 |
| 4 | 100 | 33.30 | 157.20 | 190.50 | 23.90 | 33.30 | 8 | 5/8 | 228.50 | 13 | 134.90 | 19.10 | 5.9 |
| 20 | 500 | 73.20 | 584.20 | 635.00 | 42.90 | 73.20 | 20 | 1 1/8 | 698.50 | 167 | 558.80 | 31.80 | 76 |
| 5 | 125 | 36.60 | 185.70 | 215.90 | 23.90 | 36.60 | 8 | 3/4 | 254.00 | 15.4 | 163.60 | 22.40 | 7 |
| 14 | 350 | 57.20 | 412.80 | 476.30 | 35.10 | 57.20 | 12 | 1 | 533.50 | 86 | 400.10 | 28.50 | 39 |
| 6 | 150 | 39.60 | 215.90 | 241.30 | 25.40 | 39.60 | 8 | 3/4 | 279.50 | 18.5 | 192.00 | 22.40 | 8.4 |
| 8 | 200 | 44.50 | 269.70 | 298.50 | 28.40 | 44.50 | 8 | 3/4 | 343.00 | 28.6 | 246.10 | 22.40 | 13 |
| 24 | 600 | 82.60 | 692.20 | 749.30 | 47.80 | 82.60 | 20 | 1 1/4 | 813.00 | 214 | 663.40 | 35.10 | 97 |
SS UNS S31600 Pipe Flanges Chemical Composition
| Grade | Chromium | Carbon | Nickel | Manganese | Sulfur | Silicon | Nitrogen | Phosphorus | Molybdenum |
|---|---|---|---|---|---|---|---|---|---|
| Stainless Steel 316 Flanges | 16 To 18 | 0.08 | 11 To 14 | 2 | 0.030 | 1 | 67.845 | 0.045 | 2 To 3 |
Stainless Sreel 316 FLanges Equivalent
| Standard | British Standards | Werkstoff Nr. | AFNOR | Unified Numbering System | European Standards | Japanese Standards |
|---|---|---|---|---|---|---|
| Stainless Steel 316 Flange | 316S31 / 316S33 | 1.4401 / 1.4436 | Z7CND17‐11‐02 | S31600 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 | SUS 316 |
ANSI B16.5 SS 316 Orifice Flanges Mechanical Properties
| Density | Yield Properties | Melting Point | Tensile Properties | Elongational |
|---|---|---|---|---|
| 8.0 g/cm3 | Psi – 30000, MPa – 205 | 1400 °C (2550 °F) | Psi – 75000, MPa – 515 | 35 % |
ASME B16.5 316 Stainless Steel Pipe Flanges manufacturer in India, we supply ASTM A182 F316 Flanges, SS316 SORF Flange with mechanical performance testing
ASTM A182 316 SS Plate Flange Physical Properties
| DENSITY LBM/IN^3 | SPECIFIC HEAT (BTU/LB/°F) | MELTING RANGE(°F) | THERMAL CONDUCTIVITY (BTU/H FT. °F) | ELECTRICAL RESISTIVITY(IN X 10^-6) | MODULUS OF ELASTICITY(PSI X 10^6) | COEFFICIENT OF THERMAL EXPANSION (IN/IN)/°F X 10^-6 |
|---|---|---|---|---|---|---|
| at 68°F: 0.285 | 0.1200 at 68°F to 212°F | 2500 to 2590 | 8.7 at 212°F | 27.6 at 68°F | 29 | 9.4 at 32 – 212°F |
A182 F316 Slip On Flange Heat Resistance
Intermittent service to 870°C and continuous service to 925°C have good oxidation resistance. If water corrosion resistance is necessary, continuous usage of 316 in the 425-860°C range is not suggested.
SS UNS S31600 WNRF Flanges Density
| Property | Minimum Value (S.I.) | Units (S.I.) |
|---|---|---|
| Density | 7.87 | Mg/m3 |
Stainless steel 316 Pipe Flanges Marking
- Flanges Type = (Blind)
- Schedule = (SCH 40)
- Material Designation = (ASTM A182 F304)
- Name of Manufacturer = (P.M.Metal)
- NPS = (2 Inch)
- Class = (150)
- Face Type = (RF)
- Country Name = (Made In India)
Check and compare our quality and pricing with any SS 316 Blind Flange, ASME B1.20.1 Class 300 SS 316 Flanges manufacturers in India, ASTM A182 Gr F316 SORF Flanges supplier in India offer Technical Inspection & MTR with all delivery
Stainless Sreel 316 FLanges Inventory
| 316 Stainless Steel Pipe Flanges | ANSI B16.5 SS 316 Orifice Flanges |
| 316 Stainless Steel Blind Flange | Werkstoff No 1.4401 SS Socket Weld Flanges |
| SS 316 Flange | Stainless Steel ASTM A182 F316 Threaded Flanges |
| SS 316 Puddle Flange | 316 SS Lapped joint Flanges |
| 316 SS Flanges | ASTM A182 316 SS Plate Flange |
| 316 SS Blind Flange | Stainless Steel 316 RTJ Flange |
| Stainless Steel 316 Flanges | 316 SS WNRF Flanges |
| Ss 316 Flanges | ASME SA182M Stainless Steel 316 Class 300 Flange |
| 316 Stainless Steel Flanges | SS Grade F316 Flat Flange |
| Ss 316 Flange Price | SS 316 EN 1092-1 Flanges |
| ASTM A182 F316 Flanges | A182 F316 Slip On Flange |
| A182 F316 Material | ASME SA182 SS 316 Weld Neck Flange |
| A182 Grade F316 BLRF | SS DIN 1.4401 Nippolet Flanges |
| A182 Gr F316 SORF | ASTM A182 SS F316 Plate flange |
| SS 316 Blind Flange | ANSI B16.5 SS F316 Lap Joint Flange |
| SS 316 Slip On Flange | ANSI B16.5 SS 316 Socket Weld Flanges |
| ASTM A182 F316 Stainless Steel Flanges | SS UNS S31600 WNRF Flanges |
| Stainless Steel 316 Slip On Flanges | 316 stainless steel Ring Type Joint Flanges |
| SS UNS S31600 Pipe Flanges | SS UNS S31600 Long Weld Neck Flange |
| SS F316 Flange | SS WERKSTOFF NR. 1.4401 Threaded Flanges |
| SS 316 Blind Flanges | 316 Stainless Steel Spectacle Blind Flanges |
| SS 316 Weld Neck Flange | Stainless steel 316 Pipe Flanges |
Searching for
Stainless Steel 316 FLanges Manufacturer in your country? Checklist of material we export in the following areas.
316 Stainless Steel Flanges
Bangladesh, Jakarta -Indonesia, Dubai, Los Alamos -Mexico, Hong Kong, Turkey, Argentina, Germany, China, Oman, Saudi Arabia (KSA).
ANSI B16.5 SS 316 Orifice Flanges
Malaysia, Poland, Romania, Indonesia, Malaysia, Iran, Qatar, New Zealand, Brazil, Netherlands, United Arab Emirates (UAE).
Werkstoff No 1.4401 SS Socket Weld Flanges
USA, Chile, Ellington -United States, Canada, Sweden, United States, Greece, Singapore, Vietnam, Mexico, Denmark, Thailand, Finland.
316 SS WNRF Flanges
Russia, Belgium, Norway, Egypt, Bahrain, Philippines, South Korea, Peru, Malaysia, Tehran -Iran, Colombia, Italy.
ASME SA182 SS 316 Weld Neck Flange
Spain, Jakarta, Europe, Australia, Jordan, Dammam -KSA, Japan, Istanbul -Turkey, NY 12203 (USA), Dubai -UAE, Kuala Lumpur.
Stainless steel 316 Pipe Flanges
France, Singapore, Taiwan, South Africa, Portugal, Morocco, Czechia, Kuwait, Austria, United Kingdom (UK), Nigeria.
